Interface Data; Rs 232 Instruction Set - ALGE-Timing Timy Manual

2.2.1

Interface data

RS 232 Interface
Standard 38.400 Baud (adjustable: 2400, 4800, 9600, 19200, 38400)
8 Data Bit, no Parity Bit, 1 Stop Bit
ASCII signs
2.2.2

RS 232 instruction set

Syntax Parameter
BE 0 or 1
BWF
USB-TIMY :BWF !! !!
DIT1 00 – 99
DIT2 00 – 99
DTF 00.01 – 59.99
DTS 00.01 – 59.99
KL 0 or 1
NSF ?
PRI_AF 0 – 9
PRI O or 1
PRILF
PRILU
PRIM
RSM
SL 0 or 1
TIMY INIT
Page 6
Timy
Terminal
Example
BE0 BE1 BE? Beep
BWF Update of program – RS232
USB-TIMY:BWF !! !! Update of program – USB
DIT103 DIT1 ? Display time 1 in display
DIT299 DIT2 ? Display time 2 in display
Dead time for finish and interm.
DTF00.03 DTF ?
Time
DTS09.99 DTS? Dead time for start
KL0 KL1 KL? Keyboard interlock
NSF? Timy version of program
PRI_AF3 Line feed adjustment for printer
PRI0 PRI1 Switch-on/off of printer
RPILF Line feed for printer
PRIL0 Print of ALGE-logo
PRIM Prints storage
RSM Send storage via RS232
SL0 LS1 SL? Print of ALGE-logo (switch-on)
Output of TIMY hardware
TIMY INIT
serial-number
Explanation Description
Inquiery
Afterwards update-file
Afterwards update-file
Inquiery, command
Inquiery, command
Inquiery, command
Inquiery, command
Inquierey, on/off
Sends NSFV03B2
Printer AutoLineFeed 0
– 9
Inquiery, on/off
Command
Command
Prints storage
Storage on RS232
Inquiery, on/off
Not specified
