SPLIT TYPE
ROOM AIR CONDITIONER
CEILING WALL
INVERTER
Models
AWHZ14LBC
AOHZ14LBC
AWHZ18LBC
AOHZ18LBC
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM . . . . 3
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . 4
INDOOR PCB CIRCUIT DIAGRAM . . . . . 5
OUTDOOR PCB CIRCUIT DIAGRAM . . . 8
ERROR CONTENTS . . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . .
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . .
type
10
11
14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for General AWHZ14LBC
Summary of Contents for General AWHZ14LBC
-
Page 1: Table Of Contents
CEILING WALL type INVERTER Models Indoor unit Outdoor unit AWHZ14LBC AOHZ14LBC AWHZ18LBC AOHZ18LBC CONTENTS SPECIFICATIONS ....1 OUTLINE AND DIMENSIONS ..2 REFRIGERANT SYSTEM DIAGRAM . -
Page 2: Specifications
SPECIFICATIONS REFRIGERANT CHARGE (R410A) 1,350 g Cooling and Heat-pump heating 15 m TYPE Pipe Length FULL CHARGE AMOUNT 1,450 g AWHZ14LBC AWHZ18LBC 20 m INDOOR UNIT 20 g / m AOHZ14LBC AOHZ18LBC OUTDOOR UNIT ADDITIONAL REFRIGERANT 20 m 4.2 kW 5.2 kW... -
Page 3: Outline And Dimensions
DIMENSIONS Models : AWHZ14LBC, AWHZ18LBC (Unit : mm) Models : AOHZ14LBC, AOHZ18LBC 2006.02.06... -
Page 4: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Models : AWHZ14LBC / AOHZ14LBC AWHZ18LBC / AOHZ18LBC Heat exchanger Muffler ( INDOOR ) Heat exchanger B 3-Way Valve 2-Way Valve ( INDOOR ) Muffler Receiver Compressor 4-Way Valve Strainer Accumulator Heat exchanger ( OUTDOOR ) Strainer... -
Page 5: Circuit Diagram
CIRCUIT DIAGRAM AIR FILTER (LEFT) SWITCH (LEFT) INDOOR UNIT TERMAL FUSE 102 AIR FILTER (RIGHT) SWITCH INDICATOR PCB (RIGHT) CN208 TERMAL FUSE 102 CONNECTOR (RED) BROWN WHITE WHITE ORANGE CN201 CN200 CN203 CN202 CN204 WHITE WHITE WHITE LOUVER U YELLOW WHITE CONNECTOR BOARD WHITE... -
Page 6: Indoor Pcb Circuit Diagram
WHITE LIMIT SWITCH-L WHITE WHITE CN15 JZ-11 CN204 ZHR-5 CONTROLLER PCB ASSY BROWN S8B-PASK JB-8 RJW-20 LOUVER-U AWHZ14LBC : K05DS-0500HSE-F1 WHITE ORANGE ( UP / DOWN ) WHITE WHITE AWHZ18LBC : K05DS-0501HSE-F1 YELLOW WHITE WHITE GREEN WHITE WHITE ZHR-5 BLUE... - Page 7 CONTROLLER PCB ASSY AWHZ14LBC : K05DS-0500HSE-F1 Models : AWHZ14LBC AWHZ18LBC : K05DS-0501HSE-F1 AWHZ18LBC CONTROLLER PCB RECIVER MANUAL AUTE SWITCH 2006.02.06...
- Page 8 INDICATOR PCB Models : AWHZ14LBC AWHZ18LBC 2006.02.06...
-
Page 9: Outdoor Pcb Circuit Diagram
OUTDOOR PCB CIRCUIT DIAGRAM Models : AOHZ14LBC AOHZ18LBC INVERTER ASSEMBLY AOHZ14LBC : EZ005CHUE AOHZ18LBC : EZ005DHUE EMI FILTER 1 ZCAT1518-0730 F201 20A-250V UL1015 AWG14 POWER BLACK ( A-1 ) POWER SOURCE UL1015 CHOCK COIL EMI FILTER 5 AC230V / 50Hz AWG14 POWER WHITE... - Page 10 CONTROLLER PCB ASSY Models : AOHZ14LBC AOHZ14LBC : K05AD-0500HUE-C1 AOHZ18LBC AOHZ18LBC : K05AD-0501HUE-C1 PS21265-P JM902 AWHZ18LBC AWHZ14LBC 2006.02.06...
-
Page 11: Error Contents
ERROR CONTENTS Display Error Operation Error Timer LED 2 flash Serial signal (reverse) error, at operation start up 3 flash Serial signal (reverse) error, during operation Serial signal error 4 flash Serial signal (forward) error, at operation start up 5 flash Serial signal (forward) error, during operation 2 flash Indoor temperature thermistor open / short... -
Page 12: Disassembly Illustration
DISASSEMBLY ILLUSTRATION Models : AWHZ14LBC AWHZ18LBC 2006.02.06... - Page 13 2006.02.06...
- Page 14 Models : AOHZ14LBC AOHZ18LBC 2006.02.06...
-
Page 15: Parts List
PARTS LIST INDOOR UNIT Part No. Ref. Ord. Description Q'ty AWHZ14LBC AWHZ18LBC Air Filter 9313859015 9313859015 Dust Box Assy 9313884024 9313884024 Front Panel Assy 9313882044 9313882044 Open Panel Assy 9314405037 9314405037 Top Grill 9313848019 9313848019 Top Cover 9313849023 9313849023 Under Cover... -
Page 16: Outdoor Unit
OUTDOOR UNIT Part No. Ref. Ord. Description Q'ty AOHZ14LBC AOHZ18LBC Top Panel Assy 9309230057 9309230057 Cabinet Sub Assy 9314809040 9314809040 Blow Grill 9308884015 9308884015 Cabinet Right Assy 9309236011 9309236011 Fan Ring 9308885012 9308885012 Grip 9308880017 9308880017 Switch Cover Assy 9309237025 9309237025 Protective Net 9315319012... -
Page 17: Standard Accessories
STANDARD ACCESSORIES The following installation accessories are supplied. Use them as required. Name and Shape Q'ty Name and Shape Q'ty Drain pipe Wall hook bracket 9303029022 9312011018 Cloth tape Remote control unit 9308117007 Tapping screw (big) 9314157035 Battery 0700076046 Tapping screw (small) 0600185046 0700019036 Remote control unit... - Page 18 0512G2966...
