KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 2
MICROWA VE OVEN
KOR-637V
OPERATING
INSTRUCTIONS
Before operating this oven, please read these instructions completely.

Advertisement

Table of Contents
loading

Related Manuals for Daewoo KOR-637V

Summary of Contents for Daewoo KOR-637V

  • Page 1 KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 2 MICROWA VE OVEN KOR-637V OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.

  • Page 2: Table Of Contents

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 1 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

  • Page 3: Important Safety Instructions

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 2 IMPORTANT SAFETY INSTRUCTIONS FOR MWO COOKING WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1.

  • Page 4: Earthing Instructions

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 3 EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug.

  • Page 5: Specifications

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 4 SPECIFICATIONS POWER SUPPLY 230V AC 50Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1200 W MICROWAVE OUTPUT POWER 800 W FREQUENCY 2450 MHz UV LAMP POWER CONSUMPTION 13 W OUTSIDE DIMENSIONS (W X H X D) 465 X 279 X 360 mm CAVITY DIMENSIONS (W X H X D) 290 X 220 X 306 mm...

  • Page 6: Important Safety Instructions For Sterilization

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 5 IMPORTANT SAFETY INSTRUCTIONS FOR STERILIZATION 1. Do not use the oven for the food. 2. Caution: Surface of utensil, tableware, etc., must be directly exposed to UV light for effective sterilization. The ultraviolet ray can’t penetrate through the materials such as glass, metal and plastic. 3.

  • Page 7: Features Diagram

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 6 FEATURES DIAGRAM 1 Safety interlock system-Prevents the oven 6 Shelf-Made of special heat registance plastic. from operating while the door is opened. The shelf can be easily removed for cleaning. The oven will only operate with the door fully The shelf must be placed on the glass cooking closed.
  • Page 8 KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 7 FEATURES DIAGRAM ( continued ) - KOR-637V KOR-637V DEF. LOCK STERIL AUTO COOK POWER/ CLOCK DEFROST 1. Dinner Plate STERILIZATION 2. Soup 3. Beverage 4. Fresh Vegetable STOP/CLEAR START/ EASY COOK q AUTO COOK- Used to cook using a program y STOP/CLEAR- Used to stop the oven or to reheat.

  • Page 9: Operation Procedure

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 8 OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 230V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.

  • Page 10: Controls

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 9 CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever turns off, the display shows “ :0” when the power comes back on. 1.

  • Page 11: Time Defrosting

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 10 TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Press POWER/DEFROST The DEF. indicator appears and “ : 0” is POWER/ button.

  • Page 12: Cooking In One Stage

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 11 COOKING IN ONE STAGE 1. Press POWER/DEFROST The M/W indicator appears and the display will POWER/ button. (Select the desired show what you selected. DEFROST power level.) This example shows power level 6. NOTE: If step 1 is omitted, the oven will cook at full power.

  • Page 13: Easy Cooking

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 12 EASY COOKING EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply pressing the EASY COOK button. By repeatedly pressing the EASY COOK button, you can also extend reheating time to 5 minutes by 30 seconds.

  • Page 14: Sterilization

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 13 STERILIZATION This function allow you to sterilize tableware. For proper sterilization, utensils and cookware must be properly cleaned/washed before sterilizing. Be repeatedly pressing STERILIZATION button, you can extend sterilizing time from 3 minutes to 30 minutes.

  • Page 15: Child Safety Lock

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 14 CHILD SAFETY LOCK SAFETY LOCK lock prevents unwanted oven operation such as by small children. To set, press and hold STOP/CLEAR button for 3 seconds, LOCK indicator appears and a beep sounds. To cancel, press and hold STOP/CLEAR button for 3 seconds, LOCK indicator disappears and a beep sounds.

  • Page 16: Cooking Utensils

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 15 COOKING UTENSILS Utensils should be checked to ensure that they are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy.

  • Page 17: Defrosting Frozen Foods Chart

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 16 DEFROSTING FROZEN FOODS CHART Item and Weight Defrosting Time Standing Time Special Techniques BEEF Break apart and remove thawed Mineed beef 10-12 min. 5-7 min. portions with fork. 454g (1 lb.) Stew Meat Separate and rearrange once.

  • Page 18: Cooking Chart

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 17 COOKING CHART MEAT ITEM POWER LEVEL COOKING TIMER PER 500g Beef Standing/rolled Rib - Rare P-80 9-11 min. - Medium P-80 10-12 min. - well done P-80 12-14 min. Ground Beef(to brown for casserole) P-HI 5-7 min.

  • Page 19: Reheating Chart

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 18 VEGETABLE ITEM POWER LEVEL PREPARATION QUANTITY COOKING TIME STANDING TIME asparagus, fresh P-HI 11/2-in.pieces 500g(1 lb.) 7-9 min. 3 min. asparagus, frozen P-HI Whole spears 280g(10 oz. pkg) 7-9 min. 3 min. broccoli, fresh P-HI Spears...
  • Page 20 KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 19 ITEM QUANTITY POWER LEVEL COOKING TIME SPECIAL INSTRUCTION 2 pieces P-HI 3-5 min. Arrange, on paper tower lined Fried chicken 4 pieces P-HI 4-6 min. paper plate, covered with paper 6 pieces P-HI 5-7 min.

  • Page 21: Before You Call For Service

    KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 20 BEFORE YOU CALL FOR SERVICE Refer to the following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2.
  • Page 22 KOR-637V0S(¿ ) 01.11.28 3:8 PM ˘ ` 21 QUESTIONS AND ANSWERS ( continued ) * Q : What does “standing time” mean? A : “Standing time” means that food should be removed from the oven and covered for additional time to allow it to finish cooking.
