Microscan HS-21 User Manual page 146

1B Communications Mode
1C Serial Baud Rate
1D Serial Stop Bits
1E Serial Data Bits
HS-21/HS-41X Handheld Reader User's Manual
1: RS232 serial
2: USB keyboard
5: USB Native (HID)
6: USB VComm
7: USB HID POS -Terminal 131
8: Dynamic (1 if decode is RS232; 2 if
decode is USB)
This setting is used in conjunction with
settings 08 and 42 to configure the
communication mode between stan-
dard "one-way" and "two-way" modes.
For example, USB "two-way" native:
1b: 5 (USB Native)
08: 2 (packet mode)
42: 1 (expect response)
Note: The following must be completed
within 1 second.
8
first output report with numlock set and
capslock clear
second output report with numlock set
and capslock clear
third output report with capslock set
numlock clear
fourth output report with capslock set
numlock clear
fifth output report with numlock set and
capslock clear
sixth output report with numlock set
and capslock clear
On the last output report comm proto-
col is set to raw mode, comm expect
response is false and comm mode is
USB Downloader mode.
Also see registers: 08, 42
All standard baud rates up #115200
• #9600 (2580)
1C200 • #19200 (4B00)
(#115200)
• #38400 (9600)
• #57600 (E100)
• #115200 (1C200)
1: One
1
2: Two
7: Seven
8
8: Eight
Appendices
A-29
