RGB Invert and Swap to GBR

Effect Mode parameter DMX value = 18
This option swaps the color values from RGB to an inverted GBR color model.
Modifier 1: Transitions the red component from no adjustment at a value of 0 to magenta at a
value of 255 (100%)
Modifier 2: Transitions the green component from no adjustment at a value of 0 to yellow at a
value of 255 (100%)
Modifier 3: Transitions the blue component from no adjustment at a value of 0 to cyan at a
value of 255 (100%)

RGB Scale

Effect Mode parameter DMX value = 47
Reduce and increase color components in the image as a part of the overall color range.
Note: the maximum of Mod1, Mod2 and Mod3 sets overall color range.
Modifier 1: Scales Red in the Media file. A DMX Value of 128 = no adjustment. DMX values
below 128 (50%) reduce color value. DMX values over 128 increase color value.
Modifier 2: Scales Green in the Media file. A DMX Value of 128 = no adjustment. DMX values
below 128 (50%) reduce color value. DMX values over 128 increase color value.
Modifier 3: Scales Blue in the Media file. A DMX Value of 128 = no adjustment. DMX values
below 128 (50%) reduce color value. DMX values over 128 increase color value.

RGB Swap to BGR

Effect Mode parameter DMX value = 41
This option allows you to swap colors. All red values become green and all blue values become
red. Green values are unaffacted.
Modifier 1: Transitions red color component to blue from 0 = no color change to
255 (100%) = green
Modifier 2: No change to green color component
Modifier 3: Transitions blue color component to green from 0 = no color change to
255 (100%) = red
DL.2 User Manual
CHAPTER 11
Effect Mode Options Descriptions
Object Effect Global Effect
Object Effect Global Effect
Object Effect Global Effect
101
