- Page 1 PX/QX/RX Version 4.20 User Manual Issue B...
-
Page 2: Table Of Contents
PX/QX/RX Version 4.20 User Manual – Issue B Contents CONTENTS ................................2 INTRODUCTION ..............................5 ................................. 5 VENT & S ............................5 REAS ROUPS ................................5 IRCUITS ....................5 ET GROUP AND IRCUIT DENTIFICATION ................................ 6 ODES OPERATOR CONTROLS AND DISPLAYS....................6 ............................... - Page 3 PX/QX/RX Version 4.20 User Manual – Issue B Level ................................22 ................................. 22 CHEDULE (PX O )............................23 OCKOUT (PX O )..........................23 XPIRY TEL NUMBER ..............................23 LOGS................................... 24 TIME ................................... 24 HOLIDAY ................................25 SCHEDULE ................................ 25 GROUP TEXT..............................25 MINUTES LEFT (PX250HS ONLY) .......................
- Page 4 PX/QX/RX Version 4.20 User Manual – Issue B APPENDIX E - LOG ON MESSAGES......................40 APPENDIX F – AUDIO COMMANDS ......................41 APPENDIX G - SYSTEM DETAILS ....................... 42 ................................42 EYPADS ..............................42 ROUPS ................................43 IRCUITS ................................44 SERS - 4 -...
-
Page 5: Introduction
The RX16i variant does not include the set group feature. If using a RX16i then all references to set groups throughout this manual should be interpreted as areas. -
Page 6: User Codes
A user PIN code can be replaced by a card or fob if the keypad is fitted with the optional internal or external reader. All Guardall proximity cards and fobs are manufactured with a unique code and duplicate cards or fobs cannot be obtained. Spare or replacement cards or fobs can be obtained from the installation company. -
Page 7: Dual User Code Operation
The LCD keypad will normally display the time, date and company name. If a valid code is entered the user menu will normally be displayed. The default manager code is 0202 . Enter this code followed by button to log on. 12:00 Mon 27 Sep user token on mini keypad Guardall 02=Set =Confirm Unset 04=Test LogOff... -
Page 8: Easy Set
04=Test 0=Assist 1=Contract 2=Product Info Assist Assist-1 Number _ =Dial Service not available You will now be logged off and the system will now connect to entered number the remote service centre. 12:00 Mon 27 Sep Guardall - 8 -... -
Page 9: Incorrect Codes
Out of Service for a period of 5 minutes. Any attempt to enter a user code during the locked out period will extend the period by another 5 minutes. 12:00 Mon 27 Sep Guardall 5 Min. Delay... -
Page 10: Set
1. A user request on a keypad 2. A user activating a keyswitch or radio Keyfob 3. Automatically by a timer schedule 4. Remotely from a PC using the Guardall GuardStation software 5. A user request on an ACM Proximity Reader. Setting modes include: 1. -
Page 11: Keyswitch/Radio Keyfob Setting
PX/QX/RX Version 4.20 User Manual – Issue B Keyswitch/Radio Keyfob Setting As an alternative to setting and unsetting from a keypad, your system may be fitted with an optional keyswitch, which permits setting and unsetting of a group by operating a keyswitch. The keyswitch may be configured for any set mode. -
Page 12: Setting Restrictions
PX/QX/RX Version 4.20 User Manual – Issue B Setting Restrictions 1. The selected group is programmed with a set level and a lower level set group(s) has not been set. 2. If a user attempts to set a high level set group when a lower level is not set then a warning message will be displayed. -
Page 13: Dual Set (Px250Hs Only)
Dual Set (PX250HS Only) 12:00 Mon 27 Sep In the example the vault area is programmed for dual Guardall user set. The first user code is 0202 and the second user code is 1234. Both users must have the authority to set the vault area. -
Page 14: Unset
2. A user activating a keyswitch or radio Keyfob 3. Automatically by a timer schedule 4. Remotely from a PC using the Guardall GuardStation software 5. A user request on an ACM Proximity Reader. Your installation engineer should advise which of the above options have been programmed on your system. -
Page 15: Automatic Unsetting
PX/QX/RX Version 4.20 User Manual – Issue B Automatic Unsetting The system may have been programmed by the installation engineer to automatically unset all or parts of the system according to a pre-programmed schedule. The schedule will have been programmed to take into account the normal opening time, non-working days and holidays. Unsetting Warnings When unsetting from a keypad, the user is informed on the display of any warnings, e.g. -
Page 16: Unset Delay (Px250Hs Only)
PX/QX/RX Version 4.20 User Manual – Issue B Unset Delay (PX250HS Only) 12:00 Mon 27 Sep Guardall 12:00 Mon 27 Sep Enter- **** 01=Unset 04=Test In the example the vault area is programmed with an 1=Vault unset delay. The unset delay time is programmed by 2=Office the installation engineer. -
Page 17: Reset
You will be issued with a special 6-digit PIN code. This PIN code can be used only once to reset the system. Logon to the keypad with this PIN code to clear the engineer reset condition. 12:00 Mon 27 Sep Guardall reset code + 12:00 Mon 27 Sep Enter- *****... -
Page 18: Test
PX/QX/RX Version 4.20 User Manual – Issue B Code-04 Test Each area of the system can be tested individually or all areas can be tested at the same time. The test time is limited to 1 hour. If the user does not end the test by the end of the test time then the panel will exit test mode automatically. -
Page 19: Engineer
PIN code to be entered. 05=Engineer When an engineer logs on to a keypad, all other Engineer keypads in the system will be inoperable and the Guardall display will show Out of Service . or time out (2 minutes) 12:00 Mon 27 Sep Guardall Once logged on the engineer working time is limited to 8 hours. -
Page 20: User
PX/QX/RX Version 4.20 User Manual – Issue B Code-07 User Any master user can change the name, user code and authority for any user except the engineer. To modify a user’s details enter the user number in the range 2-max users. In the programming example user 3 is used. -
Page 21: Card
PX/QX/RX Version 4.20 User Manual – Issue B User Menu Code-3 Card The procedure for adding a card is similar to adding a new PIN. Present the new card to reader when prompted to do so. Alternatively, if the card number is known, it can be entered on the keypad. The maximum number of card digits, excluding the optional site ID, is 8 digits User Menu Code-4... -
Page 22: Acm Authority (Px Only)
PX/QX/RX Version 4.20 User Manual – Issue B User Menu Code-5 ACM Authority (PX Only) This option will only be available if at least one ACM is fitted to the system. Option Range Description Enable On/Off If this option is off no further user ACM options will be displayed in this menu. -
Page 23: Lockout (Px Only)
PX/QX/RX Version 4.20 User Manual – Issue B User Menu Code-7 Lockout (PX Only) This option will only be available if at least one ACM is fitted to the system. If the lockout option is on for a user then the user code will be ignored until the lockout is turned off. User Menu Code-8 Expiry Date (PX Only) -
Page 24: Logs
PX/QX/RX Version 4.20 User Manual – Issue B Logs The panel logs all events that occur in the system. All events stored in the event log are numbered in the range 0-65535 (the event index). The event index will be reset to 0 when more than 65535 events have been recorded. -
Page 25: Holiday
PX/QX/RX Version 4.20 User Manual – Issue B Code-24 Holiday The programmed holidays are used in conjunction with the programmable schedules. The holiday date format is day and month only. No year is entered therefore the entered date will remain programmed as a holiday for all years, or until it is removed from the holiday schedule. -
Page 26: Minutes Left (Px250Hs Only)
PX/QX/RX Version 4.20 User Manual – Issue B Code-27 Minutes Left (PX250HS Only) This option is only available to an ATM user. When an ATM user code and a non-zero ATM delay period is programmed then a delay prompt will be displayed when the ATM user code is first entered. 27=Minutes left 01=ATM 1 The actual unset menu... -
Page 27: Bypass
PX/QX/RX Version 4.20 User Manual – Issue B Code-30 Bypass The bypass option will only be available if a circuit(s) has been programmed as bypassable by the installation engineer. The bypass circuit option allows the user to bypass a circuit that is in a fault condition. -
Page 28: Shunt
PX/QX/RX Version 4.20 User Manual – Issue B Code-33 Shunt A manager or ordinary user can be programmed with the shunt option. The shunt option will only be displayed if there are shuntable circuits in the user authorised areas. Shunted circuits may be viewed at any time using option 89 (Cct Status). -
Page 29: Copy User
PX/QX/RX Version 4.20 User Manual – Issue B Code-71 Copy User 71=Copy User Enter the user to copy here. Copy User ___ Enter the first and last user ___-___ in the copy range here. To copy a single user, enter the same user number as the first and last. Code-73 Copy A/User (PX Only) This option will only be available if at least one ACM is fitted to the system. -
Page 30: Access Features (Px Only)
The PX access control system can be configured through a security system keypad or a PC running GuardStation™ Access. Guardall PX proximity cards or fobs may only be introduced to the system through a PX keypad with an integrated proximity reader. -
Page 31: Delete User
PX/QX/RX Version 4.20 User Manual – Issue B Code-51 Delete User This option will only be available if at least one ACM is fitted to the system. In the example shown user 3 is deleted from the system. 51=Delete Users Delete Users Enter the range of users to delete. -
Page 32: Door Lockout
PX/QX/RX Version 4.20 User Manual – Issue B Code-54 Door Lockout This option will only be available if at least one ACM is fitted to the system. The locked out ACM door will remain locked and will refuse all access attempts until the lockout is removed. The ACM door lockout can only be removed through this programming option. -
Page 33: Appendix A - User Authorities
PX/QX/RX Version 4.20 User Manual – Issue B Appendix A – User Authorities All user options with the appropriate authority level are shown in the table. Code Menu Option Unset Reset Test Engineer Code User Tel Number Log-Full Log-Cct Log-User Log-KP Log-Date Log-Alarm... -
Page 34: Appendix B - Editing Text
PX/QX/RX Version 4.20 User Manual – Issue B Appendix B – Editing Text A number of text descriptors may be changed by an authorised user. All changes to descriptors are logged. Item Max. Length Default User User xx Set group Group x Access control module ACM x... -
Page 35: Appendix C - Log Messages
PX/QX/RX Version 4.20 User Manual – Issue B Appendix C - Log Messages Alarm & Event Log messages Log Text Additional Data Display Text Event Description 230v Fault NONE (see note) NONE Mains supply failed 230v OK NONE (see note) NONE Mains supply restored A/Set Fault... - Page 36 PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Det Test Fail Usnn, Area m Usnn, Am One or more detector test circuits failed Det Test OK Usnn, Area m Usnn, Am All detector test circuits tested Det.Test Fail...
- Page 37 PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Isolate User nn, Keypad m Usnn, KPm Keypad isolated by user Isolate User nn, RMm Usnn, RMm Radio module isolated by user Jamming Radio module number RM nn Receiver jammed...
-
Page 38: Appendix C - Access Log Messages
PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Sndr Tamper NONE NONE Panel sounder tamper Soak Alarm Circuit nnn Cctnnn A circuit on soak test has alarmed Soak Failed Circuit nnn Cctnnn... -
Page 39: Appendix E - Menu Restrictions
PX/QX/RX Version 4.20 User Manual – Issue B Appendix E - Menu Restrictions If a menu number is entered and the option is not available, then a reason will be displayed. For example if no area is set and you select unset the panel will prompt with the reason the unset option is not available. -
Page 40: Appendix E - Log On Messages
PX/QX/RX Version 4.20 User Manual – Issue B Appendix E - Log On Messages When a user logs on, the system may display a special message(s) before the normal menu is displayed. The special messages are shown in the table. Message Reason Alarm Abort... -
Page 41: Appendix F – Audio Commands
PX/QX/RX Version 4.20 User Manual – Issue B Appendix F – Audio Commands This section only applies to systems that are fitted with an audio bus or a speech module. The speech and audio functions of the system by using a DTMF telephone handset. To use an audio or speech function: 1. -
Page 42: Appendix G - System Details
PX/QX/RX Version 4.20 User Manual – Issue B Appendix G - System Details Number of Areas Number of keypads Number of Circuits Number of Users Service Number Contract Number Keypads Number Location Set Groups Number Description Areas - 42 -... - Page 43 PX/QX/RX Version 4.20 User Manual – Issue B Circuits Number Description Location Cct 1 Cct 2 Cct 3 Cct 4 Cct 5 Cct 6 Cct 7 Cct 8 Cct 9 Cct 10 Cct 11 Cct 12 Cct 13 Cct 14 Cct 15 Cct 16 Cct 17...
- Page 44 PX/QX/RX Version 4.20 User Manual – Issue B Number Description Location Cct 28 Cct 29 Cct 30 Cct 31 Cct 32 Cct 33 Cct 34 Users Number Description Areas - 44 -...
- Page 46 Guardall Limited Lochend Industrial Estate Newbridge Edinburgh EH28 8PL Tel: 0131-333-2900 FAX: 0131-333-4919 Technical Hotline: 0131-333-3802 Part Number: 320995-0B...
