- Page 1 AW900xTR-INTL USER’S MANUAL 915 MHz Outdoor Wireless Ethernet Radio AvaLAN Industrial-grade, long-range wireless Ethernet systems...
- Page 2 AW900XTR-INTL User’s Manual Thank you for your purchase of the AW900xTR-INTL Outdoor Wireless Ethernet Radio. The AW900xTR-INTL includes: • (1) Wireless transceiver in weatherproof die-cast aluminum package • (1) AW2-900 Flexible Antenna • (1) 120 VAC to 12 VDC power adapter • (1) AW-POE Power Over Ethernet Injector...
-
Page 3: Operational Summary
AW900xTR-INTL and AW900xTP-INTL radios. (Please note that older AvaLAN 900 MHz radios can exist on the same LAN but cannot be used to form wireless links with the AW900xTR/xTP-INTL units because link encryption protocols have changed.) -
Page 4: Digital Setup
“DATA IN” port on the POE. Connect a second cable from the “P + DATA OUT” port on the POE and the AW900xTR-INTL. The AW900xTR- INTL is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through it and can be tightened down around the cable to provide a weatherproof seal. - Page 5 User’s Manual AW900XTR-INTL The AW900xTR-INTL should appear in the list at the default IP address of 192.168.17.17. If it does not, click “Search” to regenerate the list. If it still does not appear, you have a connection issue and need to re-examine the cabling or you may have a firewall issue on your computer.
- Page 6 If you scroll down in the Admin browser page, you will come to three more sections: • A graphical spectrum analyzer display that may help you to select radio chan- nels that avoid interference • A section to be used if an update to the AW900xTR-INTL’s firmware is required • An Advanced Links section with a dire warning about advanced users only.
- Page 7 User’s Manual AW900XTR-INTL 8. On the Advanced Admin page, set the parameters as follows: • Choose Device Type: Access Point or Subscriber Unit. • For Subscriber Units, assign unique ID numbers in numeric order from 1 to 63. • For an Access Point, enter the number of Subscriber Units that will be com- municating with it.
-
Page 8: Limited Warranty
This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This war- ranty does not cover defects resulting from misuse or modification of the product.
