ASP Z4 DataTraq User Manual

Portable barcode reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Z4 DataTraq
Portable
Barcode Reader
The Z4 DataTraq is designed and built in Australia by:
ASP Microcomputers
456 North Road,
Ormond, Victoria, 3204
Australia
Telephone: (03) 9578-7600
FAX: (03) 9578-7727
email: solutions@asp.com.au
World Wide Web: http://www.asp.com.au
(ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729)
th
Manual revised: August 8
, 2000
Copyright © 2000 by ASP Microcomputers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z4 DataTraq and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASP Z4 DataTraq

Summary of Contents for ASP Z4 DataTraq

  • Page 1 Ormond, Victoria, 3204 Australia Telephone: (03) 9578-7600 FAX: (03) 9578-7727 email: solutions@asp.com.au World Wide Web: http://www.asp.com.au (ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729) Manual revised: August 8 , 2000 Copyright © 2000 by ASP Microcomputers...

  • Page 3: Table Of Contents

    Barcode Types ..................16 ASCII Character Code Chart .............. 17 Warranty ..................... 18 Year 2000 Statement ................18 EMC Statement The Z4 DataTraq has been tested for compliance with the following standards: FCC Part 15, Subpart B, Class A. Australia Australian Standard AS3548:1993.

  • Page 5: Meet The Z4 Datatraq

    ASP’s friendly support staff. Here are some of the features of the Z4 DataTraq: 2 products in 1 The Z4 DataTraq functions as both a battery powered Portable Barcode Reader and a fixed reader, giving you two products for the price of one.

  • Page 6: Quick Start: Pc Keyboard Connection

    – the green light labelled HOMEBASE CHARGE on the front of the Homebase should now be lit. 6. Plug your wand or scanner into the connector on the Z4 DataTraq labeled WAND 7. Turn your PC back on. 8. Turn on your Z4 DataTraq and start scanning barcodes!

  • Page 7: Quick Start: Rs-232 Y Cable Connection

    – the green light labelled HOMEBASE CHARGE on the front of the Homebase should now be lit. 6. Plug your wand or scanner into the connector on the Z4 DataTraq labeled WAND 7. Turn on your Z4 DataTraq and start scanning barcodes!

  • Page 8: Using The Wand

    Start with the wand tip in the white space at either end of the barcode, about a centimetre from the first bar. The Z4 DataTraq is able to read barcodes whether they are scanned left to right or right to left. The ideal scan path is indicated on the left below.
  • Page 9 • The use of a protective covering, such as “invisible” sticky tape or clear Contact, will prolong the useful life of a barcode label. The Z4 DataTraq has been designed to provide a high first read rate when a good symbol is scanned. A low first read rate is normally caused by either a damaged barcode symbol or improper operation of the system by the operator.

  • Page 10: The Keypad

    The shift keys operate differently to those on a computer keyboard or typewriter – on the Z4 DataTraq, you press a shift key once and released it, then press the required key. The keyboard then returns to the normal unshifted state.

  • Page 11: Use Of The Comma Key

    Editing Data Because editing data on a two-line display would be impractical, the Z4 DataTraq does not provide editing facilities for data stored in memory. If an entry is are made on the keypad but has not been pressed,...

  • Page 12: Configuration Functions

    Z4 DataTraq's battery-backed memory, and remain in effect even if the power is turned off. As delivered, the Z4 DataTraq may not be set up correctly for your computer or software, so you should check the suitability of settings when you first receive your unit, and configure it as required.
  • Page 13 Downloads stored barcode reads one at a time when the enter key is pressed Rewinds memory for use with Function 12 to go back to the first data stored in memory Lists stored data on the Z4 DataTraq’s display Press the numeric keys to list the data more slowly (higher numbers) or more quickly (lower numbers).

  • Page 14: Care Of Your Z4 Datatraq

    Printing Barcode Labels If you need to print your own sheets of barcode labels, ASP can also supply our Label+ barcode label printing program, which allows sheets of UPC/EAN, Code 39, Code 128, Code 93, Codabar and ITF labels to be printed on any Microsoft Windows compatible printer.

  • Page 15: What Do I Do If

    The display says “memory is full” You’ll probably see this message if you normally use your unit as a fixed reader. The Z4 DataTraq is designed to both output the barcodes that you scan, and to store them in memory.

  • Page 16: Batteries

    The Z4 DataTraq is powered by rechargeable Nicad batteries, and data stored in memory is maintained by a separate lithium power cell. When you first receive your Z4 DataTraq, the batteries may not be fully charged, so we suggest that you connect it to its Homebase and leave it to charge overnight before using it.

  • Page 17: Technical Information

    Z4 DataTraq Technical Information Wand Connector Signals The wand connector used on all ASP Barcode Readers is a 9 pin male sub-miniature D connector. The pinout of the wand connector is as follows: Function Digital Wand Input (black = high, white = low, idle = high)
  • Page 18 Data Traq. This is sometimes called RS-232 Wedge operation. A special cable, called a ‘Y’ cable, is required for this method of operation, and a suitable cable can be ordered from Asp or your dealer, or can be made up as described below.
  • Page 19 RS-232 Handshaking The video terminal or computer to which the Z4 DataTraq is connected may not be able to accept data at all times. The Z4 DataTraq always checks the CTS signal (Clear To Send, pin 4) before sending any data, and if the CTS signal is turned off, the BCR will not transmit the data.

  • Page 20: Barcode Types

    Z4 DataTraq Barcode Types Product Codes - UPC, EAN and APN UPC (Universal Product Code), EAN (European Article Number) and APN (Australian Product Number) codes are compatible article numbering systems used for consumer products sold in retail outlets. Product codes are numeric only, and are assigned to manufacturers by a national organisation.

  • Page 21: Ascii Character Code Chart

    095 = _ 127 = DEL When the IBM AT or PS/2 keyboard interface is selected, the Z4 DataTraq is able to output the codes for special keys using the character numbers detailed below: 129 = F1 130 = F2...

  • Page 22: Warranty

    ASP to arrange for the firmware to be updated. If your Z4 DataTraq is loaded with a custom program, you will have to contact the programmer to determine the year 2000 status of the custom program.
