02. INTRODUCTION

Your B200 evaporative humidifier adds invisible mois-
ture to your home by moving dry inlet air through a
saturated wick. As air moves through the wick, the
water evaporates into the air, leaving behind any
white dust, minerals, or dissolved and suspended so-
lids. Because the water is evaporated, there is just
clean and invisible moist air. As the evaporative wick
traps accumulated minerals from the water, its ability
to absorb and evaporate water decreases. We recom-
mend changing the wick at the beginning of every
season. In hard water areas, more frequent replace-
ment may be necessary to maintain your humidifier's
efficiency.
Use only Trotec brand replacement wicks and che-
micals. To order parts, wicks and chemicals call +49
2452-962-200.
The B 200 humidifiers use Modell 1045. Only the B
200 evaporative wick guarantees the certified out-
put of your humidifier. Use of wicks other than Trotec
brand will void your warranty as well as the certifi-
cation of output and may reduce the output of your
humidifier.
Dry air is drawn into the humidifier through the back
and moisturized as it passes through the evaporative
wick. It is then fanned out into the room.
CAUTION: Do NOT position the unit directly in front
of a hot air duct or radiator. Do NOT place on soft
carpet.
1. Water bottle
2. Chassis/Power Pack (motor and fan assembly)
3. Evaporative wick
4. Water reservoir
5. Dry room air intake
6. Moist air output
03. ASSEMBLY, CONTROLS & OPERATION
1. Remove the two polyfoam inserts from the top of
the humidifier.
2. Lift off the water bottle cover (left-hand side). Re
move the water bottle, lift off the chassis/power
pack and then remove the humidifier cabinet from
the carton.
3. Remove the evaporative wick, float assembly (black
rod with white float), and all of the remaining pa-
ckaging materials from the cabinet. Check to see
that you have all of the following items removed
from the boxes accessory kit and cabinet before
discarding the packaging:
• Filler hose
• Caster kit
• Bacterial treatment sample
• Water bottle with cap
• Optional AirCare Filter (purchased separately)
Operating manual – Humidifier B 200
B - 2
