LongReach
Scanner
ASP Microcomputers
456 North Road,
Ormond, Victoria, 3204
Australia
Telephone: (03) 9578-7600
FAX: (03) 9578-7727
email: solutions@asp.com.au
WWW: http://www.asp.com.au
(ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729)
th
Manual revised: August 6
, 2002
Copyright © 2001-2002 by ASP Microcomputers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LongReach and is the answer not in the manual?

Questions and answers

Related Manuals for ASP LongReach

Summary of Contents for ASP LongReach

  • Page 1 Ormond, Victoria, 3204 Australia Telephone: (03) 9578-7600 FAX: (03) 9578-7727 email: solutions@asp.com.au WWW: http://www.asp.com.au (ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729) Manual revised: August 6 , 2002 Copyright © 2001-2002 by ASP Microcomputers...

  • Page 3: Table Of Contents

    Contents The LongReach scanner .................1 Barcode Symbologies ................2 Host Interfaces..................2 PC Keyboard Wedge..............3 Wand Emulation ................3 Apple Macintosh ................4 RS-232 Output ................4 RS-232 Serial Wedge..............4 Standard LongReach Configurations............5 Standard Wand Emulation Setup ..........6 Standard PC Keyboard Wedge Setup..........7 Standard USB Setup..............8 Standard Apple Macintosh Setup..........9...

  • Page 5: The Longreach Scanner

    LongReach scanner The LongReach scanner ASP's LongReach scanner is a compact high-performance hand-held CCD barcode scanner suitable for reading barcodes from 5cm to 20cm away. The LongReach scanner has a yellow push button switch positioned right where your index finger comfortably sits when the scanner is held in your hand.

  • Page 6: Barcode Symbologies

    Scanning nicely printed barcode labels is simple, and most decoders can easily read well-printed labels. But because there are so many poorly printed barcode labels in the real world, the LongReach scanner has been designed to handle printing tolerances of up to ± 200% to help it to read virtually any barcode label, even if it’s badly printed.

  • Page 7: Pc Keyboard Wedge

    Turn the computer on, and the LongReach scanner will emit a high/low beep to indicate that it has passed its power-on diagnostic tests.

  • Page 8: Apple Macintosh

    In this way, all of your existing programs automatically accept barcode input. To connect the LongReach scanner, unplug the Mac from mains power, then unplug the mouse from the keyboard. Plug the adaptor’s male connector (the one with the pins) into the socket that the mouse used to plug into, then plug the mouse into the other socket on the adaptor cable, effectively interposing the adaptor between the two.

  • Page 9: Standard Longreach Configurations

    The Serial Wedge is designed to suit video terminals fitted with a female D25 connector (this is the usual case). If your video terminal instead uses a D25 male connector, you should contact ASP for advice. Switch off the terminal, then unplug the RS-232 cable from the host computer from the back of the video terminal, and plug it into the serial wedge cable.

  • Page 10: Standard Wand Emulation Setup

    LongReach scanner Standard Wand Emulation Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 11: Standard Pc Keyboard Wedge Setup

    LongReach scanner Standard PC Keyboard Wedge Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 12: Standard Usb Setup

    LongReach scanner Standard USB Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 13: Standard Apple Macintosh Setup

    LongReach scanner Standard Apple Macintosh Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 14: Standard Rs-232 Setup

    LongReach scanner Standard RS-232 Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 15: Standard Rs-232 Serial Wedge Setup

    LongReach scanner Standard RS-232 Serial Wedge Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 16: Notebook Type 10 Setup

    LongReach scanner Notebook Type 10 Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 17: Notebook Type 13 Setup

    LongReach scanner Notebook Type 13 Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 18: Notebook Type 14 Setup

    LongReach scanner Notebook Type 14 Setup You must scan the barcodes below in the numerical order shown. Note, however, that you won’t normally need to scan these setup barcodes – your scanner will normally have been supplied already set up for you.

  • Page 19: Miscellaneous Options

    LongReach scanner Miscellaneous Options The final section of this manual contains the setup barcodes for a number of the more common options, such as setting the baud rate, the beeper and trigger modes, the termination character, and ISBN (SCIS) mode.

  • Page 20: Beeper Mode Setup

    LongReach scanner Beeper Mode Setup To set the beeper mode, scan the PROGRAM barcode on the left below, then the BEEPER TONE barcode, then one of the option barcodes on the right, then the END barcode on the left. PROGRAM...

  • Page 21: Trigger Mode Setup

    LongReach scanner Trigger Mode Setup To set the trigger mode, scan all the barcodes in one or the other of the columns below. Scan all the barcodes in the left column, Use Trigger, to operate the scanner in the normal mode, where you need to press the trigger to scan a barcode.

  • Page 22: Isbn (Scis) Conversion

    LongReach scanner ISBN (SCIS) Conversion LongReach scanner can be set to convert EAN-13 barcodes that start with “978” into ISBN numbers, as required by the SCIS system, or to leave them as EAN-13 codes. First, scan the PROGRAM barcode on the left below, then the EAN/CAN/JAN SETTING barcode, then one of the ISBN barcodes on the right, and finally the END barcode on the left.

  • Page 23: Terminators For Rs-232 And Serial Wedge Only

    LongReach scanner Terminators for RS-232 and Serial Wedge Only LongReach scanner To set the terminator character when the is set to RS- 232 or RS-232 Serial Wedge mode, scan the PROGRAM barcode on the left below, then RS-232 TERMINATOR barcode, then one of the terminator barcodes on the right, then the END barcode on the left.

  • Page 24: Output Delays For Pc Keyboard Wedge & Notebooks

    LongReach scanner Output Delays for PC Keyboard Wedge & Notebooks LongReach scanner To set delays between each character output by the when operating in PC Keyboard Wedge or Notebook mode, scan the PROGRAM barcode on the left below, then the INTERCHARACTER DELAY barcode, then two numeric digits (01 to 99 in milliseconds) from the barcodes on the right, then finally the END barcode on the left.

  • Page 25: Symbology Setup

    LongReach scanner Symbology Setup In some situations, you may wish to restrict the barcode symbologies (or barcode types) that the scanner will read. To do so, scan the PROGRAM barcode on the left below, then the SYMBOLOGY barcode, then scan a two- digit sequence from the right column for each symbology to be enabled (see the table on the left below), then finally scan the END barcode on the left.

  • Page 26: Electromagnetic Interference

    ASP. Units sent freight collect will not be accepted. Freight back to you will be paid by ASP in the case of warranty repairs. ASP welcomes suggestions for improvements to our products and...
