Select Interface and Connect to Reader

USB
• In the communications dialog box, select the communications interface you are using
and click Next.
• Click the Show Connect Symbol button, print the USB Connect Mode symbol, and
decode it with the reader to ensure that you are in the correct communications interface.
Keep the printed symbol in a convenient place for future use.
• Click Next when you are finished.
The Select Device dialog will then reappear:
• You will see a " Reader" ID number in the Select Device field. Click Connect.
• When you are connected successfully, the
green box in the status bar at the bottom right of the screen.
You are now ready to configure your reader using ESP. Subsequent sections provide
more detailed information about ESP's configuration options.
HS-21/HS-41X Handheld Reader User's Manual
Click the Show
Connect Symbol
button.
Reader ID number should
match the serial number next
to the trigger under the optical
head of the reader.
CONNECTED
Quick Start
message will appear in a
1-7
