- Page 1 AW900iTR USER’S MANUAL 900 MHz Indoor Wireless Ethernet Radio AvaLAN Industrial-grade, long-range wireless Ethernet systems...
- Page 2 AW900iTR User’s Manual Thank you for your purchase of the AW900iTR Indoor Wireless Ethernet Radio. The AW900iTR includes: • (1) Radio in indoor yellow plastic case • (1) AW2-900 Flexible Antenna • (1) 120 VAC to 6 VDC power adapter (Ethernet cable not included.)
- Page 3 AW900iTR, AW900xTR and AW900xTP radios. (Please note that older AvaLAN 900 MHz radios can exist on the same LAN but cannot be used to form wireless links with the AW900iTR units because link encryption protocols have changed.)
- Page 4 1. Before placing the radio in its final location, you may want to perform the digital setup procedure described in the next section. 2. Connect the AW900iTR’s TNC RF connector to a suitable antenna. A simple omni- directional dipole unit (AW2-900) is included and may be used for testing and for relatively undemanding applications. If greater range and/or directionality is re- quired, choose one of our other antenna models.
- Page 5 The information on the left is the current status of the radio, while the boxes on the right allow you to change it. It is important that the IP address of the AW900iTR is in the same subnet as your computer. For example, if the subnet mask is 255.255.255.0 ( a class C network), the first three number groups of the IP address must match.
- Page 6 If you scroll down in the Admin browser page, you will come to three more sections: • A graphical spectrum analyzer display that may help you to select radio chan- nels that avoid interference • A section to be used if an update to the AW900iTR’s firmware is required • An Advanced Links section with a dire warning about advanced users only.
- Page 7 User’s Manual AW900iTR 8. On the Advanced Admin page, set the parameters as follows: • Choose Device Type: Access Point or Subscriber Unit. • For Subscriber Units, assign unique ID numbers in numeric order from 1 to 63. • For an Access Point, enter the number of Subscriber Units that will be com- municating with it.
-
Page 8: Limited Warranty
This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This war- ranty does not cover defects resulting from misuse or modification of the product.
