Wonwoo EWSJ-E180 Installation & Operating Manual

18, 22, 26, 27, 33, 36, 37x outdoor high speed dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Distributed by
18, 22, 26, 27, 33, 36, 37x
Outdoor High Speed Dome Camera
EWSJ-E180, EWSJ-E260, EWSJ-E360, EWSJ-E361
EWSJ-270, EWSJ-330, EWSJ-331, EWSJ-370, EWSJ-371
EWSJ-363,EWSJ-223
P/N : 388065120
PRINTED IN KOREA
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use
INSTALLATION / OPERATING MANUAL
Wall
In-Ceiling
Ceiling

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWSJ-E180 and is the answer not in the manual?

Questions and answers

Related Manuals for Wonwoo EWSJ-E180

Summary of Contents for Wonwoo EWSJ-E180

  • Page 1 INSTALLATION / OPERATING MANUAL 18, 22, 26, 27, 33, 36, 37x Outdoor High Speed Dome Camera EWSJ-E180, EWSJ-E260, EWSJ-E360, EWSJ-E361 EWSJ-270, EWSJ-330, EWSJ-331, EWSJ-370, EWSJ-371 EWSJ-363,EWSJ-223 P/N : 388065120 PRINTED IN KOREA Distributed by Wall In-Ceiling Ceiling Before attempting to connect or operate this product,...

  • Page 2: Table Of Contents

    22p. 4. 5. 2 CAMERA SETTING (EWSJ-E180, E260, E360, E361) ........operate normally, or has been dropped. 4. 5. 3 Camera Menu (EWSJ-223, 363) ..............

  • Page 3: Getting Started

    2. GETTING STARTED 2. 1 Descriptions 2. 3 EWSJ Series Selection Flow The Dome Supremacy EWSJ series are an outdoor speed PTZ dome system designed for IP66 applications, 2. 3. 1 Indoor especially, whether it is raining, snowing or sunny day, this EWSJ series delivers superior performance. Model Select Mount Type The EWSJ series is one unit of housing with pole, corner, wall or recessed ceiling mounts.

  • Page 4: Ewsj Series (Outdoor Speed Ptz Dome Camera) Module

    EWSJ-370: 1/4” Sony Super HAD CCD, Optical 37x - Cool gray color EWSJ-371: 1/4” Sony Interline Dual Scan CCD, Optical 37x with WDR EWSJ-E180: 1/4” Sony Ex-view CCD, Optical 18x - In case the camera contains EWSJ-E260: 1/4” Sony Ex-view CCD, Optical 26x with Image Stabilizer Wall-mount bracket as standard EWSJ-E360: 1/4”...

  • Page 5: Dip Switch Setting

    2. 6 DIP Switch Setting 2. 6. 3 Set the camera address (ID) 2. 6. 1 Dip Switch Setting S201: 100-digit number of address (ID) Before start up the dome camera, set the protocol and camera address and termination set with S202 : 10-digit number of address (ID) dip-switches and click-switches as shown in the below diagram.

  • Page 6: Cable Connection

    2. 7 Cable connection 2. 7. 4 Alarm connection 2. 7. 1 Power/Data communication cable connection COM A (Controller) N.C A N.O A AC 24V ALARM4 AC 24V ALARM3 F GND ALARM2 ALARM1 R(T)X A COM B R(T)X B N.C B TX A N.O B TX B...

  • Page 7: Installation (Indoor / Wall / Ceiling)

    3.Installtion (Indoor / Wall / Ceiling) 3. 2 Wall Mounting - The following steps of installation and connection work should be done by qualified service personnel or system installers and should conform to all local codes. - Be sure to switch the camera off before installation is completed. ①...

  • Page 8: On-Screen Display Program Menu

    4. ON-SCREEN DISPLAY PROGRAM MENU EWSJ series is programmed through the on-screen display (OSD) menus. 4. 2. 2 Keyboard Commands To access the OSD menus, you must open the main Setup Menu. - Keyboard control commands are composed of a sequence of two (2) inputs with the following convention: 1) a Command number key(s) + 2) a Function key.

  • Page 9: Motion Menu

    4. 3 Motion Menu 4. 3. 4 PATTERN - Function : Pattern function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. - Pattern No. : 4 Patterns can be stored in Keyboard menu. But if by chance your Keyboard does not MOTION MENU have this menu, then the Pattern might not be performed correctly.

  • Page 10: Dome Menu

    4. 5 Camera Menu 4. 4 Dome Menu 4. 5. 1 CAMERA 1 Setting (EWSJ-270, 330, 331, 370, 371) DOME MENU CAMERA MENU 1 ▷ TITLE POWER UP ACTION : ON ▷ FOCUS : AUTO PARK ACTION ▷ DISPLAY ON / OFF ▷...
  • Page 11 ⑤ EXPOSURE ⑨ LINE LOCK : Select INT or EXT. - BRIGHTNESS : Select brightness from 01 to 99. EXPOSURE MENU CAMERA MENU 2 CAMERA MENU 2 - SHUTER MODE : Select ESC,ANTI F or MANUAL. ▷ BRIGHTNESS ▷ LINE LOCK ▷...

  • Page 12: Camera Setting (Ewsj-E180, E260, E360, E361)

    4. 5. 2 CAMERA SETTING (EWSJ-E180, E260, E360, E361) ⑤ WB MODE WB MODE : Select AUTO, INDOOR, OUTDOOR ONEPUSH, CAMERA MENU WHITE BALANCE MENU ATW, MANUAL or ONEPUSHTRG. ▷ FOCUS MODE : AUTO ▷ WB MODE AUTO RED GAIN: Adjust red color level from 0~255.

  • Page 13: Camera Menu (Ewsj-223, 363)

    ⑧ SPECIAL 4. 5. 3 Camera Menu (EWSJ-223, 363) - DAY/NIGHT : Select AUTO, OFF, DAY or NIGHT. ZOOM MODE SPECIAL MENU - LINE LOCK : Select INT or EXT. Zoom speed can be set and decide using of digital CAMERA MENU ▷...
  • Page 14 FOCUS FOCUS MENU In Focus menu, you can set up the focus mode among Auto, One Push or Manual. Set the focus distance. FOCUS MODE : AUTO FOCUS SPD : USER select : Set ON : CAMERA MENU NEAR ▶ NEAR LIMIT : 10CM ZOOM MODE...
  • Page 15 Select ON/ OFF in AGC MODE. If you set SHUTTER in the AE MODE, you can control image AE EXPO.MENU AUTO EXPO.MENU brightness by adjusting shutter speed. select : Set ON : AE MODE : AUTO NEAR AE MODE : AUTO SHUTTER SPED : AUTO Set from 1/60 , 1/90 , 1/100, 1/180, 1/250, 1/500, 1/1000, SHUTTER SPED : AUTO...
  • Page 16 ICR MODE WHTE BALANCE Set the LED operating depend on IRC Mode. Set the white balance of camera. Select AUTO, DAY ,NIGHT, EXIT and SENSE IN mode and the LED will be operated depend on this mode. White balance setting is a function revising color temperature CAMERA MENU to resolve the problem that screen’s colors change by the color ▶...
  • Page 17 If you set ON in the LINE LOCK menu, you can set SPECIAL SPECIAL MENU the V PHASE. In the Special menu, it’s available to set APERTUREGAIN, BACK LIGHT, DAY&NIGHT MODE, APERTUREGAIN : 07 DAY&NIGHT LEVEL and WDR. FLICKERLESS : OFF select : Set ON : NEAR...

  • Page 18: Clear Menu

    - ID Address : Up to 255 selectable ID (Rotary switch) - Data Communication Control : RS-485 / RS-422 - Protocol : Multiple protocol (PELCO-D/P , WONWOO) - Baud rate : 2400, 4800, 9600, 19200, 38400, 57600 bps selectable - Alarm In...

  • Page 19: Camera Specification

    5. 2 Camera Specification 5. 2. 2 EWSJ-330 - Image Sensor : 1/4 inch Sony Super HAD CCD 5. 2. 1 EWSJ-270 - Lens : 33x Optical Zoom - Image Sensor : 1/4 inch Sony Super HAD CCD - Total Pixels (HV) : 811 x 508 (NTSC), 795 x 596 (PAL) - Lens : 27x Optical Zoom...
  • Page 20 5. 2. 4 EWSJ-370 5. 2. 3 EWSJ-331 - Image Sensor : 1/4 inch Sony Super HAD CCD - Image Sensor : 1/4 inch Double Density Interline Transfer CCD - Lens : 37x Optical Zoom - Lens : 33x Optical Zoom - Total Pixels (HV) : 811 x 508 (NTSC), 795 x 596 (PAL) - Total Pixels (HV)
  • Page 21 5. 2. 5 EWSJ-371 5. 2. 6 EWSJ-E180 - Image Sensor : 1/4 inch Double Density Interline Transfer CCD - Image Sensor : 1/4 Inch, Exview HAD CCD - Lens : 37x Optical Zoom - Lens : 18x Optical Zoom...
  • Page 22 5. 2. 8 EWSJ-E360 5. 2. 7 EWSJ-E260 - Image Sensor : 1/4 Inch, Exview HAD CCD - Image Sensor : 1/4 Inch, Exview HAD CCD : 36x Optical Zoom - Lens - Lens : 26x Optical Zoom - Effective Pixels : NTSC : 380K Pixels, PAL : 440K Pixels - Effective Pixels : NTSC : 380K Pixels, PAL : 440K Pixels...
  • Page 23 5. 2. 10 EWSJ-363 ( EM-363N, EM-363P ) 5. 2. 9 EWSJ-E361 - Image Sensor :1/4" SONY Super HAD II(Double Scan) CCD - Image Sensor : 1/4 Inch, Interline Dual Scan CCD - Total Pixels :1028(H) × 508(V) , 1028(H) x 596(V) - Lens : 36x Optical Zoom - Scanning system...

  • Page 24: Dimension

    6. DIMENSION 5. 2. 11 EWSJ-223 ( EM-223N, EM-223P) 6. 1 EWSJ Series - Image Sensor : 1/4" SONY Super HAD II(Double Scan) CCD - Total Pixels : 1028(H) × 508(V) , 1028(H) x 596(V) - Scanning system : Interlace - Scanning Frequency : 15.734KHz(H),59.94Hz(V) , 15.734KHz(H),59.94Hz(V) - Sync.

  • Page 25: Pmb-600(Parapet Mount Bracket)

    7. CONFIGURATION 7. 1 Control from Keyboard WTX-2000 or DVR 6. 3 PMB-600(Parapet Mount Bracket) 647.00 1.25 Inch 250.00 PMB-600 - Stainless steel(SUS) body - Unit : 5.2Kg - Silver color - Maximum load : 20Kg - Dimensions : 890x650 (Arm) - 250 x 350 (Mount plate) - 1.25 Inch to 1.5 Inch pipe adaptor Unit : (mm)

  • Page 26: Connecting To Wtx-1200A With Dvr

    7. 2 Connecting to WTX-1200A with DVR 7. 3 Connecting to WTX-1200A with DVR...
  • Page 27 MEMO MEMO...
