CHAPTER 14
Content Management Application (CMA)
You can automatically assign DMX values to all folders at once or to all the files within a folder
at once. You cannot set both files and folder values at the same time. To automatically assign
DMX values to all the User content folders or all files within a User content folder:
1. Display the User content folders or the files for a single folder in the right pane of the
Content Management window and deselect all files or folders.
2. Select Autoset All DMX from either the Media Folders or 3D Objects drop down menu
or the right click popup list. The CMA will assign a valid DMX value to all selected files or
folders.
Using the same steps, you can also Reset DMX for a single file or folder or Reset All DMX for
all display files or folders displayed in the right pane to zero.

Editing User Content DMX Values

You can manually assign any valid DMX value to your files or folders by selecting the file or
folder in the right pane and then, using the pull down menu or the right click popup, selecting
Edit DMX. A dialog box will allow you to input the DMX value. If it is a valid value from
0-255, the CMA will change the DMX value displayed for the file or folder.

Valid DMX Values

Certain DMX values are Reserved for special purposes and are not user assignable
change the assigned DMX value for a User Content item to another valid DMX value. A valid
DMX value is:
• From 0-255
• Is not one of the reserved values for that type of content
• Is unique from other content of it's type except for zero
The following table shows valid and reserved values for User Content.
Content Type
Media Folders
(media file collections)
Media Files
Objects
134
DMX Values
0
1-40
41-239
240-254
255 Internal Camera video feed
0
1-255
0
1-149
150-255
Description
No Selection
Default Stock media
User collections
Reserved
No Selection
Media files
No selection
Stock 3D Objects
User 3D Objects
You can
.
Reserved?
No
Yes
No
Yes
Yes
No
No
No
Yes
No
