HR UHBX-S-PSE User Manual

Hdmi video extender with bidirectional ir, and rs232
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDMI Video Extender with
Bidirectional IR, and RS232
Send HDMI, IR, full-duplex RS232, and PoH Power
500 ft (150 m) on a single Cat6 cable
Model numbers covered in this User's Manual:
Individual Ends
UHBX-S-PSE
HDMI+RS232+IR+PoH UTP Sender with Power Supply (PSE)
UHBX-S-PD
HDMI+RS232+IR+PoH UTP Sender Remotely Powered (PD)
UHBX-R-PSE HDMI+RS232+IR+PoH UTP Receiver with Power Supply (PSE)
UHBX-R-PD
HDMI+RS232+IR+PoH UTP Receiver Remotely Powered (PD)
Kits
UHBX-P1
HDMI+RS232+IR+PoH UTP Extender, Sender (PSE) powers Receiver (PD)
UHBX-P2
HDMI+RS232+IR+PoH UTP Extender, Receiver (PSE) powers Sender (PD)
© Copyright 2013. Hall Research, Inc. All rights reserved.
1163 Warner Ave Tustin, CA 92780, Ph: (714)641-6607, Fax (714)641-6698
User's Manual
UMA1215 Rev n/c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHBX-S-PSE and is the answer not in the manual?

Questions and answers

Related Manuals for HR UHBX-S-PSE

Summary of Contents for HR UHBX-S-PSE

  • Page 1 Send HDMI, IR, full-duplex RS232, and PoH Power 500 ft (150 m) on a single Cat6 cable Model numbers covered in this User’s Manual: Individual Ends UHBX-S-PSE HDMI+RS232+IR+PoH UTP Sender with Power Supply (PSE) UHBX-S-PD HDMI+RS232+IR+PoH UTP Sender Remotely Powered (PD)

  • Page 2: Table Of Contents

    HDMI Extender with Power, IR, and RS-232 Table of Contents 1.0 Introduction ..................3 2.0 Features ..................... 4 3.0 Model numbers covered in this Manual .......... 4 4.0 Setup ....................5 4.1 Package Contents ................5 4.2 Sender Connections ..............5 4.3 Receiver Connections ..............

  • Page 3: Introduction

    UHBX-Series 1.0 Introduction This manual covers a few of the UHBX series of HDMI extenders by Hall Research. These products are comprised of individual sender and receiver modules that can send HDMI, bidirectional IR, full-duplex RS232, and PoH (power over HDBaseT) over distances of up to 150 meters (500 feet) using a single Cat6 cable.

  • Page 4: Features

    Compact, Rugged, Reliable, and Economical • Made in USA 3.0 Model numbers covered in this User’s Manual Individual Ends UHBX-S-PSE HDMI+RS232+IR+PoH UTP Sender with Power Supply (PSE) UHBX-S-PD HDMI+RS232+IR+PoH UTP Sender Remotely Powered (PD) UHBX-R-PSE HDMI+RS232+IR+PoH UTP Receiver with Power Supply (PSE)

  • Page 5: Setup

    The PSE devices and kits also include a universal 5vDC power adapter. 4.2 Sender Connections Figure 3 - Sender Connections (UHBX-S-PSE shown above) 4.2.1 Sender Video Connection Connect the HDMI input to the source using the cable provided. If you need to substitute a different cable, for example if the 3 ft supplied cable is not long enough, then you should use quality HDMI cables.
  • Page 6 HDMI Extender with Power, IR, and RS-232 4.2.2 Sender Serial Data Connection If required, plug DB9 RS232 cable from source to the connector on the box. Typically a straight-through male-to-female cable is used to connect to the sender. Pin out of the RS232 connector on the sender is shown below DB9-F Pin Term Direction...
  • Page 7 UHBX-Series one device. A separately sold adhesive rubber cover can be used to confine the IR beam to just one target device. The CIR-EMT2 is placed in a cavity in the cover and stuck on the target device directly over its IR sensor. A typical application scenario is when several identical video sources are located in close proximity to each other and they need to be independently controlled.

  • Page 8: Receiver Connections

    HDMI Extender with Power, IR, and RS-232 4.2.4 UTP (Twisted Pair Catx) Connection The extender is designed to be used with CAT6 UTP or STP cabling. However, CAT5e cables may be used but the maximum cable length will be reduced by approximately 20% depending on the quality of the cable. Augmented CAT6 cables can also be used, and are recommended for extension distances exceeding 140 meters (or >450 feet).

  • Page 9: Setting The Distance Mode

    UHBX-Series DB9-M Pin Term Direction Input Output 4.4 Setting the Distance Mode Mode UTP Length Notes 0 to 100 m (330ft) Default setting L.R. 0 to 150 m (500ft) Long Reach setting Supports maximum of 1080p@60 Hz, 8-bit. 1080p deep-color and 4Kx2K are not supported The extender has a mode setting that affects the maximum achievable extension distance.

  • Page 10: Troubleshooting

    Do not open or try to repair the unit yourself as this will void your warranty. To return the extender for repair, you must contact HR Support at 714-641- 6607 or via email or web. To ship the unit back for repair, make sure to...

  • Page 11: Specifications

    UHBX-Series 6.0 Specifications Video Standards DVI (single link) and HDMI (compliant with HDMI 1.4 video specifications including 12 bit color depth, 3D video and 4K support) Signal type TMDS Connectors Locking HDMI Resolutions DVI signal VGA (640x480) thru WUXGA (1920x1200) HDTV signal 480i through 1080p Digital Cinema 4K (4096x2160) –...
  • Page 12 HDMI Extender with Power, IR, and RS-232 © Copyright 2013. Hall Research, Inc. All rights reserved. 1163 Warner Ave., Tustin, CA 92780 Ph: (714)641-6607...
