ASP zapper User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Zapper
TM
Only for Black Zappers with
serial numbers lower than Z22000
ASP Microcomputers
456 North Road,
Ormond, Victoria, 3204
Australia
Telephone: (03) 9578-7600
FAX: (03) 9578-7727
solutions@asp.com.au
http://www.asp.com.au
ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729
Barcode Zapper is a trademark of ASP Microcomputers
th
Manual revised: February 28
, 2013
Copyright © 1998-2013 by ASP Microcomputers
Only for Black Zappers with serial numbers lower than Z22000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the zapper and is the answer not in the manual?

Questions and answers

Related Manuals for ASP zapper

Summary of Contents for ASP zapper

  • Page 1 Telephone: (03) 9578-7600 FAX: (03) 9578-7727 solutions@asp.com.au http://www.asp.com.au ASP Microcomputers is a division of Grayline Holdings Pty. Ltd,. A.C.N. 004 940 729 Barcode Zapper is a trademark of ASP Microcomputers Manual revised: February 28 , 2013 Copyright © 1998-2013 by ASP Microcomputers...

  • Page 3: Table Of Contents

    Contents The ASP Barcode Zapper ................ 1 Barcode Symbologies ................2 Host Interfaces ..................2 USB ..................... 3 PC Keyboard Wedge ................3 Wand Emulation ................. 4 RS-232 Output ..................4 Standard Configurations ................5 USB ..................... 6 PC Keyboard Wedge ................7 Wand Emulation .................

  • Page 5: The Asp Barcode Zapper

    “good read” indicator, and beep to signal a successful read. The Barcode Zapper has been pre-programmed to read most barcode types you are likely to encounter. For special requirements, please contact ASP or your dealer.

  • Page 6: Barcode Symbologies

    Scanning nicely printed barcode labels is simple, and most scanners can easily read well-printed labels. But because there are so many poorly printed barcode labels in the real world, the Barcode Zapper has been designed to handle printing tolerances of up to ± 200% to help it to read virtually any barcode label, even if it’s badly printed.

  • Page 7: Usb

    Barcode scans simply appear as if typed on the keyboard. To install the USB interface Barcode Zapper, all you need to do is plug it into any USB connector on your computer. The USB port provides all the power required for the Barcode Zapper.

  • Page 8: Wand Emulation

    The Wand Emulation interface uses a female D9 connector, with wand data on pin 2, ground on pin 7 and +5v on pin 9. The Barcode Zapper is a low power scanner, ideally suited to portable applications. RS-232 Output The RS-232 interface outputs decoded barcode scans using ASCII codes and the RS-232 standard.

  • Page 9: Standard Configurations

    To set up your Barcode Zapper unit, turn to the relevant page for the interface type you require, and scan the setup barcodes on that page, taking care to scan them in the numerical order shown.

  • Page 10: Usb

    Barcode Zapper You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH USB KEYBOARD DEFAULTS PROGRAM CODE 25 MIN LENGTH HOST INTERFACE SELECTION...

  • Page 11: Pc Keyboard Wedge

    Barcode Zapper PC Keyboard Wedge You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH KEYBOARD WEDGE DEFAULTS PROGRAM HOST INTERFACE SELECTION CODE 25 MIN LENGTH...

  • Page 12: Wand Emulation

    Barcode Zapper Wand Emulation You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CCD/LASER OP. MODE WAND EMULATION DEFAULTS 0 (LOW POWER MODE) PROGRAM POWER INDICATOR HOST INTERFACE SELECTION...
  • Page 13 Barcode Zapper RS-232 You must scan the barcodes below in the numerical order shown, and the scanner must beep after every barcode. MASTER DEFAULT CODE 39 MIN LENGTH SERIAL COMMS DEFAULTS PROGRAM HOST INTERFACE SELECTION CODE 25 MIN LENGTH...

  • Page 14: Miscellaneous Options

    ISBN (SCIS) mode. Remember that you shouldn’t need to scan any of these setup barcodes – your Barcode Zapper will normally have been supplied already set up correctly for you. RS-232 Baud Rate...

  • Page 15: Beeper Mode

    Barcode Zapper Beeper Mode To set the beeper mode, scan the PROGRAM barcode on the left below, then the BEEPER TONE barcode, then one of the option barcodes on the right, then the END barcode on the left. PROGRAM No Beep...

  • Page 16: Blue Power Indicator

    Blue Power Indicator Normally, the blue power indicator light is lit whenever the Barcode Zapper is plugged in. However, if the glow isn’t to your liking, or you want to reduce the Zapper’s power requirements in a battery-powered application, scan the barcodes below to turn it off or on.

  • Page 17: Output Terminators For Pc And Usb

    Barcode Zapper Output Terminators for PC and USB To set the terminator character when the Barcode Zapper is set to PC Keyboard Wedge, Notebook, or USB modes, scan the PROGRAM barcode on the left below, then KEYBOARD TERMINATOR barcode, then one of the terminator barcodes on the right, then the END barcode on the left.

  • Page 18: Terminators For Rs-232 Only

    Barcode Zapper Terminators for RS-232 Only To set the terminator character when the Barcode Zapper is set to RS-232 or RS-232 Serial Wedge mode, scan the PROGRAM barcode on the left below, then RS-232 TERMINATOR barcode, then one of the terminator barcodes on the right, then the END barcode on the left.

  • Page 19: Output Delays For Pc Keyboard Wedge & Notebooks

    Barcode Zapper Output Delays for PC Keyboard Wedge & Notebooks To set delays between each character output by the Barcode Zapper when operating in PC Keyboard Wedge or Notebook mode, scan the PROGRAM barcode on the left below, then the...

  • Page 20: Isbn-10 And Isbn-13

    13 digit ISBN-13 code, and a 10 digit ISBN-10 code that is derived from the full 13 digit barcode number. The Barcode Zapper, by default, outputs the 13 digit number at the bottom of an ISBN barcode. If ISBN (or SCIS) mode is turned on...

  • Page 21: Scis

    Barcode Zapper If you're still reading, you're probably thinking "why did they bother changing if ISBN-10 and ISBN-13 are really the same thing?". The answer is that sometime in the future, ISBN-13 barcodes that start with "979" (as shown on the right) will be released, and these codes do not have a 10 digit equivalent - they are 13 digit only.

  • Page 22: Electromagnetic Interference (Emc)

    ASP. Units sent freight collect will not be accepted. Freight back to you will be paid by ASP in the case of warranty repairs. ASP always welcomes suggestions for improvements to our products...
