PX/QX/RX Version 4.20 User Manual – Issue B Contents CONTENTS ................................2 INTRODUCTION ..............................5 ................................. 5 VENT & S ............................5 REAS ROUPS ................................5 IRCUITS ....................5 ET GROUP AND IRCUIT DENTIFICATION ................................ 6 ODES OPERATOR CONTROLS AND DISPLAYS ....................6 ...............................
Page 3
SHUNT ................................28 PRINT TEXT ..............................28 PRINT HOLS..............................28 IDENTIFY USER ............................... 28 COPY USER ............................... 29 COPY A/USER (PX ONLY)..........................29 CCT STATUS ..............................29 ACCESS FEATURES (PX ONLY)........................30 ADD A/USER ..............................30 DELETE USER ..............................31 DOOR UNLOCK..............................
Page 4
PX/QX/RX Version 4.20 User Manual – Issue B APPENDIX E - LOG ON MESSAGES ......................40 APPENDIX F – AUDIO COMMANDS......................41 APPENDIX G - SYSTEM DETAILS........................ 42 ................................42 EYPADS ..............................42 ROUPS ................................43 IRCUITS ................................44 SERS...
Version 4.20 User Manual – Issue B Introduction The PX Electronic Intruder Alarm System is designed to provide secure protection for the installation. The system comprises a main control panel, normally located out of sight in a secure area, and at least one keypad.
A user PIN code can be replaced by a card or fob if the keypad is fitted with the optional internal or external reader. All Guardall proximity cards and fobs are manufactured with a unique code and duplicate cards or fobs cannot be obtained. Spare or replacement cards or fobs can be obtained from the installation company.
PX/QX/RX Version 4.20 User Manual – Issue B Dual User Code Operation Where a higher level of security is required a keypad may have been programmed to require two user codes to be entered before logging a user on to the system. Both user codes must be authorised and are logged by the system.
PX/QX/RX Version 4.20 User Manual – Issue B Easy Set If your system is programmed with the easy set option then all PIN codes are 4 digits long and PIN codes can be entered without confirming with the button. A card or fob may still be used in place of a PIN when easy set is programmed.
PX/QX/RX Version 4.20 User Manual – Issue B Incorrect Codes If Easy Set is not programmed and an incorrect user code is entered, the incorrect code message will be displayed for a few seconds or until another key is pressed. The installation engineer will have programmed a limit on the number of incorrect code attempts that can be made.
1. A user request on a keypad 2. A user activating a keyswitch or radio Keyfob 3. Automatically by a timer schedule 4. Remotely from a PC using the Guardall GuardStation software 5. A user request on an ACM Proximity Reader. Setting modes include: 1.
PX/QX/RX Version 4.20 User Manual – Issue B Keyswitch/Radio Keyfob Setting As an alternative to setting and unsetting from a keypad, your system may be fitted with an optional keyswitch, which permits setting and unsetting of a group by operating a keyswitch. The keyswitch may be configured for any set mode.
PX/QX/RX Version 4.20 User Manual – Issue B Setting Restrictions The selected group is programmed with a set level and a lower level set group(s) has not been Met opmaak: set. opsommingstekens en nummering If a user attempts to set a high level set group when a lower level is not set then a warning message will be displayed.
PX/QX/RX Version 4.20 User Manual – Issue B Dual Set (PX250HS Only) 12:00 Mon 27 Sep In the example the vault area is programmed for dual Guardall user set. The first user code is 0202 and the second user code is 1234. Both users must have the authority to set the vault area.
2. A user activating a keyswitch or radio Keyfob 3. Automatically by a timer schedule 4. Remotely from a PC using the Guardall GuardStation software 5. A user request on an ACM Proximity Reader. Your installation engineer should advise which of the above options have been programmed on your system.
PX/QX/RX Version 4.20 User Manual – Issue B Automatic Unsetting The system may have been programmed by the installation engineer to automatically unset all or parts of the system according to a pre-programmed schedule. The schedule will have been programmed to take into account the normal opening time, non-working days and holidays.
PX/QX/RX Version 4.20 User Manual – Issue B Unset Delay (PX250HS Only) 12:00 Mon 27 Sep Guardall 12:00 Mon 27 Sep Enter- **** 01=Unset 04=Test In the example the vault area is programmed with an 1=Vault unset delay. The unset delay time is programmed by 2=Office the installation engineer.
PX/QX/RX Version 4.20 User Manual – Issue B Code-03 Reset The resetting method programmed by the alarm company engineer for each area and the system will depend on the particular security requirements of the area or system. There are 3 types of reset: 1.
PX/QX/RX Version 4.20 User Manual – Issue B Code-04 Test Each area of the system can be tested individually or all areas can be tested at the same time. The test time is limited to 1 hour. If the user does not end the test by the end of the test time then the panel will exit test mode automatically.
PX/QX/RX Version 4.20 User Manual – Issue B Code-05 Engineer The Eng option will only be available if the system is configured for user authorised engineer access. This option applies to both local and remote engineer access. When the Eng option is selected the system will prompt for the engineer PIN code to be entered.
PX/QX/RX Version 4.20 User Manual – Issue B Code-07 User Any master user can change the name, user code and authority for any user except the engineer. To modify a user’s details enter the user number in the range 2-max users. In the programming example user 3 is used.
PX/QX/RX Version 4.20 User Manual – Issue B User Menu Code-3 Card The procedure for adding a card is similar to adding a new PIN. Present the new card to reader when prompted to do so. Alternatively, if the card number is known, it can be entered on the keypad. The...
PX/QX/RX Version 4.20 User Manual – Issue B User Menu Code-5 ACM Authority (PX Only) This option will only be available if at least one ACM is fitted to the system. Option Range Description Enable On/Off If this option is off no further user ACM options will be displayed in this menu.
This option will only be available if at least one ACM is fitted to the system. If the lockout option is on for a user then the user code will be ignored until the lockout is turned off. User Menu Code-8 Expiry Date (PX Only) Expiry dates can be programmed for all users (panel and access users). 1=Name Expiry Date...
PX/QX/RX Version 4.20 User Manual – Issue B Logs The panel logs all events that occur in the system. All events stored in the event log are numbered in the range 0-65535 (the event index). The event index will be reset to 0 when more than 65535 events have been recorded.
PX/QX/RX Version 4.20 User Manual – Issue B Code-24 Holiday The programmed holidays are used in conjunction with the programmable schedules. The holiday date format is day and month only. No year is entered therefore the entered date will remain programmed as a holiday for all years, or until it is removed from the holiday schedule.
PX/QX/RX Version 4.20 User Manual – Issue B Code-27 Minutes Left (PX250HS Only) This option is only available to an ATM user. When an ATM user code and a non-zero ATM delay period is programmed then a delay prompt will be displayed when the ATM user code is first entered.
PX/QX/RX Version 4.20 User Manual – Issue B Code-30 Bypass The bypass option will only be available if a circuit(s) has been programmed as bypassable by the installation engineer. The bypass circuit option allows the user to bypass a circuit that is in a fault condition.
PX/QX/RX Version 4.20 User Manual – Issue B Code-33 Shunt A manager or ordinary user can be programmed with the shunt option. The shunt option will only be displayed if there are shuntable circuits in the user authorised areas. Shunted circuits may be viewed at any time using option 89 (Cct Status).
To copy a single user, enter the same user number as the first and last. Code-73 Copy A/User (PX Only) This option will only be available if at least one ACM is fitted to the system. 73=Copy A/User Enter the user to copy here.
Set & unset Note: The panel users must be the first users in the system. For example on the PX 500 users 2-200 may be access or panel users, users 201-1000 can only be access users and user 1 is always the engineer.
PX/QX/RX Version 4.20 User Manual – Issue B Code-51 Delete User This option will only be available if at least one ACM is fitted to the system. In the example shown user 3 is deleted from the system. 51=Delete Users Delete Users Enter the range of users to delete.
PX/QX/RX Version 4.20 User Manual – Issue B Code-54 Door Lockout This option will only be available if at least one ACM is fitted to the system. The locked out ACM door will remain locked and will refuse all access attempts until the lockout is removed. The ACM door lockout can only be removed through this programming option.
PX/QX/RX Version 4.20 User Manual – Issue B Appendix A – User Authorities All user options with the appropriate authority level are shown in the table. Code Menu Option Unset Reset Test Engineer Code User Tel Number Log-Full Log-Cct Log-User...
PX/QX/RX Version 4.20 User Manual – Issue B Appendix B – Editing Text A number of text descriptors may be changed by an authorised user. All changes to descriptors are logged. Item Max. Length Default User User xx Set group...
PX/QX/RX Version 4.20 User Manual – Issue B Appendix C - Log Messages Alarm & Event Log messages Log Text Additional Data Display Text Event Description 230v Fault NONE (see note) NONE Mains supply failed 230v OK NONE (see note)
Page 36
PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Det Test Fail Us nn , Area m Us nn , A m One or more detector test circuits failed...
Page 37
PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Isolate User nn , RM m Us nn , RM m Radio module isolated by user Jamming Radio module number RM nn...
PX/QX/RX Version 4.20 User Manual – Issue B Alarm & Event Log messages Log Text Additional Data Display Text Event Description Soak Alarm Circuit nnn Cct nnn A circuit on soak test has alarmed Soak Failed Circuit nnn Cct nnn...
PX/QX/RX Version 4.20 User Manual – Issue B Appendix E - Menu Restrictions If a menu number is entered and the option is not available, then a reason will be displayed. For example if no area is set and you select unset the panel will prompt with the reason the unset option is not available.
PX/QX/RX Version 4.20 User Manual – Issue B Appendix E - Log On Messages When a user logs on, the system may display a special message(s) before the normal menu is displayed. The special messages are shown in the table.
PX/QX/RX Version 4.20 User Manual – Issue B Appendix F – Audio Commands This section only applies to systems that are fitted with an audio bus or a speech module. The speech and audio functions of the system by using a DTMF telephone handset. To use an audio or speech function: 1.
PX/QX/RX Version 4.20 User Manual – Issue B Appendix G - System Details Number of Areas Number of keypads Number of Circuits Number of Users Service Number Contract Number Keypads Number Location Set Groups Number Description Areas - 42 -...
