AW5800i
User's Manual
Thank you for your purchase of the AW5800i Kit.
If you have any questions when configuring your
AvaLAN product
please send us an email:
support@avalanwireless.com
Kit Contents:
(2) AW5800i Radio Units
(2) Power Adapters 6VDC/120VAC
(2) 5dBi Omni directional Antennae
Quick Setup for systems using the AW5800i radio:
1. Attach a 5800iHz antenna to each module.
2. Apply power to each AW5800i radio.
3. Connect an Ethernet cable from each AW5800i to a network device.
4. Send Ethernet traffic. For troubleshooting see page 2.
Each AW5800i radio automatically selects the best radio channel, encrypts the Ethernet
5.8GHz
Radio
Ethernet
Bridge
AW5800i
AW5800i
Ethernet
RJ45
Power
Ethernet
RJ45
Power
traffic
and
transports
wirelessly to its mate.
Any
Ethernet
device
connected to the AW5800i. The
AW5800i functions in place of an
Ethernet
cable
and
transparent wireless point to point
Ethernet cable replacement. Cross-
over cables are not necessary as the
AW5800i automatically senses the
device (client or switch).
the
data
can
be
provides
a
Advertisement
Related Manuals for AvaLAN AW5800i
Summary of Contents for AvaLAN AW5800i
- Page 1 1. Attach a 5800iHz antenna to each module. 2. Apply power to each AW5800i radio. 3. Connect an Ethernet cable from each AW5800i to a network device. 4. Send Ethernet traffic. For troubleshooting see page 2. Each AW5800i radio automatically selects the best radio channel, encrypts the Ethernet...
-
Page 2: Troubleshooting
LED display: The AW5800i has a 16 LED display to display the status of the device. Name Function Color Power Unit has power and has successfully booted. RF TX Radio transmission is occurring. Green RF RX Radio reception is occurring. -
Page 3: Advanced Settings
There are 58 non-overlapping channels. Manual frequency selection mode This mode enables the user to restrict the operation of the AW5800i to a specific channel. This can be done by setting DIP switches 3-8 as shown in the table below. - Page 4 This product is warranted to the original purchaser for normal use for a period of 180 days from the date of purchase. If a defect covered under this warranty occurs Avalan will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product.
