Check Required Hardware

Check Required Hardware

The HS-21/HS-41X is shipped with one of the following cables:
6' USB Straight Cable
USB Hardware
• HS-21/HS-41X Handheld Reader
• USB Cable
RS-232 Hardware
• HS-21/HS-41X Handheld Reader
• RS-232 Cable
• RS-232 Power Supply
Changing Cable and Communications Interface
The reader can be converted from USB to RS-232 or from RS-232 to USB by changing
the cable and scanning the appropriate communications programming symbol below. To
detach the USB or RS-232 cable from the reader, press a paper clip into the hole on the
side of the handle and gently pull the cable out of the connector.
1-2
8' RS-232 Coiled Cable
USB Interface
HS-21/HS-41X Handheld Reader User's Manual
RS-232 Interface
Save
Settings
