Printer setup

Note:
Be sure to set up the items in the
order listed in the table.
Installing a 2000-sheet
drawer
Warning:
If you have an optional
duplex unit and a 2000-sheet drawer, you
must install a 500-sheet drawer between
the duplex unit and the 2000-sheet
drawer.
Note:
You will install the power cord for
the 2000-sheet drawer later.
If you only purchased a base printer with no options, follow the directions under
"Positioning the printer" on page 13.
Use the following table to locate the instructions you need to set up your printer and any
paper handling options you may have purchased.
Topic

Installing a 2000-sheet drawer

Installing a 500-sheet drawer
Installing a duplex unit
Positioning the printer
Installing an output expander
Installing a 5-bin mailbox
Your printer supports one optional 2000-sheet drawer.
1
Unpack the 2000-sheet drawer and remove any packing material.
2
Place the drawer in the location you have chosen for your printer.
3
If you are installing a 500-sheet drawer on top of the 2000-sheet drawer, attach
the stabilizing bars:
a
Place the two stabilizing bars on the ground, narrow side up.
b
Lower the 2000-sheet drawer onto the bars, making sure you align the holes
in the drawer with the holes in the bars.
c
Screw the bars into place using four screws (two screws for each bar).
4
Adjust the four leveling feet on the bottom of the drawer, if necessary.
5
Continue with "Installing a 500-sheet drawer" on page 12 or "Positioning the
printer" on page 13.
Set up the printer and paper handling options
11
Go to page...
11
12
13
13
14
15
Leveling feet
