Clevo W350HU Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

W350HU/ W350HV

Advertisement

Table of Contents
loading

Related Manuals for Clevo W350HU

Summary of Contents for Clevo W350HU

  • Page 1 W350HU/ W350HV...
  • Page 3 Preface Notebook Computer W350HU/ W350HV Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W350HU/ W350HV series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents System Startup ................1-VIII Top with Fingerprint ..............A-3 Introduction ..........1-1 Bottom ................... A-4 LCD ....................A-5 Overview ..................1-1 SATA DVD Super-Multi ............... A-6 Specifications ..................1-2 HDD ....................A-7 External Locator - Top View with LCD Panel Open ......1-4 Schematic Diagrams.........
  • Page 12 Preface CARD READER JMC261C, ESATA ......... B-26 Use the flash tools to update the BIOS ...........C-2 INTEL LAN82579 ............... B-27 Restart the computer (booting from the HDD) .......C-2 LAN(82579), SATA HDD, ODD ..........B-28 USB 2.0 CHARGER, Audio Conn ..........B-29 USB 3.0 TI TUSB7320 ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W350HU/ W350HV series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. VGA & audio) is also found in the User’s Manual. The manual is shipped with the computer.

  • Page 14: Specifications

    Introduction Specifications Processor Options W350HU: 15.6" (39.62) HD/HD+ TFT LCD Intel® Core™ i7 Processor Memory  i7-2620M (2.7GHz) 4MB L3 Cache, 32nm, DDR3-1333MHz, TDP 35W Two 204 Pin SO-DIMM Sockets Supporting DDR3 1333MHz Latest Specification Information Memory Intel® Core™ i5 Processor...
  • Page 15 Built-In Gigabit Ethernet LAN 2 * Built-In Speakers (Factory Option) 1.3M/2.0M Pixel USB PC Camera Module Built-In Microphone (Factory Option) 3.75G/HSPA Mini-Card Module W350HU: Interface (Factory Option) Intel® Centrino® Advanced-N 6230 Wire- One Powered USB 2.0 Port less LAN (802.11a/g/n) + Bluetooth 3.0 Two USB 3.0 Ports...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Ca- mera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. Keyboard 7. Built-In Microphone 8. Touchpad & Buttons 9. Fingerprint Reader 10.LED Indicators 1 - 4 External Locator - Top View with LCD Panel Open...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 RIGHT SIDE VIEW Right Side View 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. Powered USB  2.0 Port (see note below) 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. e-SATA Port/USB 2.0 Combo Port 5. HDMI-Out Port 6. Vent 7. 2 * USB 3.0 Ports 8.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Docking Port 3. Component Bay Cover 4. Vent 5. Hard Disk Bay Cover  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. ITE IT8709E 2. TI TUSB7320 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots DDR3 SO-DIMM 3. Azalia Codec 4. ITE IT8518E 5. Platform Controller 6. CMOS Batery 7. JMICRO JM261C 8. Multi-in-1 Card Reader 9.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. LCD Cable Connector 2. Speaker Cable Connector 3. Inverter Connector 4. e-SATA Port/USB 2.0 Combo Port 5. HDMI-Out Port 6. USB 3.0 Ports 7. Modem Connector 8. HDD Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Battery Connector 2. Docking Station Connector 3. Mini-Card Connector (3G Module) 4. Multi-I/O Connector 5. ODD Connector 6. HDD Connector 7. Fan cable Connector 8. RJ-45 LAN Jack 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W350HU/ W350HV series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold in 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a place.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Remove the hard disk bay cover (Figure 3b Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3c HDD Assembly 5. Lift the hard disk out of the bay (Figure 3d Removal (cont’d.) 6.

  • Page 32: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3 1066/1333MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB, and 2048MB and DDRIII Modules.
  • Page 33 Disassembly 5. Gently pull the two release latches ( on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure 5c). RAM Module Removal (cont’d.) c. Pull the release latches. d. Remove the module(s). 6.

  • Page 34: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 6 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Removal 2. Remove the screw at point (Figure 6a , and use a screwdriver to carefully push out the optical device point (Figure 6b a.

  • Page 35: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Figure 7 Processor Removal Processor Removal Procedure 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - a. Remove the cover and 2. The CPU heat sink will be visible at point (Figure 7a) on the mainboard.
  • Page 36 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure 8d). Figure 8 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 8e). 7. See page 2 - 13 for information on inserting a new CPU.
  • Page 37 Disassembly Processor Installation Procedure Figure 9 1. Insert the CPU (Figure 9a , pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE Processor Installation IT!), and turn the release latch towards the lock symbol (Figure 9b).

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point (Figure 10a on the mainboard.

  • Page 39: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer and remove the battery (page 2 - & 2. Remove screws and use a screwdriver to carefully push out the top cover module at point (Figure a. Remove the screws and 11a).

  • Page 40: Removing The 3.75G Module

    Disassembly Removing the 3.75G Module Figure 12 3G Module Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 14). a. Locate the 3.75G mod- 2.

  • Page 41: Removing The Modem

    Disassembly Removing the Modem Figure 13 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), component bay cover (page 2 - 8), opti- Modem Removal cal device (page 2 - 10), CPU (page 2 - 10), bluetooth (page 2 -...
  • Page 42 Disassembly 6. Remove screws & from the module and disconnect cable (Figure 14d). Figure 14 7. Carefully lift the modem up and off the socket (Figure 14e). Modem Removal (cont’d.) d. Remove the screws and disconnect cable from the module. e.

  • Page 43: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the W350HU/ W350HV series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W350HU/ W350HV Location page A - 3 Top with Fingerprint page A - 4 Bottom...

  • Page 45: Top With Fingerprint

    Part Lists Top with Fingerprint Figure A - 1 Top with Finger- print (黑色) 修模)(RIB減膠) (新上蓋+新按鍵) (灰色) (尚盟) 增加背膠長度 (富士弘) 頭徑 頭厚 號 Top with Fingerprint A - 3...

  • Page 46: Bottom

    Part Lists Bottom 導電布 導電布 日東 Figure A - 2 Bottom (更換背膠) (富士弘) 頭徑3.5MM 頭厚0.8MM 1號穴 鍍白鎳 I頭 (黑色) A - 4 Bottom...

  • Page 47: Lcd

    Part Lists Figure A - 3 (富士弘) (黑色亮面) 頭徑 頭厚 號穴 鍍白鎳 頭 (志精) (今皓) (志精) (富士弘) Ω Ω LCD A - 5...

  • Page 48: Sata Dvd Super-Multi

    Part Lists SATA DVD Super-Multi Figure A - 4 SATA DVD Super- Multi *(非耐落) (志精) (黑色) A - 6 SATA DVD Super-Multi...

  • Page 49: Hdd

    Part Lists Figure A - 5 無鉛 (無鉛) HDD A - 7...
  • Page 50 Part Lists A - 8...

  • Page 51: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W350HU/ W350HV notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page...

  • Page 52: System Block Diagram

    Schematic Diagrams System Block Diagram ODD board 5V,3V,5VS,3VS,1.5VS, Huron River System Block Diagram 6-71-W760N-D02 1.5VS_CPU,1.05V_M,1.05VS MULTI I/O BOARD SPK_R, RJ-11, CCD 6-71-W3501-D02 VDD3,VDD5 1 ? ? 6-7P-W3507-002 Memory Termination Sandy Bridge AUDIO BOARD 800/1067/1333 MHz 1.5V/0.75V(VTT_MEM), PHONE JACK, USB DDR3 / 1.5V 1.8VS 6-71-T5108-D02 37.5*37.5 mm...

  • Page 53: Processor/ Dmi, Peg, Fdi

    Schematic Diagrams PROCESSOR/ DMI, PEG, FDI Sandy Bridge Processor 1/7 ( DMI,PEG,FDI ) 1.05VS_VTT U21A 20 mil PEG_COMP 24.9_1%_04 PEG_ICOMPI PEG_ICOMPO DMI_TXN0 DMI_RX#[0] PEG_RCOMPO DMI_TXN1 DMI_RX#[1] DMI_TXN2 DMI_RX#[2] DMI_TXN3 DMI_RX#[3] PEG_RX#[0] DK_PEG_RX#0 22 DK_PEG_RX#1 22 PEG_RX#[1] DK_PEG_RX#2 22 DMI_TXP0 DMI_RX[0] PEG_RX#[2] DMI_TXP1 DMI_RX[1]...

  • Page 54: Processor/ Clk, Misc, Jtag

    Schematic Diagrams PROCESSOR/ CLK, MISC, JTAG Processor Pullups/Pull downs 1.05VS_VTT Sandy Bridge Processor 2/7 H_PROCHOT# PU/PD for JTAG signals 62_04 1.05VS_VTT H_CPUPWRGD_R 10K_04 R327 ( CLK,MISC,JTAG ) 51_04 R337 XDP_TMS *0.1u_10V_X7R_04 C386 XDP_TDI_R 51_04 XDP_PREQ# *51_04 XDP_TDO_R 51_04 51_04 R336 XDP_TCLK U21B 51_04...

  • Page 55: Processor/ Ddr3

    Schematic Diagrams PROCESSOR/ DDR3 Sandy Bridge Processor 3/7 ( DDR3 ) U21C U21D M_A_DQ[63:0] M_A_CLK_DDR0 9 M_B_DQ[63:0] M_B_CLK_DDR0 10 SA_CLK[0] SB_CLK[0] M_A_CLK_DDR#0 9 M_B_CLK_DDR#0 10 SA_CLK#[0] SB_CLK#[0] M_A_DQ0 M_B_DQ0 M_A_CKE0 9 M_B_CKE0 10 SA_DQ[0] SA_CKE[0] SB_DQ[0] SB_CKE[0] M_A_DQ1 M_B_DQ1 SA_DQ[1] SB_DQ[1] M_A_DQ2 M_B_DQ2...

  • Page 56: Processor/ Power1

    Schematic Diagrams PROCESSOR/ POWER1 Sandy Bridge Processor 4/7 POWER U21F VCORE 1.05VS_VTT PROCESSOR UNCORE POWER 8.5A AG35 PROCESSOR CORE POWER VC C1 AG34 AH 13 VC C2 VCC IO1 AG33 AH 10 AG32 VC C3 VCC IO2 AG10 C111 C119 C 120 C 121 C 122...

  • Page 57: Processor/ Power2

    Schematic Diagrams PROCESSOR/ POWER2 Sandy Bridge Processor 5/7 ( GRAPHICS POWER ) POWER 1.5V U21G VGFX_CORE All VAXG = 33A R356 AT24 AK35 VAXG1 VAXG_SENSE VCC_GT_SENSE 39 AT23 AK34 1K_1%_04 VSS_GT_SENSE 39 VAXG2 VSSAXG_SENSE AT21 C108 C110 C103 C118 *AO3402L VAXG3 AT20 V_SM_VREF...

  • Page 58: Processor/ Gnd

    Schematic Diagrams PROCESSOR/ GND Sandy Bridge Processor 6/7 ( GND ) U21H U21I AT35 AJ22 VSS1 VSS81 AT32 AJ19 VSS2 VSS82 AT29 AJ16 AT27 VSS3 VSS83 AJ13 VSS161 VSS234 VSS4 VSS84 VSS162 VSS235 AT25 AJ10 VSS5 VSS85 VSS163 VSS236 AT22 VSS6 VSS86 VSS164...

  • Page 59: Processor/ Reserved

    Schematic Diagrams PROCESSOR/ RESERVED Sandy Bridge Processor 7/7 ( RESERVED ) CFG Straps for Processor PEG Static Lane Reversal - CFG2 is for the 16x U21E 1:(Default) Normal Operation; Lane # CFG2 RSVD28 RSVD29 definition matches socket pin map definition AK28 CFG0 CFG[0]...

  • Page 60: Ddr3 So-Dimm 0

    Schematic Diagrams DDR3 SO-DIMM 0 SO-DIMM A CHANGE TO STANDARD JDIMM2A M_A_A[15:0] M_A_DQ[63:0] 4 M_A_A0 M_A_DQ0 JDIMM2B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 1.5V M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_A7 M_A_DQ7 VDD3 VSS18 M_A_A8 M_A_DQ8 VDD4 VSS19 M_A_A9...
  • Page 61 Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM B CHANGE TO STANDARD JDIMM1A M_B_B[15:0] M_B_DQ[63:0] 4 M_B_B0 M_B_DQ0 JDIMM1B M_B_B1 M_B_DQ1 M_B_B2 M_B_DQ2 1.5V M_B_B3 M_B_DQ3 M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ5 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18 M_B_B8 M_B_DQ8 VDD4 VSS19 M_B_B9 M_B_DQ9...

  • Page 62: Lvds, Inverter

    Schematic Diagrams LVDS, INVERTER 3.3VS_LCD PANEL CONNECTOR R283 R285 2.2K_04 2.2K_04 J_LCD1 MUX_2N 0_8P4R_04 LVDS-U2N P_DDC_DATA MUX_2P P_DDC_DATA 16 LVDS-U2P LVDS-UCLKN P_DDC_CLK MUX_1N LVDS-UCLKN P_DDC_CLK 16 LVDS-U1N LVDS-UCLKP PLVDD_SEL MUX_1P LVDS-UCLKP LVDS-U1P MUX_2N MUX_0N 0_8P4R_04 LVDS-U0N MUX_1N MUX_2P MUX_0P R294 0_06 VLED LVDS-U0P...

  • Page 63: Hdmi, Crt

    Schematic Diagrams HDMI, CRT 5VS_HDMI For ESD FOR W/O LEVEL SHIFT HDMI PORT D02 0523 Colay ? ? ? U5? ? ? ? ? FOR INTEL GRAPHIC D02 0524 HDMIB_D2BP R117 0_04 HDMIB_DATA2P_R HDMIB_D2BN R116 0_04 HDMIB_DATA2N_R 5VS_HDMI *BAV99 RECTIFIER *BAV99 RECTIFIER HDMIB_D1BP R119...

  • Page 64: Pch/ Hda, Jtag, Sata

    HDA_SYNC_R 32 RN22 33_8P4R_04 3.3V_M HDA_SDOUT_R W350HU HDA_SDO_MDC HDA_SDOUT 32 HDA_SYNC_R HDA_SY NC_MDC HDA_SYNC 32 HDA_RST#_R HDA_RST#_MDC HDA_RST# 32 VDD3 C619 W350HU VPRO HDA_BITCLK_R HDA_BITCLK_MDC HDA_BITCLK 32 NC_04 *0.1u_16V_Y 5V_04 33_8P4R_04 32Mbit RN21 3.3VS_SPI SPI_SI R407 R388 R387 15,19,26,27,34 3.3V_M...

  • Page 65: Pch/ Pci-E, Smbus, Clk

    Schematic Diagrams PCH/ PCI-E, SMBUS, CLK PCI-E x1 Usage VDD3 CougarPoint - M (PCI-E,SMBUS,CLK) Lane 1 RN17 2.2K_8P4R_04 Lane 2 USB3.0 SMB_CLK SMB_DATA Lane 3 WLAN SML0_CLK Lane 4 CARD READER SML0_DATA Lane 5 NEW CARD Lane 6 GLAN INTEL 82579 U32B SMC_CPU_THERM R461...

  • Page 66: Pch/ Dmi, Fdi, Gpio

    Schematic Diagrams PCH/ DMI, FDI, GPIO CougarPoint -M (DMI,FDI,GPIO) AC_PRESENT R465 10K_04 U32C PCIE_WAKE# R439 10K_04 VDD3 PM_SLP_LAN# R462 *10K_04 BC24 BJ14 DMI_RXN0 DMI0RXN FDI_RXN0 FDI_TXN0 2 BE20 AY14 SWI# R443 10K_04 R460 0_04 DMI_RXN1 DMI1RXN FDI_RXN1 FDI_TXN1 2 BG18 BE14 DMI_RXN2 FDI_TXN2 2...

  • Page 67: Pch/ Lvds, Ddi,Crt

    Schematic Diagrams PCH/ LVDS, DDI,CRT CougarPoint -M (LVDS,DDI,CRT) U32D AP43 BLON L_BKLTEN SDVO_TVCLKIN N AP45 11,30 N B_EN AVDD L_VD D _EN SD VO_TVC LKINP AM42 L_BKLTC TL SD VO_STALLN AM40 SD VO_STALLP Ver:1.0 P_D DC _C LK L_D DC _CLK AP39 pull up 2.2K P_DD C_D ATA...

  • Page 68: Pch/ Pci, Usb, Nvram

    Schematic Diagrams PCH/ PCI, USB, NVRAM Boot BIOS Strap BBS_BIT1 BBS_BIT0 Boot BIOS Location CougarPoint -M (PCI,USB,NVRAM) Reserved (NAND) U32E AY 7 FOR LAYOUT SWAP RSVD1 BG26 RSVD2 3.3VS RN 6 BJ26 RSVD3 10K_8P4R_04 BH 25 RSVD4 INT_PIRQD# BJ16 AT10 0421 Swap SATA_ODD_D A# BG16...

  • Page 69: Pch/ Gpio, Vss Nctf, Rsvd

    Schematic Diagrams PCH/ GPIO, VSS NCTF, RSVD R219 10K_04 BIOS_REC 3.3VS CougarPoint - M (GPIO,VSS_NCTF,RSVD) R207 *0_04 BIOS RECOVERY U32F DISABLE----R349 NO STUFF (DEFAULT) ENABLE-----R349 STUFF S_GPIO SATA_ODD_PWRGT SATA_ODD_PWRGT 27 BMBUSY# / GPIO0 TACH4 / GPIO68 SMI# PCH_GPIO57 R501 1.5K_1%_04 SMI# TACH1 / GPIO1 TACH5 / GPIO69...

  • Page 70: Pch/ Power 1

    Schematic Diagrams PCH/ POWER 1 CougarPoint -M (POWER) 3.3VS HCB1005KF-121T20 POWER 1.05VS VCCA_DAC_3.3VS U32G All VCCORE = 1.3A AA23 VCCCORE[1] VCCADAC AC23 C321 C304 C312 C314 C559 C547 C566 C554 C568 C573 VCCCORE[2] AD21 R538 VCCCORE[3] SHDN# AD23 10u_6.3V_X5R_06 1u_6.3V_Y5V_04 1u_6.3V_Y 5V_04 1u_6.3V_Y 5V_04 0.01u_16V_X7R_04...
  • Page 71 Schematic Diagrams PCH/ POWER 2 CougarPoint - M (POWER) CougarPoint power supply range Voltage Rail Voltage S0 Iccmax Current (A) 1.05VS_VCCA_CLK V_CPU_IO 1.05 1 (mA) Voltage *HCB1005KF-121T20 V5REF 1 (mA) 1.05VS 1.00V 1.05V 1.10V V5REF_Sus 1 (mA) POWER R209 *20mil_04 U32J VDD3 Vcc3_3...

  • Page 72: Pch/ Gnd

    Schematic Diagrams PCH/ GND CougarPoint -M (GND) U32I U32H VSS[159] VSS[259] VSS[0] AY 42 VSS[160] VSS[260] AY 46 AA17 AK38 VSS[161] VSS[261] VSS[1] VSS[80] VSS[162] VSS[262] VSS[2] VSS[81] AK42 VSS[163] VSS[263] AA33 VSS[3] VSS[82] AK46 VSS[164] VSS[264] AA34 VSS[4] VSS[83] VSS[165] VSS[265] VSS[5]...

  • Page 73: Docking Connector

    Schematic Diagrams DOCKING CONNECTOR J_DOCK1 NEAR OSC1 *0_04 CLK_48M_COM 14 3.3V pin2,8,143,144 DOCKING? ? ? OSC1 3.3V AVCC DK_SENSE DK_LAN_MDIO0+ DK_USB_PN12 17 DK_LAN_MDIO0- DK_USB_PP12 17 DK_SENSE DSO751SV_48MHz DK_LAN_MDIO1+ AVCC CTS# DK_LAN_MDIO1- AVSS VSTBY CLKIN DCD# AVSS DCD# / GPIO21 / CIR1TX AVSS DSR# CLKRUN#...

  • Page 74: 3G, Tpm

    Schematic Diagrams 3G, TPM MINI CARD 3G & mSATA REDRIVER 3G POWER 3G_3.3V J_3G1 60mils WAKE# 3.3VAUX_0 COEX1 1.5V_0 UIM_PWR COEX2 UIM_PWR UIM_DATA C370 C359 UIM_DATA UIM_CLK C369 CLKREQ# UI M_CLK 3.3V UIM_RST REFCLK- UIM_RESET UIM_VPP REFCLK+ UI M_VPP For mSATA GND0 GND1 GND5...

  • Page 75: New Card, Mini Pcie

    Schematic Diagrams NEW CARD, MINI PCIE 3.3V NEW CARD C207 *0.1u_16V_Y5V_04 3.3V BUF_PLT_RST# 74AHC1G08GW R218 R193 C462 C476 C461 *100K_04 *100K_04 0.1u_16V_Y5V_04 0.1u_16V_Y 5V_04 0.1u_16V_Y 5V_04 1.5VS 3.3VS 3.3V J_NEW1 NC_RST# NC_PERST# AUXIN PERST# PERST# 36mils NC_3.3VAUX AUXOUT +3.3VAUX 48mils NC_3.3V 3.3VIN 3.3VOUT...

  • Page 76: Card Reader Jmc261C, Esata

    Schematic Diagrams CARD READER JMC261C, ESATA SD _CLK Switching Regulator JMC261C VC C_C AR D 3.3VS VDD 3 close to PIN33 C453 near Pin#41 *10p_50V_NPO_04 DVDD SD_CLK R375 22_1%_04 C456 C463 (>20mil) R408 10K_04 R EGLX DVDD D02 0524 1u_16V_Y 5V_04 1u_16V_Y 5V_04 R409 *4.7K_04...
  • Page 77 Schematic Diagrams INTEL LAN82579 3.3V_M 3.3V_M 3.3V_LAN 1.05V_LAN_M 1.0M_LAN D02 0525 D02 0525 *28mil_06_SHORT *28mil_06_SHORT C610 C611 0.1u_16V_Y 5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y 5V_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 VDD3 10K_04 LAN_MDIP0 IGLAN_CLKREQ# LAN_MDIP0 27 CLK_REQ_N MDI_PLUS0 LAN_MDIN0 Sheet 26 of 49 17,22,24,25,29,30 BUF_PLT_RST# PE_RST_N MDI_MINUS0 LAN_MDIN0 27...

  • Page 78: Lan(82579), Sata Hdd, Odd

    Schematic Diagrams LAN(82579), SATA HDD, ODD GIGA LAN (82579) *WCM2012F2S-SHORT J_RJ1 NB_LAN_MDIP0 LMX1+ DLMX1+ GND1 TD4+ 3.3V_M MX4+ shield GND2 NB_LAN_MDIN0 LMX1- *WCM2012F2S-SHORT DLMX1- TD4- MX4- shield NB_LAN_MDIP1 LMX2+ DLMX2+ MX3+ TD3+ NB_LAN_MDIN1 LMX2- DLMX2- TD3- MX3- NB_LAN_MDIP2 LMX3+ DLMX3+ TD2+ MX2+ NB_LAN_MDIN2...

  • Page 79: Usb 2.0 Charger, Audio Conn

    Schematic Diagrams USB 2.0 CHARGER, Audio Conn USB Charger components USBCHG VDD5_USBCHG C486 10u_10V_Y 5V_08 80mils 80mils USB_PN0_R C483 USB_PN0 DM_O DM_IN USB_PP0_R *0.1u_16V_Y 5V_04 USB_PP0 DP_O DP_IN VDD3 ILIM_SEL R451 10K_04 R473 20K_1%_04 R3_4_PREVIEW_6_02 VDD5_USBCHG EN/DSC ILIM0 R450 10K_04 R472 *10K_04 R471...

  • Page 80: Usb 3.0 Ti Tusb7320

    Schematic Diagrams USB 3.0 TI TUSB7320 7 5 C o m p o n e n t . 1.1V_TI 3.3V_TI 3VA_TI C200 C199 C197 C184 C181 HCB1608KF-121T25 C178 C203 C201 C204 C186 C193 C177 C185 C171 C174 C198 pin#A6 pin#B17 pin#B24 pin#B40 pin#B44...

  • Page 81: Kbc-Ite It8518

    Schematic Diagrams KBC-ITE IT8518 KBC_AVDD VDD3 VDD3 HCB1005KF-121T20 RN25 MODEL_ID VDD3 2.2K_8P4R_04 VDD3 C493 C553 C296 C517 C551 SMC_BAT V1.0 W240HU C503 C502 C504 R498 SMD_BAT 0.1u_16V_Y5V_04 10u_10V_Y 5V_08 0.1u_16V_Y 5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 W250HUQ 0.1u_16V_Y 5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 100K_04 W270HUQ D02 0525 R4.3_5_24 D02 0525 R4.3_5_24 KBC_WRESET#...

  • Page 82: Led, Mdc, Power, Fan

    Schematic Diagrams LED, MDC, POWER, FAN FAN CONTROL FON# FON# 5VS_FAN VOUT CPU_FAN VSET MJ_MDC1 20 MIL *AX995B 1.5V FON# R183 *0_04 3.3V 5VS_FAN VOUT J_MDC1 CPU_FAN VSET 3.3V R184 0_04 RESERVED 10mil AX995SA HDA_SDO_MDC Azalia_SDO RESERVED 5VS_FAN 3.3V Main/aux J_FAN1 HDA_SYNC_MDC Azalia_SY NC...

  • Page 83: Audio Codec Alc269, Via1802

    Schematic Diagrams AUDIO CODEC ALC269, VIA1802 AUDIO CODEC R252 *0_04 ALC269 VB 1.5VS PVDD1_2 DVDD_IO Layout Note: VT1802P R256 0_04 R545 *28mil_06 Very close to Audio Codec 3.3VS_AUD C529 C528 C576 C572 10u_10V_Y5V_08 0.1u_16V_Y 5V_04 10u_10V_Y5V_08 0.1u_16V_Y5V_04 3.3VS 3.3VS_AUD ALC269 D02 0525 R4.3_5_24 VT1802P ? ? ? R542...

  • Page 84: Lid, Ap Key, Fp, Multi Con

    Schematic Diagrams LID, AP KEY, FP, MULTI CON FP CONN MULTI I/O CONN 3.3VS_FP 3.3VS J_FP1 HCB1608KF-121T25 J_FP1 USB_PP3 17 C164 USB_PN3 17 CCD_DET# C427 CCD_EN SPKOUTR+ 85201-04051L C163 SPKOUTR- 1u_6.3V_Y 5V_04 *1u_6.3V_Y5V_04 USB_PN5 USB_PP5 85205-08001 CCD USB PORT Sheet 33 of 49 LID, AP KEY, FP, LID SWITCH IC CLICK B'd CONN...

  • Page 85: 5Vs, 3Vs, 105Vs, 1.5Vs Cpu

    Schematic Diagrams 5VS, 3VS, 105VS, 1.5VS CPU SYS5V SYS5V VIN 1 SY S5V SY S5V PR188 PR192 PC190 PC 188 PC183 PR42 10K_04 10K_04 PR 41 DD_ON "L" TO 0. 1u_50V_Y 5V_06 0. 1u_50V_Y 5V_06 0.1u_50V_Y 5V_06 10K_04 "H" FROM EC DD_ON# SUSB 10K_04...

  • Page 86: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR197 *0_04 PR193 0_04 PC170 1u_10V_06 PR195 PR196 EN_3V EN_5V PC172 100K_04 100K_04 PC173 1000p_50V_X7R_04 1000p_50V_X7R_04 PU10 VREG3 PC192 PC193 PC174 PR200 *10K_04 4.7u_25V_X5R_08 4.7u_25V_X5R_08 VDD3 SY S5V VDD5 LDO3 1u_10V_06 PC196 PC194 PC195 PQ67 PC176 0.1u_10V_X7R_04 P1203BV...

  • Page 87: Power 1.5V/ 0.75V, 1.8Vs

    Schematic Diagrams POWER 1.5V/ 0.75V, 1.8VS PC154 PC150 PC148 PC155 G5616 / UP6163 PQ48 RB0540S2 MDU2657 1.5V PC46 VTT_MEM 10u_10V_Y 5V_08 VDDQ PC47 0.1u_10V_X7R_04 VLDOIN VBST PR182 VTT_MEM DRVH VDDQ 1.5V 3.3_06 *OPEN_2A 1.0UH_11.5*10.2*3.0 PJ18 PC42 PC45 PC40 VTTGND PR69 *OPEN_12A 0_06 VTTSNS...

  • Page 88: Power 1.05V Lan M

    Schematic Diagrams POWER 1.05V LAN M VDD5 VDD3 PJ12 1230 D02 PR121 *6mil RB0540S2 10K_04 PR152 8.2K_1%_04 PR122 0_04 PJ13 *6mil 15,34 PM_SLP_LAN# G5413 / UP6127 PQ38 PR123 *0_04 ME4894-G 1.05V_LAN_M PC112 PQ30 *0.1u_16V_Y5V_04 PC128 3,34,36 SUSB *MTN7002ZHS3 0.1u_16V_Y5V_04 V1.05 PJ16 1.05V_LAN_M PR131...

  • Page 89: Power 0.85Vs

    Schematic Diagrams POWER 0.85VS 3.3V PC111 0.022u_16V_X7R_04 PR129 10K_04 0.9V 0.8V 0.725V 0.675V 0.85VS_PWRGD 15 VCCSA_VID0 PR126 VCCSA_VID1 0_04 PR142 PR143 9.31K_1%_04 9.31K_1%_04 PR148 PR149 PR136 FOR EMI 100_04 RB0540S2 12K_1%_04 10K_1%_04 PR160 PR161 10K_1%_04 10K_1%_04 Sheet 38 of 49 0.85VS PQ29A PC110...

  • Page 90: Power V-Core1

    Schematic Diagrams Power V-CORE1 CSCOMP DROOP VR1_CSREF PR231 1.21K_1%_04 PC205 1000p_50V_X7R_04 CSCOMPA DROOPA CSNA PR112 PC97 PR232 1.21K_1%_04 PC206 1000p_50V_X7R_04 1.05VS_VTT 10_04 680p_50V_X7R_04 D02 0530 VCORE_1 PR111 PR108 1.21K_1%_04 B~4350 24.9K_1%_04 PUT COLSE PR35 PR37 PR60 PC96 TO VCORE 130_1%_04 *75_04 5600p_50V_X7R_04 A_GND...

  • Page 91: Power/ V-Core2, Vgfx

    Schematic Diagrams POWER/ V-CORE2, VGFX VCORE_2 PC87 PC91 PC89 PC88 PC90 D02 0530 PR19 PC95 PQ25 PQ24 2.2_06 MDU2657 *MDU2657 0.22u_10V_X7R_06 NCP5911 PR18 0_06 VREG_SW1_HG_R VREG_SW1_HG 0.36uH_12.9*14*3.8 VREG_SW1_OUT VCORE VR1_PWM1 VCORE PW M PQ26 PQ28 PQ27 PR25 MDU2654 MDU2654 *MDU2654 PC98 DRON 2K_1%_04...

  • Page 92: Ac In, Charger

    Schematic Diagrams AC IN, CHARGER PR 10 0_04 PR 9 * 470K_04 PQ23 VI N V_BAT MEP4435Q8 D02 0517 ? ? JBATTA1 J_D C-JACK1 PQ20 2DC -G213-B200 HCB4532K-800T90 MEP4435Q8 PQ22A D02 0524 PC67 PR 95 PD 1503Y VS PQ22B PR 5 0.

  • Page 93: Audio Board For T51

    Schematic Diagrams AUDIO BOARD FOR T51 USB PORT A_USBVCC A_USBVCC2 HCB1608KF-121T25 60 mil 60 mil 100u_6.3V_B2 0.1u_10V_X7R_04 AJ_USB1 AGND AUSB_PN8_R DATA_L AUSB_PP8_R *10mil_short DATA_H AUSB_PN8 AUSB_PP8 US04036BCA074 *WCM2012F2S-161T03 *10mil_short AGND AGND Sheet 42 of 49 AUDIO BOARD AUDIO JACK FOR T51 AJ_SPDIF1 AC11 0.01u_16V_X7R_04...

  • Page 94: Power Switch Board For M74

    Schematic Diagrams POWER SWITCH BOARD FOR M74 POWER SW & POWER LED FOR M74 POWER SM_3.3VS SWITCH POWER BUTTON 20mil SMSW1 SMR1 TJG-533-S-T/R /SFKQRMP2125T 220_04 SM_BTN# SM_3.3VS SMC1 20mil SMJ_SW1 20mil SJ_SW1 Sheet 43 of 49 *.1U_04 SM_BTN# SMGND POWER SWITCH SMD1 SMGND 85201-04051_L...

  • Page 95: External Odd Board For W76

    Schematic Diagrams EXTERNAL ODD BOARD FOR W76 ODD BOARD FOR W76 WJ_ODD1 WJ_ODD2 Sheet 44 of 49 WGND WGND EXTERNAL ODD W_5VS W_5VS BOARD FOR W76 202001-1 242003-1 WGND WGND GND1~2=WGND GND1~3=WGND W_5VS 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 WGND C237D91 C237D91 C67D67 C67D67 WGND WGND EXTERNAL ODD BOARD FOR W76 B - 45...

  • Page 96: Fingerprint Board For W86

    Schematic Diagrams FINGERPRINT BOARD FOR W86 FPJT1 FPU1 FREG_OUT FREF_OSC FBDRIVE1 FUSB_CONN FBDRIVE2 USB_CONNECT FAVDD FBEZEL1 FBDRIVE1 FXIN FBEZEL2 BDRIVE1 FXOUT FBDRIVE2 FMISO BDRIVE2 FMOSI FUSB_CONN FBEZEL1 FMCLK FPD_REG BEZEL1A The TESD_GND trace has to be wide (> 20mil) FMCS FNRESET FUSB_PN BEZEL1B...

  • Page 97: Click Finger Board For W35

    Schematic Diagrams CLICK FINGER BOARD FOR W35 C L I C K B O A R D F I N G E R B O A R D CJ_FPB1 CTREG_OUT CTREF_OSC CC13 0.1u_10V_X7R_04 CTBDRIVE1 RIGHT LIFT CTBDRIVE2 CSW1~4 CTAVDD CTBEZEL1 CTXIN CTBEZEL2 CTXOUT...

  • Page 98: Multi I/O Board For T51

    Schematic Diagrams Multi I/O Board for T51 M_5V M5V_CCD MULTI I/O CONN SPEAKER CONNECTOR MC10 1u_6.3V_X5R_04 1u_6.3V_Y5V_04 MGND MGND M_5V M5V_CCD AO3409 48 mil 48 mil M_5V HCB1005KF-121T20 0.2_06 0.2_06 MJ_SPK1 MJ_CCD1 MDD-SPKR+ FCM1005KF-121T03 MJ_FB1 0.1u_10V_X5R_04 D02 0518 MDD-SPKR- MCCD_DET# FCM1005KF-121T03 1u_6.3V_X5R_04 100K_04...

  • Page 99: Power Sequence

    Schematic Diagrams Power Sequence W350HU-D02 POWER ON SEQUENCE DD_ON ? ? ? D01 , ? ? ? D02 , ? ? ? (? 2ND Source) 1.029ms (980 us) (980 us) 1.719ms (1.59 ms) (1.54 ms) 3.3V 3.3V_M RSMRST# ACPRESENT (171 ms) (172 ms) 172.65ms(DD_ON)
  • Page 100 Schematic Diagrams Power Sequence 2 W350HU-D02 POWER ON SEQUENCE ? ? ? D01 , ? ? ? D02 , ? ? ? (? 2ND Source) 1.8VS (660 us) (1.17 ms) 1.33ms 1.8VS_PWRGD 1.33ms (660 us) (1.17 ms) 1.05VS_VTT_EN 982.us (1.06 ms) (2.04 1.05VS_VTT...

  • Page 101: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS ver- 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...
  • Page 102 BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
