SMART-AVI UTX-500 Installation Manual

What's in the Box?
PART NO. QTY DESCRIPTION
UTX-TX500 1 UTX-500 Transmitter
UTX-RX500 1 UTX-500 Receiver
PS5VDC2A 2 5 Volt 2 Amp Power Supply
CCUSBAB06 1 6ft USB MM AB cable
CCVGAMM06 1 6ft XVGA MM Cable

Technical Specifications

VIDEO
Format RGBHV, RGsB, YUV, Y/C, CVBS
Resolution Up to 1920 x 1200 VGA, SVGA, XGA, SXGA,
UXGA, WUXGA
Input Interface (TX) (1) HD-15 Female
Output Interface (RX) (1) HD-15 Female
AUDIO
Signal Type Stereo Unbalanced
Input Interface (TX) 3.5 mm Jack Socket (Female)
Output Interface (RX) 3.5 mm Jack Socket (Female)
USB
Signal Type USB 1.1
Input Interface (TX) (1) USB Type B (Female)
Output Interface (RX) (4) USB Type A (Female)
OTHER
Power External 100-240 VAC/5VDC2A @10W
Dimensions 5.5 in W x 1 in H x 3.375 in D
Weight 1 lb
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
