DualSaw CS 450 Owner's Manual

Hide thumbs Also See for CS 450:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Activate your Warranty Plan and
gain access to amazing promotional
offers and after-sales service.
See Page 2
CS 450
OWNER'S MANUAL
CAUTION! Read, understand and follow all Safety Rules and Operating Instructions in
this manual before using this product. Save this manual for future reference.
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DualSaw CS 450

Summary of Contents for DualSaw CS 450

  • Page 1 See Page 2 CS 450 OWNER’S MANUAL CAUTION! Read, understand and follow all Safety Rules and Operating Instructions in this manual before using this product. Save this manual for future reference.

  • Page 2: Warranty Activation

    VIP MEMBERSHIP CARD WARRANTY ACTIVATION EMAIL COMPLETED ACTIVATION FORM www.dualsaw.eu ACTIVATE WARRANTY ONLINE : DUALSAW MODEL / SERIAL NO.: 1234 5678 9101 00 ACTIVATION REQUIRED FOR AFTER SALES SERVICE & SUPPORT. ACTIVATION NECESSAIRE POUR SERVICE APRES-VENTE ET GARANTIE First Name ACTIVACIÓN NECESARIA PARA SERVICIO AL CLIENTE Y GARANTÍA...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warranty Activation Safety instructions and warnings Machine components Proper usage General safety instructions Special safety instructions Fitting the support handle Operation Instructions for Cutting Various Cross Sectional Material Removal / Replacement of Saw blades Lubrication Maintenance and care Troubleshooting Technical data Repairs &...

  • Page 4: Safety Instructions And Warnings

    SAFETY INSTRUCTIONS AND WARNINGS This machine complies with the prescribed safety regulations for electrical machines. Read the operating manual carefully before using the machine. Incorrect use may result in damage or injury to people and property. People who are not familiar with the manual must not be permitted to use the machine.

  • Page 5: Proper Usage

    PROPER USAGE • The machine is designed for cutting metal, stone and ceramics using the appropriate blades and accessories. • If it is not used for the purpose for which it is designed or if any modifications are made to the machine, the manufacturer cannot accept any liability. • Also refer to the safety instructions, the installation and operating manual, and the general accident prevention regulations.

  • Page 6: Special Safety Instructions

    PERSONAL SAFETY • Do not wear loose-fitting clothing or jewelry. • Ensure that you have a safe place to stand and that you wear non-slip shoes. • Wear a hair net if you have long hair. • Loose-fitting clothing, jewelry and long hair may become caught in moving parts. • Always wear safety goggles. Following this instruction will reduce the risk of serious injuries.
  • Page 7 that you do not lose control of it. Never stand in line with the saw blade. Always stand to the right or left of the saw blade. Any recoil may result in the saw jumping backwards. Never reach below the work piece. The safety hood over the saw blade does not of- fer any protection from the saw blade underneath the work piece.
  • Page 8 still moving. Do not use bent or torn saw blades. Do not solder or weld saw blade cracks or weld support parts with carbide metal teeth. Never slow down or stop the saw blades by exerting lateral pressure on them. Never use carbide metal-tipped saw blades with a residual height or thickness of less than 1 mm.
  • Page 9 this saw blade will become too narrow, which will cause excessive friction resulting in the saw blade jamming and possibly recoil. If you wish to cut into existing walls or other concealed areas, proceed with special care and caution. Since you cannot know what is behind the area you are cutting, you must anticipate recoil to occur at any time.

  • Page 10: Fitting The Support Handle

    FITTING THE ADDITIONAL HANDLE The handle can be fitted on either the left-hand side or right-hand side of the saw. Secure the handle using the screw supplied. OPERATION SAW BLADES Keep the saw blades clean and sharp at all times. Ensure that the saw blades are fitted correctly. A blunt saw blade will reduce the cutting capacity, place additional strain on the saw’s motor and increase the risk of recoil. Ensure that you always have spare saw blades available. In the event that resin and pitch residue build up on to the saw blade, the blade’s speed will be reduced.
  • Page 11 blade. Any contact between parts of your body and the rotating saw blade will result in very serious injuries. SAWING Always use the saw as set out in these instructions. Always support the work piece near the cut (for example using a saw stool or the like). Always secure the work piece so that the cut is on your side.
  • Page 12 integral lubrication device since these material tend to adhere to the saw blades. When sawing these materials, pay very close attention to ensuring that the direction of the saw is always parallel to the saw blade since otherwise the saw blade will become so hot that it could burn or the damage the saw teeth.

  • Page 13: Instructions For Cutting Various Cross Sectional Material

    INSTRUCTION FOR CUTTING VARIOUS CROSS SECTIONAL MATERIALS FLAT SCRIP ALUMINUM /COPPER WAX STICK 90° SQUARE TUBE U PROFILE THING SHEET METAL ROUND TUBE 90° 10 MM...

  • Page 14: Removal / Replacement Of Saw Blades

    REMOVAL / REPLACE OF SAW BLADES Press and hold button. Holding button. Affix key tool on bolt. Unscrew and remove bolt by rotating in counter-clockwise direction. Open blade guard and remove blade To replace blades, affix new blade FACE 1 first and blade FACE 2 second. FACE 1 first and blade FACE 2 second. Important Note: Blade sets and labeling vary slightly, and may be labeled FACE 1 and FACE 2, or FACE A and FACE B.

  • Page 15: Lubrication

    LUBRICATION • The blades are equipped with “Dry Cut” teeth. As a rule these need not be lubri- cated. However, in extreme cutting conditions, cutting paste (wax) can be applied. • When cutting Aluminium /Copper/ Stainless steel and cast iron, the lubricating de- vice must always be used. • We recommend that you buy cutter paste in rod form, available from your nearest dealer. • Insert a cutter paste rod.

  • Page 16: Troubleshooting

    3. Replace blades 4. Blades have buckled 4. Replace blades 5. Blades have burned out 5. Replace blades TECHNICAL DATA DESCRIPTION Mod. CS 450 / BLACKSTAR 115 Motor Power 1050W Voltage EU 230V / 50Hz Voltage UK 240V / 50Hz...

  • Page 17: Limited & Extendable Warranty

    or the place where you purchased the product. This symbol on the product or on its packaging indicates that this product (includ- ing batteries) shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equip- ment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 18 your return or process an exchange/refund. WARRANTY The Manufacturer’s warranty is limited to the terms set forth in the Warranty Information Card provided in the product instruction manual, or listed in the conditions listed in the section below: “2 YEARS SERVICE PROTECTION PLAN- LIMITED WARRANTY POLICY” The Warranty Information Card must be completed and returned per the instructions above (unless activated online) within 30 days from the order date.
  • Page 19 mal business hours and if you can also request a Return Materials Authorization (RMA). CUSTOMER SERVICE Business Hours: Monday - Friday 09:00 / 17:00 Please have the following information ready: part number or model, detailed description of problem, and the original purchase order information. All the data collected from the customer service will be forwarded immediately to our Technical Service who will send you a response by email including the full return/exchange procedure to proceed the return (unless a phone response is specifically requested). We guarantee to answer all your questions, and resolve any concerns.

  • Page 20: Optional Blades And Accessories

    OPTIONAL BLADES AND ACCESSORIES STAD115TU STAD115SS TUNGSTEN 115 STAINLESS STEEL115 For universal purpose Especially for Stainless Steel STAD115DI STAD115GL DIAMOND 115 GLASS CUT 115 Stone, Tile, Marble, Ceramic... Especially for Glass STALSP115 STAGR115 STALA SPINLASER GUIDE RULER LASER GUIDE Accessory Accessory for Accessory for straight cuts...

  • Page 22: Declaration Of Conformity (Doc)

    Imported and distributed by: HOME SHOPPING EXPRESS, S.A C/O GRANBY MARKETING SV., STANLEY STR. BB13BW BLACKBURN UNITED KINGDOM P. (+44) 08453025761 www.dualsaw.co.uk...
