Parts & Maintenance
Manual
R-311
™
Rotary Mower with folding ROPS
69166 – Kubota
69167 – Kubota
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers, and should read the entire manual before attempting to set up,
operate, adjust, or service the machine.
GB
®
V2203-M
®
V2203-M EC
WARNING
4192121-Rev C
6
5
9
1 1
1 6
1 5
1 3
7
8
1 8
1 7
1 - I N C L U D E S I T E M S 3 - 1 6
1 9
3
4
1 0
