- Page 1 AW5810HTA AW5810HTS AW5810HTP-PAIR USER’S MANUAL 5.8 GHz Outdoor 10 Mbps Wireless Ethernet Radios AvaLAN Industrial-grade, long-range wireless Ethernet systems...
- Page 2 • (1) AW-POE18i Power over Ethernet Injector with integrated power supply The AW5810HTA serves as an Access Point in point-to-multipoint wireless networks and has a 9 dBi omnidirectional antenna. Each AW5810HTA Access Point can support multiple AW5810HTS Subscriber Units. This product includes: •...
-
Page 3: Operational Summary
(AP). Several AW5810HTS clients or subscriber units (SU) may be pointed toward the AW5810HTA. All the radios in the network must share common SSIDs and encryption keys. The AP is configured for a particular RF channel and the SUs locate and switch to this same frequency. -
Page 4: Physical Setup
“DATA IN” port on the POE. Connect a second cable from the “P + DATA OUT” port on the POE and the AvaLAN radio. Each radio is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through and can be tightened down around the cable to provide a weatherproof seal. - Page 5 5. If your login is successful, you should see a status window similar to this: The web server software built in to your AvaLAN radio is shared with other product configurations. There are some features of the interface that are not used and even...
- Page 6 AW5810HTA,HTS,HTP-PAIR User’s Manual 6. Main Menu: The menu at the left side of the browser window chooses among major sections of the interface: • Wireless - This page is where most of the status checking and confguration is done. • IP Addressing > Set IP/subnet - This page is where the IP address and subnet mask may be changed.
- Page 7 Recovery can be a time-consuming process and will require the help of AvaLAN Technical Support. If you are changing parameters over the RF link (we do not rec- ommend this), be sure to make the remote changes first because the link will be broken if the SSIDs or Security Pass Phrases do not agree.
- Page 8 AW5810HTA,HTS,HTP-PAIR User’s Manual profiles available. • Click in the “WPA2-AES-PSK2” row to bring up a page that shows the Pre- Shared Key and provides a text box to change it. You may want to toggle the “Hide Passwords” button at the top of the browser window to make the Key text visible.
- Page 9 AW5810HTA,HTS,HTP-PAIR Viewing Status Information After configuring your AvaLAN radios and establishing links among them, you can use the browser interface to view status and troubleshooting Information. Choose “Wireless” from the Main Menu at the left side of the window. The “Wireless Tables”...
- Page 10 AW5810HTA,HTS,HTP-PAIR User’s Manual 3. Security Profiles Tab: There are two security profiles available. “WPA2-AES-PSK2” is 256-bit encryption using a pre-shared key. “default” is open and unencrypted. Clicking on the “WPA2- AES-PSK2” line brings up a screen where the pre-shared key may be viewed and changed.
- Page 11 User’s Manual AW5810HTA,HTS,HTP-PAIR This page displays the current RF frequency, the SSID, the Security Profile in use, current transmission rates, amount of data sent and received since last reboot, drops and errors. Also shown are graphs of megabits per second and packets per second during the last three minutes or so.
-
Page 12: Frequency Channels
This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product.
