HDMI on Dual UTP Extender
Extend HDMI™ on 2 Cat6 Cables
UH-2D
UH-2D-S
UH-2D-R
UH-2D-S-DP
SUPPORT &
ORDERING
INFORMATION
Kit of UH-2D-S (Sender) and UH-2D-R (Receiver)
HDMI on 2 UTP Sender
HDMI on 2 UTP Receiver
HDMI on 2 UTP Sender Decora® Wallplate
For technical support, Call 714-641-6607 or fax 714-641-6698
Order by phone: toll-free in the U.S. 800-959-6439
Web site: www.hallresearch.com
Hall Research, 1163 Warner Ave. Tustin, CA 92780
User's Manual
UMA1216 Rev. n/c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UH-2D and is the answer not in the manual?

Questions and answers

Related Manuals for HR UH-2D

Summary of Contents for HR UH-2D

  • Page 1 User’s Manual HDMI on Dual UTP Extender Extend HDMI™ on 2 Cat6 Cables UH-2D Kit of UH-2D-S (Sender) and UH-2D-R (Receiver) UH-2D-S HDMI on 2 UTP Sender UH-2D-R HDMI on 2 UTP Receiver UH-2D-S-DP HDMI on 2 UTP Sender Decora® Wallplate For technical support, Call 714-641-6607 or fax 714-641-6698 SUPPORT &...

  • Page 2: Trademarks Used In This Manual

    TRADEMARKS USED IN THIS MANUAL Hall Research and its logo are trademarks of Hall Research. Any other trademarks mentioned in this manual are acknowledged as the property of the trademark owners. FCC RADIO FREQUENCY STATEMENT This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication.
  • Page 3 Model UH-2D 1. Introduction Hall Research’s Model UH-2D is a member of the Hall Research HD-Cat™ video extension product line. The HD-2D extender kit uses two Cat6 cables to extend high definition video well beyond the limitations of HDMI cable. The Sender and Receiver set support HDCP, Deep-Color, 3D and can achieve a distance of up to 170 ft @ 1080i/720p or 130 ft @ 1080p resolution.
  • Page 4 Plug in the power supply (included) into the receiver or the sender whichever is more convenient for your setup. Please note that when the UH-2D-S-DP wall-plate is used, the power supply must be plugged into the receiver as there is no power jack on the wall-plate.

  • Page 5: Troubleshooting

    Receiver Figure 3 – LED indicators On both sides POWER indicated that the UH-2D circuit has power. If either side’s power indicator is off, you need to check the power supply connection. On both sides DISPLAY indicates that the UH-2D is detecting a connected display (Hot Plug Detection).

  • Page 6: Contacting Hall Research

    HDMI™ over Dual UTP Extender Connect the display directly to the source and make sure you can get a picture without the  extender. If so then using the menus of the video source try to set the output resolution to a low one (such as 480p) to start with.
  • Page 8 © Copyright 2013. Hall Research All rights reserved. 1163 Warner Ave., Tustin, CA 92780 Ph: (714)641-6607, Fax: (714)641-6698...
