AvaLAN AW2400xTR User Manual

2.4 ghz outdoor wireless ethernet radio
Hide thumbs

Advertisement

Quick Links

Download this manual
High
Security
Supplement
User Manual Supplement
forAvaLAN Wireless Radios
with FIPS 140-2 Security
(AWxxxS Series)
AvaLAN
Industrial-grade, long-range wireless Ethernet systems
W
I
R
E
L
E
S
S

Advertisement

loading
Need help?

Need help?

Do you have a question about the AW2400xTR and is the answer not in the manual?

Questions and answers

Related Manuals for AvaLAN AW2400xTR

Summary of Contents for AvaLAN AW2400xTR

  • Page 1 High Security Supplement User Manual Supplement forAvaLAN Wireless Radios with FIPS 140-2 Security (AWxxxS Series) AvaLAN Industrial-grade, long-range wireless Ethernet systems...
  • Page 2 High Security Supplement If you have an AvaLAN radio with FIPS 140-2 Security, this supplement to the User Manual provides instructions for setting up the encryption. Please disregard the AES Encryption instructions in the regular manual: This supercedes them. A feature of the level of security provided is that there is no way to change the encryption method or key through the radio's interface.
  • Page 3 High Security Supplement key. You should program the encryption modules in both radios of your wireless link at the same time and on the bench prior to deployment. (This is much more conve- nient than climbing a pole with a laptop strapped around your neck.) Make sure you do not lose the login password and encryption key because they cannot be retrieved from the modules in any fashion.
  • Page 4 USB cable and replace the cap on the connector. Then cycle power through the LAN cable to restore the wireless radio to normal operation. © 2012 by AvaLAN Wireless Systems, Inc. All Rights Reserved. Version 04.20.2012 PAGE 4 Technical support (650) 384-0000 www.avalanwireless.com...
  • Page 5 AW2400xTR User’s ManUal 2.4 GHz Outdoor Wireless Ethernet Radio AvaLAN Industrial-grade, long-range wireless Ethernet systems...
  • Page 6 AW2400xTR User’s Manual Thank you for your purchase of the AW2400xTR Outdoor Wireless Ethernet Radio. The AW2400xTR includes: • (1) Radio in weatherproof die-cast aluminum package • (1) AW2-2400 Flexible Antenna • (1) 120 VAC to 12 VDC power adapter • (1) AW-POE Power Over Ethernet Injector...

  • Page 7: Operational Summary

    User’s Manual AW2400xTR Operational summary The AW2400xTR Radio allows the user to create a long-range, wireless Ethernet net- work with up to 16 subscriber units per access point. The configuration may include any combination of AW2400xTR, AW2400iTR and AW2400xTP radios. Configuring a wireless link with the AW2400xTR requires the establishment of six elements: • Each radio must know whether it is to be an access point (AP) or subscriber unit (SU).

  • Page 8: Physical Setup

    “DATA IN” port on the POE. Connect a second cable from the “P + DATA OUT” port on the POE and the AW2400xTR. The AW2400xTR is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through it and can be tightened down around the cable to provide a weatherproof seal.
  • Page 9 3. Run the IP Discovery Utility, ipfinder.exe and you should see a window similar to this: The AW2400xTR should appear in the list at the default IP address of 192.168.17.17. If it does not, click “Search” to regenerate the list. If it still does not appear, you have a connection issue and need to re-examine the cabling or you may have a firewall issue on your computer.
  • Page 10 If you scroll down in the Admin browser page, you will come to three more sections: • A graphical spectrum analyzer display that may help you to select radio chan- nels that avoid interference • A section to be used if an update to the AW2400xTR’s firmware is required • An Advanced Links section with a dire warning about advanced users only.
  • Page 11 User’s Manual AW2400xTR 8. On the Advanced Admin page, set the parameters as follows: • Choose Device Type: Access Point or Subscriber Unit. • For Subscriber Units, assign unique ID numbers in numeric order from 1 to 63. • For an Access Point, enter the number of Subscriber Units that will be com- municating with it.

  • Page 12: Limited Warranty

    This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This war- ranty does not cover defects resulting from misuse or modification of the product.
