Summary of Contents for Gree CROWN09HP230V1A

Page 1 HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER’S MANUAL Models: CROWN09HP230V1A CROWN12HP230V1A CROWN18HP230V1A...
Page 2: Table Of Contents
& Heating System! You can feel confident in your selection because the same pride in craftsmanship and engineering knowledge that goes into millions of other Gree installed products worldwide has gone into your unit. Please read this owner’s manual carefully before operation and retain it for future reference.
Page 3: Introduction
Crown system even more versatile, for year-round comfort. Flexibility, intelligent design and Gree innovation make the Crown your best choice for creating ideal climate conditions. The Crown series is WiFi enabled. It allows you to monitor and change settings through on-screen virtual controls from smart phones or tablets with Gree-Smart App.
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read the following before operation. Recognize safety information. This is the safety-alert symbol. When you see this symbol on the unit and in instructions or manuals, be alert to the potential for personal injury. Understand these signal words: DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol.
Page 5 • Disconnect electrical power to the indoor and outdoor units before performing any maintenance or cleaning. • Do not attempt to repair the Gree system yourself. Incorrect repairs may cause electric shock or fire. Contact a qualified service technician for all service requirements.
Page 6: Part Names
PART NAMES Air inlet Indoor unit Air outlet Part Name 1. Front Panel 2. Aux. Button 3. Filter 4. Remote Controller 5. Inter-Connection Wire 6. Drain Hose 7. Refrigerant Lines Air inlet Outdoor unit Air outlet...
Page 7: System Functions
SYSTEM FUNCTIONS WHISPER QUIET Not only are the Gree systems energy efficient but they are quiet too. Crown High-Wall units operate with sound pressure levels starting as low as 22 dB(A). MULTI FAN SPEEDS Whether operating in either Cooling or Heating mode, the indoor fan can be set to your choice of seven different speeds (Ultra-Low, Low, Low-Medium, Medium, Medium-High, High or Turbo) to achieve maximum comfort.
Page 8 SYSTEM FUNCTIONS MODE BUTTON The unit can be set to five different operating modes: HEAT, COOL, DRY, FAN ONLY and AUTO. NOTE: AUTO MODE has fixed setpoints of 68° F heating and 78° F cooling, which are not adjustable.The system will automatically select heating or cooling to maintain room temperature within this band.
Page 9: Operation Of Wireless Remote Controller
OPERATION OF WIRELESS REMOTE CONTROLLER REMOTE CONTROLLER Part Name 1. ON/OFF Button 2. +/- Button 3. Cool Button 4. Heat Button 5. Fan Button 6. I Feel Button 7. Up & Down Swing Button 8. Mode Button 9. Timer-On Button 10.
Page 10 OPERATION OF WIRELESS REMOTE CONTROLLER MATCHING INSTRUCTIONS The Crown models require the wireless remote controller to be matched to the indoor wall unit before beginning any operations, otherwise the Crown indoor wall unit will not accept commands from the remote controller. Follow the instructions below to automatically match the remote controller to the Crown indoor wall unit: 1.
Page 11 OPERATION OF WIRELESS REMOTE CONTROLLER LOCK MODE The Privacy Lock prevents unauthorized access to the unit controls and prevents tampering with system settings. The remote controller can be locked by pushing the"+"and "-" buttons simultaneously for 5 seconds. The Privacy Lock icon will be displayed on the remote controller.
Page 12 OPERATION OF WIRELESS REMOTE CONTROLLER VERTICAL SWING LOUVERS • Press the Vertical Swing Louver button to select five different vertical (up & down) air discharge directions including Continuous Sweep.The Swing Louver icon will be displayed. Press this button to set swing angle, which changes in direction as below: Vertical Louver Display Indicates louver swings back and forth in the five directions, as shown.
Page 13 OPERATION OF WIRELESS REMOTE CONTROLLER TRADITIONAL MODE - SLEEP 1 In Traditional Mode the unit will slowly relax the room set temperature by up to 4° F until Sleep Mode is cancelled. Cooling Mode Heating Mode EXPERT MODE - SLEEP 2 In Expert Mode the unit will adjust the room set temperature at a rate based on the starting set temperature value.
Page 14 OPERATION OF WIRELESS REMOTE CONTROLLER NOTE: During this procedure, if no button is pressed within 10 seconds, remote controller will automatically exit the sleep curve setting and resume original display. If ON/OFF, MODE, TIMER, SLEEP, COOLING or HEATING button is pressed during the setting or inquiry procedure, remote controller will also exit the sleep curve setting.
Page 15 OPERATION OF WIRELESS REMOTE CONTROLLER X-FAN MODE When operating in humid areas, the unit has a DRY COIL function called X-Fan that will allow the indoor fan to run for a pre-determined amount of time after the unit is turned off (cooling or dry modes) to ensure that additional moisture is removed from coil.
Page 16 OPERATION OF WIRELESS REMOTE CONTROLLER TIMER SETTING T-OFF button (Timer OFF) To set when you want the unit to turn Off at the end of a selected time period, use the button labeled “T-OFF” on the remote controller. Press this button to make the clock icon disappear, replaced with the word “OFF”...
Page 17 OPERATION OF WIRELESS REMOTE CONTROLLER CHANGING BATTERIES AND ADDITIONAL NOTES To change batteries, slide cover off battery compartment on back of remote controller. Remove and safely discard old batteries. Insert two new AAA 1.5V dry batteries, using correct polarity. Reattach back cover. NOTE: •...
Page 18: Operation Of Smart Control
Refer to application program for the specific version. STEP 1. Download and install Gree-Smart App on your smart phone METHOD 1: Go to www.gree.com/english/downloadcenter/ihome_jsp_catid_2840.shtml. In the "Download Center,” follow instructions to download the “G-Life”...
Page 19 OPERATION OF SMART CONTROL STEP 5. Get started Open the application software and click “Refresh.” The system will automatically link with the Crown unit. Touch “ ” to turn On the smart control function. STEP 6. Set custom network name and password Slide the bottom function bar to the left.
Page 20 OPERATION OF SMART CONTROL COMMON NETWORK SETTING PROBLEMS If local WiFi control fails, check the following items one by one: Make sure electrical power is turned on to the outdoor and indoor units. • Make sure WiFi function is turned On as normal •...
Page 21 OPERATION OF SMART CONTROL SOFTWARE FUNCTIONS Timer On/Off: Set the Timer On or Off function by selecting the Preset icon. Then move the slider to the right to select either Timer On or Off. Scroll to the desired time period and press Save. See Remote Controller instructions for more details.
Page 22: Operation Of Smart Control
OPERATION OF SMART CONTROL Regional Swing: Press“Air flow position”button to adjust the fan coverage of a specific room area. Control this by moving the air conditioner icon left or right. You can then move the person icon among nine pane areas. The Regional Swing function can be turned off through up/down swing.
Page 23: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE/SOLUTION System does not restart. Cause: The system has a built-in three-minute delay to prevent short and/or rapid cycling of the compressor. Solution: Wait three minutes for the protection delay to expire. Indoor unit emits unpleasant odor Cause: Typically unpleasant odors are the result of mold or mildew forming on when started the coil surfaces or the air filter.
Page 24: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE/SOLUTION Water leaking from the indoor Cause: While it is normal for the system to generate condensate water in cooling unit into the room. mode, it is designed to drain this water via a condensate drain system to a safe location. Solution: If water is leaking into the room, it may indicate one of the following.
Page 25: Care And Cleaning
CARE AND CLEANING WARNING CAUTION W RNING WARNING Take notice of the following items before cleaning your Crown indoor wall unit. • To avoid electric shock or injury, do not attempt to clean the unit unless it has been turned off and the indoor and outdoor units have been disconnected from the main power supply.
Page 26: Energy Saving Tips
ENERGY SAVING TIPS 1. Reduce room setpoint at night: During the nighttime hours you don't require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2.
Page 27: Limited Warranty
LIMITED WARRANTY GREE distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows.All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture.
Page 28 66129916954...
