Lexicon Recording Studio Owner's Manual page 25

Rewind and Play Buttons
5. Turn the Alpha Studio™ Output Level knob to adjust the listening volume, and
make sure the Monitor Mix knob is somewhere in the middle between Direct and
Playback.
To overdub a second track:
1. Click anywhere in the gray area (not on the buttons) of the Track 2 window
(labeled as Audio 02).
2. In the Inspector, click the IN: box and select IN 1 or IN 2 for Track 2's input. (IN 1
relates to Line 1/Inst inputs, IN 2 relates to Line 2/Mic inputs).
3. In the Track 2 window, the Record Enable button
If it isn't, click it so that it turns red.
4. In the Track 2 window, click the Input Monitoring button
lit.
To set monitor levels for a comfortable listening level:
1. On the front of the Alpha Studio hardware, locate the Monitor Mix knob.
Input Louder Playback Louder
Playback Softer Input Softer
Monitor Mix
2. While playing back the recording, adjust the Monitor Mix knob to balance the
levels between direct input signal and recording playback. To make the direct
input louder than the recording playback in the headphones, turn the Monitor
Mix knob towards the Direct side. To make the recorded track louder, turn the
Monitor Mix knob towards the Playback side.
NOTE: Changing the Monitor Mix does not affect the recording level, only what
you hear while recording. You can also adjust the playback level and pan position
of the original track in your monitor by adjusting the controls for Track 1 within
Cubase LE's Mixer window.
®
3. Click on Record and record the second (overdubbed) track.
Recording Using the Microphone/Line Input
should already be red.
so that it is not
25
