CD PLAYER / USB SOUND SYSTEM CD5

Maintenance of Rubber Belt

Periodical maintenance or check is not required for a rubber belt used for all CEC belt-drive
CD transports and players. However, the tension of the belt may be lowered by using for years
which may result unstable reading of information on CD, noise during music reproduction
and/or jump of the music. The replacement of the belt may solve the problem if it comes from
weaker tension of the belt. If replacement of a belt does not solve the problem, consult with
the dealer that you have purchased. An average of the life of a belt is 5 years. It is not required
to replace if musc reproduction goes well even after 5 years.
Replacement of a rubber belt
No other rubber band than CEC original rubber belt can be used for replacement. Require
the CEC belt at the dealer that you have purchased.
❶ Remove the old belt.
❷ Mount a new belt to the groove under the CD-turntable through the clearance between
pick-up cover and CD-turntable.
❸ Then mount the belt to the motor pulley groove. Using a pair of tweezers would be easier
POWER SOURCE
to mount.
❹ Be sure the belt is installed at the grooves and the belt is not twisted. Twist of the belt
POWER SOURCE
can be corrected easily by using a pair of tweezers moving the center shaft by hand.

POWER SOURCE
pick-up cover motor pulley
side view
groove under CD-turntable
motor pulley groove
HEADPHONE VOLUME
side view
BELT DRIVE CD PLAYER CD5
HEADPHONE VOLUME
side view
BELT DRIVE CD PLAYER CD5
succeeded replacing the belt
HEADPHONE VOLUME
