User's Manual
UHBX-8X
8-Port HDMI Extender on HDBaseT™
with
IR, RS-232, and IP Control
Send 8 HDMI inputs to 8 remote displays up to 500 ft away
Send PoH to power compatible receivers
Extend IR in both directions
Send RS-232 and IR commands to any remote Display
Control unit via RS-232 and IP ports
UMA1213 Rev A
© Copyright 2014. Hall Research, Inc. All rights reserved.
1163 Warner Ave Tustin, CA 92780, Ph: (714)641-6607, Fax (714)641-6698
Advertisement
Table of Contents
Related Manuals for HR UHBX-8X
Summary of Contents for HR UHBX-8X
- Page 1 User’s Manual UHBX-8X 8-Port HDMI Extender on HDBaseT™ with IR, RS-232, and IP Control Send 8 HDMI inputs to 8 remote displays up to 500 ft away Send PoH to power compatible receivers Extend IR in both directions Send RS-232 and IR commands to any remote Display...
-
Page 2: Table Of Contents
8-Port HDMI Extender with Power, IR, and RS-232 Table of Contents 1.0 Introduction 2.0 Features 3.0 Setup 3.1 Package Contents 4.0 Operation 3.2 Extender Connections 5.0 Control Commands (RS232 and IP) 4.1 Front Panel HDBaseT Status Indicators 6.0 Troubleshooting 7.0 Specifications TRADEMARKS USED IN THIS MANUAL Hall Research and its logo are trademarks of Hall Research. -
Page 3: Introduction
IR detector input. The IR received by the detector can be routed to any particular or combination of outputs. 8 separate IR emitter ports are provided on the rear of the UHBX-8X The source of these signals would be IR detectors at each remote location. This would be perfect for controlling multiple sources in a rack remotely from where the TV’s are located... -
Page 4: Setup
8x8 HDMI matrix that has HDBaseT outputs. Hall Research manufactures 8x8 HDMI matrix with the outputs on the right side. So if you stack the UHBX-8X with the above matrix, using short 5 inch patch cables you can add cross-point capability to the extender as shown below: Figure 2 –... - Page 5 Term Direction Output Input Figure 6 – RS-232 path from UHBX-8X to remote receivers 3.2.3 Extender IP Connection Figure 5 – IP Port The RJ45 connector is a 10/100 Base-T Ethernet port. This IP port can be accessed via Telnet. As shipped, the IP address is configured for DHCP (assigned by your network’s router) and Port 6324 is used for Telnet...
- Page 6 TV’s remote and point it at the IR detector that is plugged in to the UHBX-8X and be able to control the remotely located TV. Figure 9 – IR path from UHBX-8X extender to remote locations...
- Page 7 UHBX does provide the means to send “learned” IR codes, but to learn the codes a Hall Research model HR-4P may be needed. The IR send command for “learned” codes are typically a series of 64 Hex bytes that precisely define the IR signal to be generated.
- Page 8 8-Port HDMI Extender with Power, IR, and RS-232 IR Emitter (Blaster) Cables Currently two IR emitter cables are available: CIR-EMT and CIR-EMT2. CIR-EMT, shown below, is recommended for most applications Figure 13 – IR Emitter Cable CIR-EMT (Emitter has adhesive backing) Pin out: Tip=Anode, Ring=Cathode, Sleeve=Not Connected An alternative Emitter cable is CIR-EMT2.
- Page 9 The UH-1BTX-R, does not have a mode switch, however the mode can be set on the UHBX-8X using the Windows GUI. If you are using UH-1BTX and would like to set the link mode to Long Reach, you can do that using the Windows GUI through the USB connection.
- Page 10 IR or RS-232 (such as UHBX-R-PD), the UHBX-8X keeps the HDBaseT link fully active at all times even if there is no video. If you are using UHBX-R-PD as receiver, but are not using the RS-232 nor the IR functions, it is recommended that you turn on “power management”...
- Page 11 UHBX-8X If all the LED’s on the front panel are blinking together, then the unit has detected an over temperature condition and is performing a partial shutdown to prevent damage to the integrated circuits. This condition is reversible and when the temperature decreases to acceptable levels the extender begins to function normally again.
-
Page 12: Control Commands (Rs232 And Ip)
All byte received after this command end up in a FIFO and will be sent out after receiving a special two byte end of data designator (referred to as terminal characters). Therefore The UHBX-8X does not distinguish between ASCII or Hex data, all data are treated as bytes The user has 1-5 seconds to enter any data or characters, or a timeout will occur. - Page 13 ISk,m,n <cr> Command: IS9<cr> Stands for IR Send Detailed Timing (HR Protocol) If the protocol of the particular IR Remote you intend to emulate is unknown it is possible to instruct the UHBX-8X to send IR commands based on detailed...
- Page 14 (demodulated type 2) will be required for learning these codes. The learned codes can be cut from the HR-4P GUI, and used as data for the IS9 command. The IS9<cr> command is followed by a string of hex bytes to be sent out. The user has up to 5 seconds to enter each hex byte from 0x00 to 0xFF.
-
Page 15: Troubleshooting
1BTX-R receiver which does not have a mode switch, then you have to set the mode on the UHBX-8X using the GUI via the USB connection. If you are using an HDBaseT Class B (lite) receiver such as the model UH-1BT-... - Page 16 Do not open or try to repair the unit yourself as this will void your warranty. To return the extender for repair, you must contact HR Support at 714-641- 6607 or via email or web. To ship the unit back for repair, make sure to obtain...
-
Page 17: Specifications
100 VAC to 240 VAC, 50-60 Hz, 1.5A, internal; Power 30 watts (102 BTU/hr) maximum Temp/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing... - Page 20 © Copyright 2014. Hall Research, Inc. All rights reserved. 1163 Warner Ave., Tustin, CA 92780 Ph: (714)641-6607...
