Zapper
TM
Only for Black Zappers with serial numbers
between Z22000 and Z2999
ASP Microcomputers
14 Business Park Drive,
Notting Hill, Victoria, 3168
Australia
Phone: (03) 9578-7600
FAX: (03) 9578-7727
solutions@asp.com.au
http://www.asp.com.au
ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729
Barcode Zapper is a trademark of ASP Microcomputers
Manual revised November 19th, 2020
Copyright © 1998-2020 by ASP Microcomputers
Only for Black Zappers with serial numbers between Z22000 and Z29999
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ASP Zapper Z22000
Summary of Contents for ASP Zapper Z22000
- Page 1 Phone: (03) 9578-7600 FAX: (03) 9578-7727 solutions@asp.com.au http://www.asp.com.au ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729 Barcode Zapper is a trademark of ASP Microcomputers Manual revised November 19th, 2020 Copyright © 1998-2020 by ASP Microcomputers...
-
Page 3: Table Of Contents
Contents The ASP Barcode Zapper ................ 1 Barcode Symbologies ................2 Host Interfaces ..................2 USB ..................... 2 PC Keyboard Wedge ................3 RS-232 Output ..................3 Standard Configurations ................4 USB ..................... 5 PC Keyboard Wedge ................6 RS-232 ....................7 Miscellaneous Options ................ -
Page 5: The Asp Barcode Zapper
Barcode Zapper The ASP Barcode Zapper ASP's Barcode Zapper is a compact high-performance hand-held barcode scanner suitable for reading barcodes of up to 10cm wide, from contact to 9cm away. The Barcode Zapper has push button switches on both sides,... -
Page 6: Barcode Symbologies
One cable is supplied with each ASP Barcode Zapper; and additional adaptor cables are available as optional extras. Adaptor cables can be removed by pushing the end of a paper clip into the hole near the base of the Barcode Zapper, and then carefully pulling the connector out. -
Page 7: Pc Keyboard Wedge
The RS-232 interface outputs decoded barcode scans using ASCII codes and the RS-232 standard. The RS-232 interface is compatible with ASP's ASPKey software, allowing RS-232 output to be accepted from the serial port and placed directly in the keyboard buffer of IBM PC compatible computers. -
Page 8: Standard Configurations
If you have any special scanning requirements, it’s likely that the Barcode Zapper can be configured to suit, so please contact ASP or your dealer to discuss your needs. -
Page 9: Usb
Barcode Zapper You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH USB KEYBOARD DEFAULTS PROGRAM HOST INTERFACE SELECTION CODE 25 MIN LENGTH... -
Page 10: Pc Keyboard Wedge
Barcode Zapper PC Keyboard Wedge You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH PROGRAM HOST INTERFACE SELECTION CODE 25 MIN LENGTH... - Page 11 Barcode Zapper RS-232 You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH PROGRAM HOST INTERFACE SELECTION CODE 25 MIN LENGTH...
-
Page 12: Miscellaneous Options
Barcode Zapper Miscellaneous Options The final section of this manual contains the setup barcodes for a number of the more common options, such as setting the baud rate, the beeper and trigger modes, the termination character, and ISBN (SCIS) mode. Remember that you shouldn’t need to scan any of these setup barcodes –... -
Page 13: Scis
Barcode Zapper Most likely, you will only need to scan ISBN codes for use with SCIS. SCIS say that they now allow either ISBN-10 and ISBN-13 codes to be used, so it really doesn't matter if your scanner outputs the 10 digit code or the 13 digit code when the ISBN barcode is scanned. -
Page 14: Beeper Mode
Barcode Zapper Beeper Mode To set the beeper mode, scan the PROGRAM barcode on the left below, then the BEEPER TONE barcode, then one of the option barcodes on the right, then the END barcode on the left. PROGRAM No Beep BEEPER TONE Low Pitch Medium Pitch... -
Page 15: Blue Power Indicator
Barcode Zapper Blue Power Indicator Normally, the blue power indicator light is lit whenever the Barcode Zapper is plugged in. However, if the glow isn’t to your liking, or you want to reduce the Zapper’s power requirements in a battery-powered application, scan the barcodes below to turn it off or on. -
Page 16: Output Delays For Pc Keyboard Wedge Only
Barcode Zapper Output Delays for PC Keyboard Wedge only To set delays between each character output by the Barcode Zapper when operating in PC Keyboard Wedge mode, scan the PROGRAM barcode on the left below, then the INTERCHARACTER DELAY barcode, then two numeric digits (01 to 99 in milliseconds) from the barcodes on the right, then finally the END barcode on the left. -
Page 17: Output Terminators For Pc And Usb Only
Barcode Zapper Output Terminators for PC and USB only To set the terminator character when the Barcode Zapper is set to PC Keyboard Wedge or USB modes, scan the PROGRAM barcode on the left below, then KEYBOARD TERMINATOR barcode, then one of the terminator barcodes on the right, then the END barcode on the left. -
Page 18: Rs-232 Baud Rate
Barcode Zapper RS-232 Baud Rate To set the baud rate, scan the PROGRAM barcode on the left below, then the SET BAUD RATE barcode, then one of the baud rate barcodes on the right, then the END barcode on the left. PROGRAM 38400 baud SET BAUD RATE... -
Page 19: Output Terminators For Rs-232 Only
Barcode Zapper Output Terminators for RS-232 Only To set the terminator character when the Barcode Zapper is set to RS-232 mode, scan the PROGRAM barcode on the left below, then RS-232 TERMINATOR barcode, then one of the terminator barcodes on the right, then the END barcode on the left. PROGRAM NONE RS-232 TERMINATOR... -
Page 20: Electromagnetic Interference (Emc)
ASP. Units sent freight collect will not be accepted. Freight back to you will be paid by ASP in the case of warranty repairs. ASP always welcomes suggestions for improvements to our products...
