- Page 1 Owner’s Manual Model No. 1653501 - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and Understand this Manual before Operating unit Retain For Future Reference...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions…………………………………………………. 2 Important Electrical Instructions……………………………………………… 4 Assembly instructions…………………………………………………………. 5 Folding/ Transport Instructions……………………………………………… 10 Operation of Your New Treadmill…………………………………………… 11 Exploded View Diagram/Parts List…………………………………………. 15 General Maintenance………………………………………………………….19 Manufacturer’s Limited Warranty…………………………………………… 22 Customer Service 1-888-707-1880 Dyaco Canada Inc. 2013 Email: customerservice@dyaco.ca... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INFORMATION THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL ▲CAUTION: Before starting any exercise program, it is recommended that you consult your physician. ▲WARNING: Connect this unit to a properly grounded outlet only. ▲DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet immediately after using and before cleaning. - Page 4 15. Never turn on treadmill while standing on treadbelt. Always hold the handrails while using the treadmill. Always return the treadmill to the slowest speed to provide for safe dismount and low speed restart. 16. To disconnect, turn all controls to the off position, then remove plug from outlet. 17.
-
Page 5: Important Electrical Instructions
Important Electrical Information WARNING! NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power cord ● away from any moving part of the treadmill including the elevation mechanism and transport wheels. NEVER remove any cover without first disconnecting AC power. ●... -
Page 6: Assembly Instructions
Assembly Instructions !!ATTENTION: IMPORTANT UNPACKING INSTRUCTIONS. PLEASE READ BEFORE UNPACKING YOUR FOLDING TREADMILL!! Serious injury could occur if this folding treadmill is not unpacked properly. There is a Velcro strap installed around the treadmill base that prevents the treadmill from unfolding accidentally during shipping. - Page 7 Assembly Instructions #100. #99. Ø8×Ø18×1.5m/m 5/16" ×1/2" #156. M5×15m/m (8pcs) (8pcs) Flat Washer Hex Head Bolt (6pcs) Phillips Head Screw #125. 5/16" × 3/4" #126. Ø8 × Ø19 × 1.5T Button Head Socket Bolt Curved Washer (2pcs) (10pcs) #104. Lubricant #44.
- Page 8 Assembly Instructions Step 1. Remove the treadmill from the carton and lay it on a smooth level surface. Step2. Connect Computer Cable (Middle) (54) with Computer Cable (Lower) (55) then insert Right and Left Uprights (4) and (5) into the Frame Base (2) and use 13m/m Wrench (90) to tighten 8 pcs of 5/16"...
- Page 9 Step 3 Connect Computer Cable (Middle) (54) with Computer Cable (Upper) (53) Step 4. Install the Console Support (6) into the Uprights (L,R) (5,4) with the 6pcs of 5/16" × 3/4" Button Head Socket Bolts (125) and 2pcs ofψ8 x 19 x 1.5T Curved Washers (126) by using the Combination M5 Allen Wrench &...
- Page 10 Step 6. Insert Console Assembly (21) into Console Support (6) and secure with 6 pcs ofM5 × 15m/m_Phillips Head Screws (156) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (102). Step 7. Install Handrail Support (9) between left and right Uprights (5) and (4) and use Combination M5 Allen Wrench &...
-
Page 11: Folding/ Transport Instructions
Folding Instructions Do not attempt to move the unit unless it is in the folded and locked position. Be sure the power cord is secured to avoid possible damage. Use both handrails to maneuver the unit to the desired position. ■... -
Page 12: Operation Of Your New Treadmill
Operation of Your Treadmill Button Function： A > SPEED (FAST)： Pressing this button increases the speed by 0.1(km/mile). Press and hold this button for 3 seconds to increase speed rapidly. Press this button during setting the program to adjust the value (to increase). B >... -
Page 13: Treadmill Operation
Treadmill Operation After turning on the power on, place the safety key on the console for the treadmill to enter the ready mode. Press the start button to start the treadmill or press PROGRAM button to select the training mode, normal or manual mode, preset programs (P1~P24) or heart rate control mode. Manual/Normal Mode: Turn on the power, put on the safety key and the console enters MANUAL or normal mode then press start button to start the treadmill... - Page 14 Metric Table Customer Service 1-888-707-1880 Dyaco Canada Inc. 2013 Email: customerservice@dyaco.ca...
- Page 15 English Table Customer Service 1-888-707-1880 Dyaco Canada Inc. 2013 Email: customerservice@dyaco.ca...
-
Page 16: Exploded View Diagram/Parts List
Parts List and Diagram KEY NO. PART NO. DESCRIPTION Q'TY 350101 Main Frame 350102 Frame Base 350103 Incline Bracket 350104 Right Upright 350105 Left Upright 350106 Console Support 350107 Outer Slide 350108 Seat Slider 350109 Handrail Support 350110 Incline Motor 350111 Drive Belt 350112... - Page 17 350136 Handgrip Foam 350137 Foot Rail 350140 Motor Cover Anchor(D) 350143 30 × 60m/m_Square End Cap 350144 Safety Key 350145 Power Socket 350146 3/8" × 7T_Nut 350147 Sensor Rack 350148 Power Cord 350149 300m/m_Connecting Wire (White) 350150 300m/m_Connecting Wire (Black) 350151 100m/m_Connecting Wire (Black) 350152...
- Page 18 350195 Cylinder 350196 M8 × 50m/m_Flat Head Countersink Bolt 350199 5/16" × 1/2"_Hex Head Bolt 3501100 Ø8 × Ø18 × 1.5T_Flat Washer 3501102 Combination M5 Allen Wrench & Phillips Head Screw Driver 3501103 M6 (66 × 86)_L Allen Wrench 3501104 Lubricant 3501105 Adjustment Foot...
-
Page 19: Parts Diagram
PARTS DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. 2013 Email: customerservice@dyaco.ca... -
Page 20: General Maintenance
General Maintenance Belt and Bed - Your treadmill uses a very high-efficient low-friction bed. Performance is maximized when the bed is kept as clean as possible. Use a soft, damp cloth or paper towel to wipe the edge of the belt and the area between the belt edge and frame. Also reach as far as practical directly under the belt edge. -
Page 21: Treadbelt Tracking Adjustment
TREADBELT TRACKING ADJUSTMENT: The performance of your treadmill is dependent on the frame running on a reasonably level surface. If the frame is not level, the front and back roller cannot run parallel, and constant belt adjustment may be necessary. The treadmill is designed to keep the treadbelt reasonably centered while in use. - Page 22 Service Checklist – Diagnosis Guide Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill’s warranty. PROBLEM SOLUTION/CAUSE 1.
-
Page 23: Manufacturer's Limited Warranty
12 months from the date of purchase. All other obligations or liabilities, including liability for consequential damages are hereby excluded REPAIR PARTS AND SERVICE All of the parts for the Everlast treadmill, shown in figure can be ordered from: Dyaco Canada Inc.
