Service Manual

Microwave Oven

KOR-63350S
MODEL :
KOR-86350S
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : R63350S001
MAR. 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-63350S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo KOR-63350S

Summary of Contents for Daewoo KOR-63350S

  • Page 1: Microwave Oven

    : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD MAR. 2000 http : //svc.dwe.co.kr...

  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other microwave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse.

  • Page 3: Safety And Precautions

    SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) (1) A broken door hinge.

  • Page 4: Specifications

    SPECIFICATIONS MODEL KOR-6335 KOR-8635 230V ~ 50Hz, SINGLE PHASE WITH EARTHING POWER SUPPLY POWER MICROWAVE 1200W 1350W CONSUMPTION GRILL COMBINATION MICROWAVE ENERGY OUTPUT 800W 900W 2450MHz MICROWAVE FREQUENCY 465 x 279 x 365 mm 495 x 294 x 392 mm OUTSIDE DIMENSIONS(W X H X D) (18.3 x 11.0 x 14.4 in.) (19.5 x 11.6 x 15.4 in.)

  • Page 5: External View

    EXTERNAL VIEW 1. OUTER DIMENSION(KOR-6335/KOR-8635) 2. FEATURE DIAGRAM 1. Safety interlock system 2. Door viewing screen - Allows viewing of food. The screen is designed so that light can pass through, but not the microwave. 3. Door hook - When the door is closed, it will automatically shut. If the door is opened while the oven operating, the magnetron will immediately stop operating.

  • Page 6: Installation

    This appliance is supplied with cable of special type, which, if samaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a Qualified Person. 6. Examine the oven after unpacking for any damage such as: A misaligned door, broken door or a dent in cavity.

  • Page 7: Operations And Functions

    OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray must always be in place during cooking. 3.

  • Page 8: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safety during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 9 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly. NOTE After replacing the door assembly, perform a check of correct alignment with the hinge and cavity front plate. 3. To remove door parts. (1) KOR-63350S REF NO. PART CODE PART NAME DESCRIPTION Q’...
  • Page 10  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY (2) KOR-86350S REF NO.
  • Page 11 In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY 5. To remove control panel parts. (1) KOR-63350S REF NO. PART CODE PART NAME...
  • Page 12 DISASSEMBLY AND ASSEMBLY 1) Remove the screw which secure the control panel, push up two snap fits and draw forward the control panel assembly. 2) Remove the door open lever from thee control panel. 3) Remove two screws which secure the timer assembly. 4) Remove the timer assembly.
  • Page 13 DISASSEMBLY AND ASSEMBLY NOTE Never install the magnetron without the metallic gasket plate which is packed with each magnetron to prevent microwave leakage. Whenever repair work is carried out on magnetron, check the microwave leakage. It shall not exceed 4mW/cm for a fully assembled oven with door normally closed.

  • Page 14: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. (1) Primary interlock switch When the door is closed, the hook locks the oven door.

  • Page 15: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before checking trouble. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed.
  • Page 16 TROUBLE SHOOTING GUIDE Does the fan motor work when you shut the door and turn the timer? Does the oven lamp light? Replace or repair oven lamp, Does the turntable turn? turntable motor. Normal reading should be approx. 0Ω Continuity Replace high NO Continuity Check continuity filament...

  • Page 17: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000 5cc of potable water.

  • Page 18: Microwave Radiation Test

    MEASUREMENT AND TEST 2. MICROWAVE RADIATION TEST WARNING Make sure to check the microwave leakage before and after repair of adjustment. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. Care should be taken not to place the eyes in direct line with the source of microwave energy.

  • Page 19: Component Test Procedure

    MEASUREMENT AND TEST 3. COMPONENT TEST PROCEDURE High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. It is neither necessary nor advisable to attempt measurement of the high voltage. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor. 1.

  • Page 20: Wiring Diagram

    WIRING DIAGRAM...

  • Page 21: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY...
  • Page 22 In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST (1) KOR-63350S REF NO. PART CODE...
  • Page 23  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST REF NO.
  • Page 24  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST (2) KOR-86350S REF NO.

  • Page 25: Exploded View And Parts List

     Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST REF NO.
  • Page 26 DAEWOO ELECTRONICS CO., LTD 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX : DWELEC K28177-8 CABLE : “ DAEWOOELEC” FAX : 02)360-7877 TEL : 02)360-7804 E-mail : G7F00E@web.dwe.co.kr PRINTED DATE : MAR. 2000...
