Icom IC-F50 Service Manual Addendum page 21

INTRODUCTION
This service manual describes the latest service information
for the IC-F50/IC-F51 VHF TRANSCEIVERS at the time of
publication.
MODEL VERSION
IC-F50 U.S.A
IC-F51 Europe
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 8 V. Such a connection
could cause a fire or electric hazard.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the trans-
ceiver's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
5030002630 LCD L3-0048TAY-2
8810010120 Screw BO 2x8 SUS ZK IC-F50
Addresses are provided on the inside back cover for your
convenience.
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
SYMBOL I/S TX Hi-POWER
USA NO
USA-88 FM
EUR NO
EUR-88 ATEX
IC-F50 Front unit
Chassis
5 W
5 W
1 W
5 pieces
10 pieces
REPAIR NOTES
