Baxi Fires Division Heartbeat Oxysafe 2 Installer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 339
Heartbeat Oxysafe 2
LIVE FUEL EFFECT GAS FIRE
(GC No. 32-032-29)
We trust that this guide gives
sufficient details to enable this
appliance to be installed and
maintained satisfactorily. However, if
further information is required, our
Baxi Fires Division Technical
Helpline will be pleased to help.
Telephone 08706 061 065 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 8706 061 065.
INSTALLER: Please leave this guide with the
©
Baxi Heating U.K. Limited 2007.
INSTALLER GUIDE
THIS APPLIANCE IS FOR USE WITH
NATURAL GAS (G20).
THIS APPLIANCE IS SUITABLE ONLY
FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC
OF IRELAND (IE).
600B687/11
owner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heartbeat Oxysafe 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi Fires Division Heartbeat Oxysafe 2

Summary of Contents for Baxi Fires Division Heartbeat Oxysafe 2

  • Page 1 600B687/11 INSTALLER GUIDE Model 339 Heartbeat Oxysafe 2 LIVE FUEL EFFECT GAS FIRE (GC No. 32-032-29) We trust that this guide gives sufficient details to enable this THIS APPLIANCE IS FOR USE WITH appliance to be installed and NATURAL GAS (G20).
  • Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Baxi Fires Division, Erdington, Birmingham B24 9QP www.firesandstoves.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication ©...
  • Page 3 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Baxi Fires Division is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance. Careful Installation Baxi Fires Division is a CORGI registered company.

  • Page 4: Table Of Contents

    INSTALLER GUIDE CONTENTS Section Heading Page 1 SAFETY 2 LIST OF ACCESSORIES 3 APPLIANCE DATA 4 GENERAL INSTALLATION REQUIREMENTS 4.11.2 Conventional fireplace. 4.11.3 Wall mounting to conventional or pre-cast flues. 4.11.4 Precast flues. 4.11.5 Metal flue box. 5 PRE-INSTALLATION PREPARATION 5.1 Unpacking.

  • Page 5: Safety

    INSTALLER GUIDE 1 SAFETY Installer Before continuing any further with the installation of this appliance please read the following guide to manual handling: The lifting weight of this appliance is 15.43 kg. One person should be sufficient to lift the fire. If for any reason this weight is considered too heavy then obtain assistance.

  • Page 6: Appliance Data

    INSTALLER GUIDE 3 APPLIANCE DATA Natural (G20) Inlet Pressure 20mbar Gross Heat Input Control Setting 5.05kW (17,200Btu/h) 3.45kW (11,800Btu/h) 1.80kW (6,100Btu/h) 1.55kW (5,300Btu/h) Burner Test Pressure (Cold) 17.2 + 0.75mbar (6.9 + 0.3in w.g.) Gas Connection 8mm pipe Burner Injectors Upper Bray Cat.
  • Page 7 INSTALLER GUIDE The conversion of net efficiency to gross was achieved by multiplying the net efficiency by the following conversion factor from Table E3 of SAP 2005, rounding down to the nearest whole number. Conversion factor from net to gross efficiency Natural Gas 0.901 This product uses a burner gasket and burner surface containing Refractory...

  • Page 8: General Installation Requirements

    INSTALLER GUIDE 4 GENERAL INSTALLATION REQUIREMENTS The installation must be in accordance with these instructions. For the user’s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations.
  • Page 9 INSTALLER GUIDE Any chimney dampers or restrictors should be removed. If removal is not possible they must be fixed in the open position. Normal adventitious ventilation is usually sufficient to satisfy the ventilation requirements of this appliance. In GB reference should be made to BS 5871 Part 2 and in IE reference should be made to the current edition of IS 813 “Domestic gas Installations”...
  • Page 10 INSTALLER GUIDE The minimum allowable distance from the outside of the appliance fascia to a corner wall having combustible material or any other combustible surface which projects beyond the front of the appliance is 100mm at either side (See figure 1). A clearance of 100mm should be maintained at the right side in all installations to allow satisfactory access to the control knob.

  • Page 11: Conventional Fireplace

    4.11 In the United Kingdom, as supplied, this appliance can be installed in the following situations: - Note: A spigot extension is available (Baxi Fires Division part number 0595191). When fitted this shall extend through the closure plate for at least 15mm and have a minimum clearance of 50mm from the end to any surface.

  • Page 12: Precast Flues

    INSTALLER GUIDE finished floor covering. Any opening visible below the appliance may be closed in but the depth of the catchment space within the wall opening must be as shown in figure 2. 4.11.4 Precast flues. The appliance can be installed to a fireplace that has a properly constructed precast concrete or clay flue block system conforming to BS1289 or BS EN 1806.
  • Page 13 INSTALLER GUIDE * The total height of the closure plate is 660mm and will accommodate a maximum opening height of 650mm (This allows a 10mm overhang). Heights above 623mm (Inclusive of sealing tape) will leave the sealing tape and closure plate visible above the appliance.
  • Page 14 INSTALLER GUIDE There must also be a minimum clearance of 165mm between the back of the closure plate and the back of the catchment space. On conventional flues the catchment space below the flue spigot must extend at least 250mm downward measured from the bottom of the flue spigot (See figure 2). 4.16 The front of the fireplace should be flat over an area sufficient to ensure a good seal with the closure plate.

  • Page 15: Pre-Installation Preparation

    INSTALLER GUIDE 5 PRE-INSTALLATION PREPARATION 5.1 Unpacking. The carton contains the following:- 1off Fire assembly. 1off Ceramic fuel effect (In packaging inside firebox). 1off Closure plate. 1off Smoke match tube. 1off Olive & olive nut for gas line connection 1off Literature pack Remove all the items carefully to prevent damage.
  • Page 16 INSTALLER GUIDE 5.3.5. Remove the control bezel by unscrewing two screws (See figure 6). 5.3.6. Detach the fascia by removing the screws at the fascia sides (See figure 6). 5.3.7. Pull the bottom of the fascia forward while springing the bottom corners outward to clear the fixing brackets.
  • Page 17 INSTALLER GUIDE required the opening should be completely sealed with tape. 5.4.1 Hearth mounting (See figure 9). The closure plate must be fitted and sealed to the hearth and fireplace opening using a suitable heat resistant material. If necessary cut the closure plate but make sure that it overlaps the fireplace opening sufficiently to allow satisfactory sealing.

  • Page 18: Appliance Installation

    INSTALLER GUIDE 5.4.2 Wall mounting (See figure 10). The closure plate must be fitted and sealed to the hearth and fireplace opening using a suitable heat resistant material. If necessary cut the closure plate but make sure that it overlaps the fireplace opening sufficiently to allow satisfactory sealing.

  • Page 19: Gas Supply Connection

    INSTALLER GUIDE flue spigot opening are shown in figure 11. Mark these positions on the wall. The positions can alternatively be marked by placing the fire in position and marking the wall through the holes in the back panel. Drill and plug the holes using no.

  • Page 20: Control And Pressure Checks

    INSTALLER GUIDE 7 CONTROL AND PRESSURE CHECKS 7.1 Check control settings. 7.1.1 If closed, open the isolating valve at the inlet ‘T’ connector. 7.1.2 To help in checking the control positions while the fascia is detached, place the control bezel over the gas tap spindle and against the tap bracket. Temporarily secure to the tap bracket with one of the screws.
  • Page 21 INSTALLER GUIDE 7.3 Test for spillage. A spillage test must be made before the installed appliance is left with the customer. 7.3.1 Close all doors and windows in the room containing the fire. 7.3.2 Light the appliance and set the control knob to the maximum position (Position 4).

  • Page 22: Flame Supervision And Spillage Monitoring System

    This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system must only be exchanged using Baxi Fires Division authorised parts. 8 FINAL ASSEMBLY AND REVIEW 8.1 Fitting the fascia.

  • Page 23: Servicing And Parts Replacement

    INSTALLER GUIDE 8.2.4 Explain to the customer that the appliance has a flame failure and spillage monitoring system. Point out the explanation of this system shown in the owner guide. Advise that if the fire goes out for any reason, wait at least three minutes before relighting.

  • Page 24: To Remove The Window Unit

    INSTALLER GUIDE recommend that you use a HEPA filtered vacuum to remove any dust and soot accumulated in and around the fire before and after working on the fire. Do NOT vacuum the burner surface. When replacing the the burner surface we recommend that the replaced items are not broken up, but are sealed within a heavy duty polythene bag, clearly labelled as RCF waste.

  • Page 25: To Remove The Gas Tap

    INSTALLER GUIDE 9.4 To remove the gas tap. 9.4.1 Remove the fascia as section 9.2 above. 9.4.2 Detach the electrode lead from the pilot unit by pulling the lead down and away from the electrode situated at the centre rear of the burner. 9.4.3 Disconnect the two pipes linking the upper and lower injectors at the tap end and loosen their connections at the injector ends.

  • Page 26: To Remove An Injector

    INSTALLER GUIDE the tap. 9.6.8 Refit the piezo generator. 9.7 To remove an injector. 9.7.1 Remove the fascia as section 9.2. 9.7.2 Release the pipe compression fitting to the upper or lower injector as required. Lock the injector with a second spanner to ensure that it does not move. 9.7.3 Loosen the pipe compression fitting at the tap end and move the pipe clear.
