- Page 1 KVM Switch KH1508 / KH1516 User Manual www.aten.com...
-
Page 2: Fcc Information
KH1508 / KH1516 User Manual FCC Information This is an FCC Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: User Information
KH1508 / KH1516 User Manual User Information Online Registration Be sure to register your product at our online support center: International http://support.aten.com North America http://www.aten-usa.com/product_registration Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-10-5255-0110 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988... -
Page 4: Package Contents
Copyright © 2013 ATEN® International Co., Ltd. Manual Part No. PAPE-0268-AX4G Manual Date: 2013-01-30 Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners. -
Page 5: Table Of Contents
KH1508 / KH1516 User Manual Contents FCC Information ..........ii RoHS. - Page 6 KH1508 / KH1516 User Manual Chapter 3. Basic Operation Port Selection ..........19 Manual .
- Page 7 KH1508 / KH1516 User Manual Setting the Hotkey Beeper ON/OFF ......45 Setting the Hotkey key combination .
-
Page 8: About This Manual
KH1508 / KH1516 User Manual About This Manual This User Manual is provided to help you get the most from your KH1508 KH1516 system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. -
Page 9: Conventions
For information about all ALTUSEN products and how they can help you connect without limits, visit ALTUSEN on the Web or contact an ALTUSEN Authorized Reseller. Visit ALTUSEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... - Page 10 KH1508 / KH1516 User Manual This Page Intentionally Left Blank...
-
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Overview A KH1508 or KH1516 KVM switch is a control unit that allows IT administrators to access and control multiple computers from a single PS/2 or USB KVM (keyboard, monitor, and mouse) console. A single KH1508 KH1516 can control up to 8 / 16 computers. -
Page 12: Features And Benefits
KH1508 / KH1516 User Manual Features and Benefits The features and benefits provided by a KH1508 / KH1516 deployment are described in the following table: Features Benefits Simple Installation and Plug-and-play installation – no software required – connecting Operation cables is all it takes. Station positions are automatically recognized. - Page 13 Chapter 1. Introduction Features Benefits Upgradeable Firmware Stay current with the latest functionality improvements and updates by downloading firmware upgrade files from our website and installing them with the built-in firmware upgrade utility. Effortless Upgrades Simultaneous firmware upgrades to all daisy-chained KVM switches and dongles through the daisy-chain cable.
-
Page 14: Requirements
KH1508 / KH1516 User Manual Requirements Console A VGA, SVGA, or multisync monitor capable of the highest resolution that you will be using on any computer in the installation A PS/2 or USB mouse A PS/2 or USB keyboard Computers The following equipment must be installed on the computers that connect to the KH1508 or KH1516... -
Page 15: Kvm Adapter Cables
Chapter 1. Introduction KVM Adapter Cables Cat 5e/6 cable is required to connect the KH1508 / KH1516 to one of the KVM adapter cables. The following KVM adapter cables are required for use with the KH1508 KH1516 Function Module Connect to devices with PS/2 ports KA7920 / KA7520 / KA7120 KA9520 / KA9120 Connect to devices with USB ports... -
Page 16: Components
KH1508 / KH1516 User Manual Components Front View KH1508 1&2 KH1516 1&2... - Page 17 KH1508A / KH1516A (see page 51), plugs into this RJ-11 connector. Power LED Lights to indicate that the KH1508A / KH1516A is powered and ready to operate. Station ID The KH1508A / KH1516A's Station ID is displayed here. If this...
-
Page 18: Rear View
KH1508 / KH1516 User Manual Rear View KH1508 KH1516... - Page 19 Power Socket The power cord to the AC source plugs in here. Power Switch This is a standard rocker switch that powers the KH1508A / KH1516A on and off. Daisy Chain When daisy chaining units (see Daisy Chaining, page 17), Ports the daisy chain cables plug in here.
- Page 20 KH1508 / KH1516 User Manual This Page Intentionally Left Blank...
-
Page 21: Chapter 2. Hardware Setup
Chapter 2 Hardware Setup Overview For convenience and flexibility that allows mixing the PS/2, USB and serial interfaces, the KH1508 / KH1516 's design utilizes KVM adapter cables that serve as intermediaries between the KVM switch and the connected devices: A separate KVM adapter cable is required for each computer or device connection. -
Page 22: Stacking And Rack Mounting
KH1508 / KH1516 User Manual Stacking and Rack Mounting The KH1508 / KH1516 can be stacked on the desktop or rack mounted at the front or rear of the rack. The following sections take you through the procedures for each method. Note: 1. -
Page 23: Rack Mounting
Chapter 2. Hardware Setup Rack Mounting The KH1508 / KH1516 can be mounted in a 19" (1U) rack. The mounting brackets can screw into either the front or the back of the unit so that it can attach to the front or the back of the rack. To rack mount the unit: 1. -
Page 24: Single Station Installation
KH1508 / KH1516 User Manual Single Station Installation In a single stage installation, there are no additional KVM switches daisy chained down from the KH1508 / KH1516 . To set up a single stage installation, refer to the installation diagrams starting on page 15 (the numbers in the diagram correspond with the numbers of the instruction steps), and do the following: 1. -
Page 25: Single Stage Installation Diagram
Chapter 2. Hardware Setup Single Stage Installation Diagram... -
Page 26: Kvm Adapter Cable Installation Diagrams
KH1508 / KH1516 User Manual KVM Adapter Cable Installation Diagrams KA7120 KA7520 KA7920 KA9120 KA9520 KA7130 KA9130 KA7170 KA7570 KA7970 KA9170 KA9570 SERIAL TERMINAL KA9140... -
Page 27: Daisy Chaining
Chapter 2. Hardware Setup Daisy Chaining To control even more computers, up to 31 additional KH1508 / KH1516 KVM switches can be daisy chained from the original KH1508 or KH1516 As many as 512 computers can be controlled from a single console in a complete installation. - Page 28 KH1508 / KH1516 User Manual Daisy Chain Installation Diagram...
-
Page 29: Kh1508 A / Kh1516 A
Chapter 3 Basic Operation Port Selection KH1508 / KH1516 installations provide three methods to obtain instant access to any computer on your installation: Manual, OSD (on-screen display), and Hotkey. Manual Manual port selection simply involves pressing the port selection switch that corresponds to the device you wish to access. -
Page 30: Hot Plugging
KH1508 / KH1516 User Manual Hot Plugging The KH1508 / KH1516 supports hot plugging – components can be removed and added back into the installation by unplugging and replugging their cables without the need to shut the unit down. In order for hot plugging to work properly, however, the procedures described below should be followed. -
Page 31: Powering Off And Restarting
Chapter 3. Basic Operation Powering Off and Restarting If it becomes necessary to power off the KH1508 / KH1516 , or if the switch loses power and needs to be restarted, before starting it back up you should follow these procedures to prevent possible equipment issues: 1. - Page 32 KH1508 / KH1516 User Manual This Page Intentionally Left Blank...
-
Page 33: Chapter 4. Osd Operation
Chapter 4 OSD Operation OSD Overview The On Screen Display (OSD) is a menu driven method to handle computer control and switching operations. All procedures start from the OSD Main Screen. To display the Main Screen, tap the OSD hotkey twice. The default hotkey is [Scroll Lock]. - Page 34 KH1508 / KH1516 User Manual When you invoke the OSD, a screen similar to the one below appears: Note: 1. The diagram depicts the Administrator's Main Screen. The User Main Screen does not show the F4 and F6 functions, since these are reserved for the administrator and can't be accessed by ordinary users.
-
Page 35: Osd Navigation
Chapter 4. OSD Operation OSD Navigation To dismiss the menu, and deactivate the OSD, click the X at the upper right corner of the OSD Window or press Esc. To Logout click F8 or the symbol at the top of the Main Screen, or press [F8]. -
Page 36: Osd Functions
KH1508 / KH1516 User Manual OSD Functions OSD functions are used to configure and control the OSD. For example, you can rapidly switch to any port, scan selected ports only, limit the list you wish to view, designate a port as a Quick View Port, create or edit a port name, or make OSD setting adjustments. -
Page 37: F2: List
Chapter 4. OSD Operation F2: LIST Many of the switch’s OSD functions only operate on the computers currently selected for listing on the Main Screen. Accessing this function lets you broaden or narrow the scope of ports that get listed. The submenu choices and their meanings are given in the table below: Choice Meaning... -
Page 38: F3: Set
KH1508 / KH1516 User Manual F3: SET Accessing this function allows the administrator and each user to set up an individual working environment. A separate profile for each operator is stored by the OSD and is activated according to the username provided during login. To change a setting: 1. - Page 39 Chapter 4. OSD Operation Setting Function SCAN/SKIP Selects which computers will be accessed under Skip mode (see F5: MODE SKP, page 34), and Auto Scan mode (see F7: SCAN, page 36). Choices are: – All the ports which have been set Accessible (see SET ACCESSIBLE PORTS, page 31);...
- Page 40 KH1508 / KH1516 User Manual Setting Function SET QUICK This function lets the administrator select which ports to include as VIEW PORTS Quick View ports. To select/deselect a port as a Quick View Port, use the navigation keys to move the highlight bar to it, then press the [Spacebar]. When a port has been selected as a Quick View Port, an arrowhead displays in the QV column of the LIST on the Main Screen to indicate so.
-
Page 41: F4: Adm
Chapter 4. OSD Operation F4: ADM F4 is an administrator only function. Accessing this function allows the administrator to configure and control the overall operation of the OSD. To change a setting double click it; or use the up and down arrow keys to move the highlight bar to it, then press [Enter]. - Page 42 KH1508 / KH1516 User Manual Setting Function EDIT PORT To identify which computer is attached to a particular port, every port NAMES can be assigned a name. This function allows the administrator to create, modify, or delete port names. To assign a port name: 1.
- Page 43 Press [Spacebar] to cycle through the choices: The default is LANGUAGE English (US). FIRMWARE In order to upgrade the KH1508A / KH1516A and adapter cable UPGRADE firmware (see The Firmware Upgrade Utility, page 51) you must first enable Firmware Upgrade mode with this setting.
-
Page 44: F5: Skp
KH1508 / KH1516 User Manual F5: SKP This function enables you to easily skip backward or forward, switching the console focus from the currently active KVM Port to the previous or next available one. The selection of computers to be available for Skip mode switching is made with the Scan/Skip mode setting under the F3 SET function (see page 29). -
Page 45: F6: Brc
Chapter 4. OSD Operation F6: BRC F6 is an administrator only function. When this function is in effect, commands sent from the console are broadcast to all available computers on the installation. This function is particularly useful for operations that need to be performed on multiple computers, such as performing a system wide shutdown, installing or upgrading software, etc. -
Page 46: F7: Scan
KH1508 / KH1516 User Manual F7: SCAN This function automatically switches among the available computers at regular intervals so that you can monitor their activity without having to take the trouble of switching manually. The selection of computers to be included for Auto Scanning is made with the Scan/Skip mode setting under the F3 SET function (see page 29). -
Page 47: F8: Lout
Chapter 4. OSD Operation F8: LOUT Clicking the F8 field, or pressing [F8], logs you out of the OSD and blanks the console screen. This is different from simply deactivating the OSD when you are at the Main Screen by pressing [Esc]. With this function you must log in all over again to regain access to the OSD, whereas with [Esc], all you have to do to reenter the OSD is tap the OSD Hotkey. - Page 48 KH1508 / KH1516 User Manual This Page Intentionally Left Blank...
-
Page 49: Chapter 5. Hotkey Operation
Chapter 5 Hotkey Operation Hotkey Port Control Hotkey port control allows you to provide KVM focus to a particular computer directly from the keyboard. The KH1508 / KH1516 provides the following Hotkey port control features: Selecting the Active Port Auto Scan Mode Switching Skip Mode Switching Computer Keyboard / Mouse Reset The following settings can also be controlled in Hotkey mode:... -
Page 50: Invoking Hotkey Mode
KH1508 / KH1516 User Manual Invoking Hotkey Mode All Hotkey operations begin by invoking Hotkey mode. To invoke Hotkey mode you may use two possible keystroke sequences shown below. Only one of the two key-sequences below can be operational (see Setting the Hotkey key combination on page 46): Number Lock and Minus Keys 1. -
Page 51: Selecting The Active Port
Chapter 5. Hotkey Operation Selecting the Active Port Each computer port is assigned a port ID (see Port ID Numbering, page 21). You can directly access any computer with a Hotkey combination that specifies the port ID that the computer is connected to. The steps are: 1. -
Page 52: Auto Scan Mode Switching
KH1508 / KH1516 User Manual Auto Scan Mode Switching Auto Scan automatically switches among all the active computer ports that are accessible to the currently logged on user at regular intervals. This allows their activity to be monitored automatically (See SKAN/SKIP MODE of the OSD F3 SET function, page 29). -
Page 53: Exiting Auto Scan
Chapter 5. Hotkey Operation (Continued from previous page.) When you want to keep the focus on a particular computer, Pausing is more convenient than exiting Auto Scan mode. When you resume scanning it starts at the computer where you paused. If you exited and then restarted Auto Scanning, it starts, at the beginning, from the first computer on the installation. -
Page 54: Skip Mode Switching
KH1508 / KH1516 User Manual Skip Mode Switching This feature allows you to switch between computers in order to monitor them manually. You can focus on a particular port for as long as you like – as opposed to auto-scanning, which automatically switches the port focus after a fixed interval. -
Page 55: Computer Keyboard / Mouse Reset
Chapter 5. Hotkey Operation Computer Keyboard / Mouse Reset If either the keyboard or mouse stop functioning on the computer connected to the currently selected port, you can perform a keyboard / mouse reset on the computer by executing the following steps: 1. -
Page 56: Setting The Hotkey Key Combination
KH1508 / KH1516 User Manual Setting the Hotkey key combination The keys used to enter the Hotkey Mode (see HOTKEY COMMAND MODE, page 29) can be switched between: , and [Num Lock] + [-] [Ctrl] + [F12] by the following steps: 1. -
Page 57: Setting The Port Operating System
Chapter 5. Hotkey Operation Setting the Port Operating System A port’s operating system configuration can be matched to that of the computer attached to the port by performing the following steps: 1. Invoke Hotkey mode: [Num Lock] + [-] or [Ctrl] + [F12] 2. -
Page 58: Hotkey Summary Table
KH1508 / KH1516 User Manual Hotkey Summary Table [Num Lock] + [-] [A] [Enter] Invokes Auto Scan mode. When Auto Scan mode is in effect, [P] or left-click pauses auto-scanning. [Ctrl] + [F12] When auto-scanning is paused, pressing any key or another left-click resumes auto- scanning. -
Page 59: Chapter 6. Keyboard Emulation
Chapter 6 Keyboard Emulation Mac Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Mac keyboard. The emulation mappings are listed in the table below. PC Keyboard Mac Keyboard [Shift] Shift [Ctrl] Ctrl [Ctrl] [1] [Ctrl] [2] [Ctrl] [3] [Ctrl] [4] [Alt]... -
Page 60: Sun Keyboard
KH1508 / KH1516 User Manual Sun Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Sun keyboard when the Control key [Ctrl] is used in conjunction with other keys. The corresponding functions are shown in the table below. PC Keyboard Sun Keyboard [Ctrl] [T]... -
Page 61: The Firmware Upgrade Utility
Chapter 7 The Firmware Upgrade Utility Introduction The purpose of the Windows-based Firmware Upgrade Utility is to provide an automated process for upgrading the KH1508 / KH1516 and compatible adapter cable firmware. The program comes as part of a Firmware Upgrade Package that is specific for each device. - Page 62 KH1508 / KH1516 User Manual (Continued from previous page.) 3. Use the firmware upgrade cable (provided with this unit), to connect a COM port on your computer to the firmware upgrade port of your device. Note: On a daisy chained installation, connect the cable to the first station (master) unit.
-
Page 63: Performing The Upgrade
Chapter 7. The Firmware Upgrade Utility Performing the Upgrade Starting the Upgrade To upgrade your firmware: 1. Run the downloaded Firmware Upgrade Package file, either by double clicking the file icon, or by opening a command line and keying in the full path to it. - Page 64 KH1508 / KH1516 User Manual (Continued from previous page.) 3. Click Next to continue. The Firmware Upgrade Utility main screen appears: The Utility checks to make sure the KH1508 / KH1516 is in the Firmware Upgrade Mode and then lists all firmware needed preselected in the Device List panel.
- Page 65 Chapter 7. The Firmware Upgrade Utility 4. Select MAIN to upgrade the firmware for the Main Board. Deselect any KVM Adapter Cable types that are not required to be upgraded. After you have made your selection(s), click Next to perform the upgrade. Check Firmware Version - when selected the utility compares the Main Board firmware level with the upgrade files MAIN.
-
Page 66: Upgrade Succeeded
KH1508 / KH1516 User Manual Upgrade Succeeded After the upgrade has completed, a screen appears to inform you that the procedure was successful: Click Finish to close the Firmware Upgrade Utility. Note: At the completion of the upgrade, the KH1508 / KH1516 restarts. -
Page 67: Upgrade Failed
Chapter 7. The Firmware Upgrade Utility Upgrade Failed If the upgrade failed to complete successfully a dialog box appears asking if you want to retry. Click Yes to retry. If you click No, the Upgrade Failed screen appears. Click Cancel to close the Firmware Upgrade Utility. See the next section, Firmware Upgrade Recovery, for how to proceed. -
Page 68: Adapter Cable Firmware Upgrade Recovery
KH1508 / KH1516 User Manual Adapter Cable Firmware Upgrade Recovery To perform an adapter cable firmware upgrade recovery, do the following: 1. Unplug the adapter cable from the computer it is connected to. 2. Slide its Firmware Upgrade Recovery Switch (located next to the RJ45 connector) to the Recover position. -
Page 69: Appendix
Appendix Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. Do not use the device near water. - Page 70 KH1508 / KH1516 User Manual If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
-
Page 71: Rack Mounting
Appendix Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack. -
Page 72: Technical Support
KH1508 / KH1516 User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://support.aten.com For telephone support, see Telephone Support, page iii. North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support Technical Documentation Support Software Updates Telephone Support 1-888-999-ATEN ext 4988 When you contact us, please have the following information ready beforehand:... -
Page 73: Specifications
Appendix Specifications Function KH1508 KH1516 Computer Direct Connections Max. 256 (via Daisy Chain) 512 (via Daisy Chain) Port Selection OSD (On Screen Display); Hotkeys Pushbuttons Connectors Console KB 1 x 6-pin Mini-DIN F (Purple) 1 x USB Type A F Video 1 x HDB-15 F Mouse... - Page 74 KH1508 / KH1516 User Manual Function KH1508 KH1516 Physical Housing Metal Properties Weight 2.74 kg 2.77 kg Dimensions 43.30 x 16.00 x 4.40 cm...
-
Page 75: Connection Tables
Appendix Connection Tables The following table indicates the relationship between the number of KH1508 / KH1516 units and the number of computers that they control KH1508 Computers Computers Computers Computers 1 - 8 65 - 72 129 - 136 193 - 200 9 - 16 73 - 80 137 - 144... -
Page 76: Compatible Switches
KH1508 / KH1516 User Manual Compatible Switches The following ATEN switches can be installed on a KH1508 / KH1516 daisy chain: ACS1208 / ACS1216 CS1708 / CS1716 KH1508 / KH1516... -
Page 77: Osd Factory Default Settings
Appendix OSD Factory Default Settings The factory default settings are as follows: Setting Default OSD Hotkey [Scroll Lock] [Scroll Lock] Port ID Display Position Upper Left Corner Port ID Display Duration 3 Seconds Port ID Display Mode The Port Number plus the Port Name Scan Duration 5 Seconds Scan/Skip Mode... -
Page 78: Administrator Login Failure
KH1508 / KH1516 User Manual Administrator Login Failure If you are unable to perform an Administrator login (because the Username and Password information has become corrupted or you have forgotten it, for example) you can clear the login information with the following procedure: 1. -
Page 79: Troubleshooting
Appendix Troubleshooting Overview Operation problems can be due to a variety of causes. The first step in solving them is to make sure that all cables are securely attached and seated completely in their sockets. In addition, updating the product’s firmware may solve problems that have been discovered and resolved since the prior version was released. -
Page 80: Limited Warranty
ALTUSEN warrants this product against defects in material or workmanship for a period of one (1) year from the date of purchase. If this product proves to be defective, contact ALTUSEN's support department for repair or replacement of your unit. ALTUSEN will not issue a refund. - Page 81 Index Hot Plugging, 20 Hotkey, 23 Adapter cable installation, 16 Selecting the Active Port, 41 Administrator Login Failure, 68 Summary Table, 48 Auto Scanning, 28, 42 Hotkey Mode Invoking Auto Scan, 42 Exiting, 40 Pausing Auto Scan, 42 Invoking, 40 Setting the Scan Interval, 42 Hotkey Port Control, 39 Stopping, 43...
- Page 82 KH1508 / KH1516 User Manual KVM adapter cables, 5 Operating Systems, 5 Online OS Support, 5 Registration, iii Reset Switch, 7 RoHS, ii Factory Default Settings, 67 Functions, 26 Hotkey, 23 Safety Instructions Main Screen Headings, 25 General, 59 Navigation, 25 Rack Mounting, 61 Overview, 23 Scan Duration, 28...
