Battery Installation - C.E.C. CD5 Owner's Manual

❽ Skip / button
Jump to the previous or next track.
❾ PLAY/PAUSE
Press to start playback or to pause playback temporarily.
❿ STOP button
Press to stop playback.
DIMM button
Press to change the display brightness in different 3 levels.
CD button
Press to enter the CD mode.
Music SOURCE (USB, COAX and TOS) buttons
Press to select an external music source USB, COAX or TOS.
DF (Digital Filter) button
Press to select a digital filter type FLAT or PULSE. Refer to "Digital Filter" on
page 16 for details.
Precaution on handling the remote control unit
▷ When operating the remote control, point it towards the remote sensor on the front
panel.
▷  M ake sure nothing is blocking the front panel where the remote sensor is located.
▷ Avoid exposing the remote sensor on the front panel to direct sunlight or other light
sources, as such exposure can cause malfunction.
▷ The remote control unit may malfunction when its batteries are running low. Change
the batteries to new ones of the same type if this seems to be the case.
▷ Upon shifting the input from CD to others or otherinputs to CD make sure to press
the key correctly to hear the click sound for switching. When you don't hear the
click sound, it is possible that selected music source could not be shown at display
window or brightness of display is not even upon using DIMM function. If this
happens, press again the same source button after moving the remote control hand
set correctly facing on display window.

Battery Installation

Remove the cover of the battery compartment. Insert the
supplied two AAA batteries into the compartment. Make
sure that the batteries are inserted with their positive (+)
and negative (-) poles positioned correctly, and put the
cover back on
Battery Replacement Period
If the distance at which the remote control unit can be used to operate CD5 seems to
be decreasing, replace both batteries with new ones.
Precaution on handling batteries
▷ Never use different types of batteries together. Both rechargeable and non-
rechargeable batteries can be used, but the two should not be used together.
▷ If you will not be using the remote control unit for an extended period of time (more
than a month), remove the batteries to prevent leakage.
▷ If the batteries leak, use a cloth to wipe away the liquid inside the battery
compartment and replace the batteries with new ones.
▷ Do not heat or disassemble batteries, and never dispose of old batteries by throwing
them in a fire. Dispose of batteries following laws in the local area.
/ button
CD5 User's Manual
15
