2000-Sheet Drawer User's Guide
10
Pull each locking pin up to unlock it, and then pull up on the
guides to remove them.
Locking pins
Color-coded slots
(bottom)
11
Reposition the paper guides in the color-coded slots,
located at the top of the unit, corresponding to the paper
size you selected.
12
Insert the paper guides into the matching colored slots
located on the inside bottom of the unit. The guides should
now be seated flush against the top of the unit.
13
Push each pin down to lock the guides in place.
Back guide
Side guides
Color-coded slots
(top)
