Microscan HS-21 User Manual page 151

Serial Commands
42 Expect Acknowledgement From Host
43 JPEG Picture Quality (percent)
45 Read Cycle Timeout
47 Maxicode Symbology
48 Codabar Checksum
A-34
0: Reader doesn't wait for acknowl-
edge
1: Reader will retransmit data when
Host doesn't acknowledge receipt
This setting is used in conjunction with
settings 1B and 42 to configure the
communication mode between stan-
0
dard "one-way" and "two-way" modes.
For example, USB "two-way" native:
1B: 5 (USB Native)
08: 2 (packet mode)
42: 1 (expect response)
Also see registers: 08, 1B
Valid Range: 0 to 64 (#100) Percent
0: Raw Image (No JPEG Compression)
32 (#50)
1 To 100: JPEG Compression Quality
Percent
Also see registers: 36, AC, AD, AE, AF
1F4 (#500) Valid Range: 0 to FFFF (#65535) ms
Binary Dip Switch
Bit Controls
Maxicode Decoding,
0
Mode 0
Maxicode Decoding,
1
Mode 1
Maxicode Decoding,
2
Mode 2
0
Maxicode Decoding,
3
Mode 3
Maxicode Decoding,
4
Mode 4
Maxicode Decoding,
5
Mode 5
Maxicode Decoding,
6
Mode 6
Binary Dip Switch
Bit Controls
Codabar Checksum
0
0
Checking
Strip Checksum from
1
Output
HS-21/HS-41X Handheld Reader User's Manual
Value
0: Disabled
1: Enabled
0: Disabled
1: Enabled
0: Disabled
1: Enabled
0: Disabled
1: Enabled
0: Disabled
1: Enabled
0: Disabled
1: Enabled
0: Disabled
1: Enabled
Value
0: Disabled
1: Enabled
0: Disabled
1: Enabled
