MICROWA VE OVEN



OPERATING
INSTRUCTION


Before operating this oven, please read these instructions completely.
KOR-630A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-630A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo KOR-630A

Summary of Contents for Daewoo KOR-630A

  • Page 1  MICROWA VE OVEN    OPERATING INSTRUCTION   Before operating this oven, please read these instructions completely. KOR-630A...

  • Page 2: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

  • Page 3: Earthing Instructions

    EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed.

  • Page 4: Specifications

    SPECIFICATIONS POWER SUPPLY POWER CONSUMPTION MICROWAVE OUTPUT POWER FREQUENCY OUTSIDE DIMENSIONS (W X H X D) CAVITY DIMENSIONS (W X H X D) NET WEIGHT TIMER POWER LEVELS * Specifications are subject to change without notice. IMPORTANT The wires in this mains lead are coloured in accordance with the following code. Green-and-yellow Blue Brown...

  • Page 5: Important Safety Instructions

    14. Always test the temperature of food or drink which has been heated in a microwave oven before you give it to somebody, especially to children or elderly people. This is important because things which have been heated in a microwave oven carry on getting hotter even though the microwave oven cooking has stopped.

  • Page 6: Features Diagram

    FEATURES DIAGRAM 1 Door latch-When the door is closed it will automatically shut off. If the door is opened while the oven is operating, the magnetron will automatically shut off. 2 Door seal-The door seal maintains the microwave within the oven cavity and prevents microwave leakage 3 Oven cavity 4 Spatter shield-Protects the...
  • Page 7 FEATURES DIAGRAM 0 Time set pad-Used to set the cooking time and the present time. q Display-Cooking time, power level, indicators and present time are displayed. w One touch-used to cook or reheat specific quantities of food. e Auto Cook-Used to cook or reheat. r More-Used to add time to cooking.

  • Page 8: Operation Procedure

    OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 230~240V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.

  • Page 9: Controls

    CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever goes off, the display shows “ :0” when the power comes back on. 1.

  • Page 10: Weight Defrosting

    WEIGHT DEFROSTING Auto Defrost lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. MEAT 2. Select the desired defrosting weight. (Refer to the weight defrost chart below.) 3.

  • Page 11: Cooking In One Stage

    COOKING IN ONE STAGE 1. Touch POWER pad. (Select the desired power level.) POWER 2. Touch the time set pads for the cooking time. 3. Touch START pad. When you touch START pad, the M/W indicator starts blinking to show the oven is cooking. The display counts down the time to show how much cooking time is left.

  • Page 12: Kitchen Timer Mode

    KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking.However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1.

  • Page 13: Easy Cook

    EASY COOK EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the EASY COOK pad. By repeatedly touching the EASY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments.

  • Page 14: Auto Cook

    ONE TOUCH COOKING 1. Touch DISH WARMER pad DISH once for 350g or twice for WARMER 450g. * DISH WARMER * • 350 g : Touch DISH WARMER once. • 450 g : Touch DISH WARMER twice within 1.5 seconds. NOTE: 1 Put food on microwave plate.

  • Page 15: Less, More

    2. Touch START pad. START LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE. (except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 second. The overall one touch cooking time can be increased to a maximum of 59 minutes 50 seconds.

  • Page 16: Cooking Utensils

    As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them. 1. Dishes with metal trim of any type-should not be used. This will cause sparking.

  • Page 17: Before You Call For Service

    * Q : Why do I have moisture in my microwave oven after cooking? A : The moisture on the side of your microwave oven is normal. It is caused by steam form cooking food hitting the cool oven surface.
