IBM InfoPrint 20
Quick Reference Card
Install your printer and turn it on.
1
See the
Quick Setup Poster
that came with your printer
for instructions.
Print a configuration page.
2
See the
Operator Panel
Install any options, such as duplex unit, extra paper tray,
3
2000-sheet input drawer, network card, or SIMM.
See the instructions that accompany each option for installation instructions.
Connect the printer to a parallel cable or network.
4
Parallel cable
connection
See the documentation that comes with the IBM Network Card
for instructions on connecting your printer to a network.
Install the printer drivers for your operating system.
5
Follow the instructions on the CD-ROM.
section of this
Quick Reference Card
for instructions.
G544-5512-00
