PARTS LIST Not Pictured: Key Qty Description TOP LID, OUTER Key Qty Description INNER INSERT F/ TOP LID … DOOR MAGNET HANDLE F/ TOP LID LOGO PLATE … CASTER PIN RUBBER BUMPER, RECTANGLE, F/ TOP … HARDWARE PACK … ASSEMBLY MANUAL, ENGLISH FIREBOX …...
Page 13
ASSEMBLY Place bottom shelf upside down. Insert Bent U Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Bent U Pin and repeat for remaining casters.
Page 14
This step requires two people to lift and position grill head Carefully lower the grill onto cart. head onto the cart, aligning slots at bottom of grill head with posts on Make sure the cart side panels. regulator hose is hanging inside the cart.
Page 15
Pull out the two knobs from control panel. Insert temperature gauge stem into the bigger hole above knob bezel, shown Make sure the gauge is pushed in as far as it will go, then push the gauge downward until it clips into the panel, shown Re-install the two knobs.
Page 16
Attach foldable side shelf brackets to the tracks under right side shelf using one shoulder screw, flat washer, lock 1/4” washer and nut each side, shown Pull foldable side shelf outward and press it down, shown Push foldable side shelf toward right side shelf untill they gather up, shown Only right side shelf shown for assembly, repeat above steps to Install left side shelf with foldable side shelf.
Page 17
Insert flange on right side shelf into side shelf brackets on side of firebox, shown 1/4”-20x3/4” 1/4” Attach right side shelf using three screws, flat washers, lock washers and nuts, shown Attach rear of shelf using one 1/4-20x1½” screw, lock washer, and flat washer in lower hole, shown #8x3/8”...
Page 18
Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and 1/4-20x1½” facing the front. Secure using two screws, lock washers, and flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
Page 19
Insert hinge pin on bottom of door into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of door, and release hinge pin into door. PRESS Top of door Door Hinge pin on bottom of door Release the cap and nut from electronic ignition module.
Page 20
Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Front of firebox Flame tamers Back of firebox Place cooking grates onto the firebox as shown. Insert the two wire ends at rear of warming rack into holes in back of firebox.
Page 21
On back of grill, slide grease tray into opening in upper back panel. CAUTION Failure to install grease tray will cause hot grease to drip from bottom of grill with risk of fire or property damage. Grease tray negative (—) end first. Unscrew electronic ignition cap on cart right side panel.
Page 22
LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Make sure cylinder Care section). Once cylinder has been filled and leak checked, place cylinder into hole in bottom shelf. valve is facing front of grill.
