Wonwoo HDSC-S202M Installation & Operating Manual

Full hd mega-pixel speed, wall/in-ceiling/ceiling
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION / OPERATING MANUAL
Full HD Mega-pixel Speed Dome Camera
P/N : 388065420
PRINTED IN KOREA
Distributed by
Wall
In-Ceiling
Ceiling
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDSC-S202M and is the answer not in the manual?

Questions and answers

Related Manuals for Wonwoo HDSC-S202M

Summary of Contents for Wonwoo HDSC-S202M

  • Page 1 INSTALLATION / OPERATING MANUAL Full HD Mega-pixel Speed Dome Camera P/N : 388065420 PRINTED IN KOREA Distributed by Wall In-Ceiling Ceiling Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. PRECAUTIONS 1. 1 Important Safety Instruction 1. PRECAUTIONS • Read these instructions. 1. 1 Important Safety Instruction ................... 2. GETTING STARTED • Pay attention on all the warnings. 2. 1 Descriptions ......................• Follow all instructions. 2.

  • Page 3: Getting Started

    2. GETTING STARTED 2. 1 Descriptions 2. 3 EWSJ Series Selection Flow The Dome Supremacy EWSJ series are an outdoor speed PTZ dome system designed for IP66 applications, 2. 3. 1 Indoor especially, whether it is raining, snowing or sunny day, this EWSJ series delivers superior performance. Model Select Mount Type The EWSJ series is one unit of housing with pole, corner, wall or recessed ceiling mounts.

  • Page 4: Ewsj Series Accessories Selection (Sold Separately)

    2. 4 EWSJ Series 2. 5 EWSJ Series Accessories Selection (Sold Separately) 2.4. 1 EWSJ Series Models ITEM Model Name Image Description EWSJ-M202: 1/3" Type Exmor CMOS Sensor optical 20×with WDR - Steel body In-ceiling mount EWSJ-FC - Unit : 0.4Kg 1/3"...

  • Page 5: Dip Switch Setting

    S202 : 10-digit number of address (ID) PELCO-D 2400 EH-6300 RS-485 MM-202 PELCO-P 4800 S203 : 1-digit number of address (ID) WONWOO 9600 Ex) If SW203=8, SW202=2, SW201=1, (SW201, SW202, SW203) 19200 the ID number is 128 38400 SW206 57600...

  • Page 6: Cable Connection

    3.Installtion (Indoor / Wall / Ceiling) 2. 7 Cable connection - The following steps of installation and connection work should be done by qualified service personnel or system installers and should conform to all local codes. - Be sure to switch the camera off before installation is completed. - Do not install the camera near the air outlet of an air conditioner.

  • Page 7: Wall Mounting

    4. ON-SCREEN DISPLAY PROGRAM MENU 3. 3 Wall Mounting EWSJ series is programmed through the on-screen display (OSD) menus. To access the OSD menus, you must open the main Setup Menu. ① ② ③ ④ 4. 1 Powering On When turning EWSJ series camera power on, there is a ten (10) second pause before the camera starts its homing phase.

  • Page 8: Motion Setting

    4. 2. 2 Keyboard Commands - Keyboard control commands are composed of a sequence of two (2) inputs with the following The initialize screen is shown up to check address, version, INITIALIZE convention: 1) a Command number key(s) + 2) a Function key. protocol and video when the power on.
  • Page 9 (2) Set the Preset Label (5) “Save” above setting Pattern data to the memory. PRESET MENU Move : Select : Delete : TELE WIDE (6) “CLR” means above setting Pattern data will not be PRESET NO : 01 DEFINE JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Preset.
  • Page 10 4. 3. 2 Tour (2) Set the Tour Label Move : Select : Delete : TELE WIDE Tour Quick Operating Guide MAIN MENU JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Tour. MOTION ▶...
  • Page 11 4. 3. 3 Scan (2) Set the Scan Label Move : Select : Delete : TELE WIDE MAIN MENU Scan Quick Operating Guide JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Scan. MOTION ▶...
  • Page 12 4. 3. 4 Pattern (5) Set the Scan speed SCAN MENU Increase : TELE Tour Quick Operating Guide MAIN MENU SCAN NO : 01 DEFINE LABEL : SCAN 01 JOYSTICK START POS : 000 . 0 , 000 . 0 END POS : 000 .
  • Page 13 (2) Set the Pattern Label (5) “Save” above setting Pattern data to the memory. PATTERN MENU Move : Select : Delete : TELE WIDE (6) “CLR” means above setting Pattern data will not be JOYSTICK JOYSTICK PATTERN NO : 01 DEFINE LABEL : It’s available to set the desired label, displayed on the executing screen of Pattern.
  • Page 14 (3) Define the Start pan position 4. 3. 5 Area ① Select the “Start Pan Pos” menu ② Move and set the position ③ Set & Back MAIN MENU MOTION MENU NEAR NEAR MOTION ▶ PRESET ▶ DOME ▶ TOUR ▶...
  • Page 15 4. 3. 6 Alarm (3) Define the Preset position with Alarm trigger ① Select the “Preset No” ② Move and set the position ③ Set & Back MOTION MENU MAIN MENU NEAR NEAR PRESET ▶ MOTION ▶ TOUR ▶ DOME ▶...
  • Page 16 (3) “Save” above settings of Privacy Zone data to the memory. 4. 3. 7 Privacy Zone Masking PRIVACY MENU (4) “CLR” means above setting of Privacy Zone data will not PRIVACY NO : 01 UNDEFINE MAIN MENU MOTION MENU be saved and be cleared. POSITION : XXX .

  • Page 17: Dome Setting

    4. 4 Dome Setting 4. 4. 3 PARK ACTION DOME MENU This function enables to locate the camera to specific MAIN MENU TITLE : EH-202 position automatically if operator doesn’t operate the POWER UP ACTION : ON PARK ACTION ▶ controller for a while.

  • Page 18: Camera Setting

    4. 5 Camera Setting 4. 4. 4 Display ON/OFF Set You can select the OSD ON to shown on the screen or clear by selecting OFF in this function. 4. 5. 1 CAMERA MENU (EH-6300) select : Set ON : Set OFF : CAMERA MENU NEAR...
  • Page 19 ② FOCUS MODE - AF MODE Set the AUTO FOCUS MODE position In Focus menu, you can set up the focus speed, focus mode, FOCUS MENU CAMERA MENU near limit, AF mode and sensitivity. select : NEAR Set ON : Set OFF : NEAR FOCUS SPD...
  • Page 20 ③ WHTE BALANCE Set the white balance of camera. - AE MODE White balance setting is a function revising color temperature to Select AUTO,MANUAL,SHUTTER, IRIS or BRIGHT. AUTO EXPO. MENU CAMERA MENU resolve the problem that screen’s colors change by the color ▷...
  • Page 21 ⑤ WDR MODE - IRIS LEVEL If you set IRIS in the AE MODE, you can set the IRIS level Select WDR(Wide Dynamic Range) AUTO EXPO. MENU from 00 to 17. CAMERA MENU AE MODE : IRIS ZOOM MODE ▷ EXPOSURE select : Set ON :...
  • Page 22 - BLOCKED UP LEVEL - SHORT EXPOSURE Select short exposure Select blocked up level (LOW.MID.HIGH) WDR MODE MENU WDR MODE MENU WDR MODE : WDR OFF WDR MODE : WDR OFF select : NEAR Set ON : Set OFF : NEAR select : NEAR...
  • Page 23 ⑥ SPECIAL - GAMMA GAMMA : Select light and shade level In the Special menu, it’s available to set special function SPECIAL MENU CAMERA MENU of the camera HR MODE : ON ZOOM MODE ▷ select : NEAR Set ON : Set OFF : NEAR NR LEVEL...
  • Page 24 - BACK LIGHT ⑦ CAMERA RESET Select ON/OFF in the BACK LIGHT function. SPECIAL MENU Make initialize the setting value which is set in CAMERA MENU. CAMERA MENU ENHANCE MODE ▷ select : NEAR Set ON : Set OFF : NEAR APERTUREGAIN : 05...
  • Page 25 ② FOCUS MODE 4. 5. 2 CAMERA MENU(MM-202) In Focus menu, you can set up the focus speed, focus mode, CAMERA MENU near limit, AF mode and sensitivity. CAMERA MENU MAIN MENU ZOOM MODE ▷ MOTION → ▷ ZOOM MODE ▷...
  • Page 26 - AF MODE ③ WHTE BALANCE Set the white balance of camera. Set the AUTO FOCUS MODE position White balance setting is a function revising color temperature to FOCUS MENU CAMERA MENU resolve the problem that screen’s colors change by the color Select : NEAR Set ON :...
  • Page 27 - AE MODE - IRIS LEVEL Select AUTO,MANUAL,SHUTTER, IRIS or BRIGHT. If you set IRIS in the AE MODE, you can set the IRIS level AUTO EXPO. MENU AUTO EXPO. MENU from 00 to 20 ▷ AE MODE : AUTO Select : NEAR Set ON :...
  • Page 28 ⑥ SPECIAL ⑤ WDR MODE In the Special menu, it’s available to set special function Set WDR funtion CAMERA MENU CAMERA MENU of the camera WDR(Wide Dynamic Range) ZOOM MODE ▷ ZOOM MODE ▷ FOCUS MODE ▷ FOCUS MODE ▷ WHITE BAL.
  • Page 29 - ICR AUTO GAP - DNR LEVEL Select the ICR level. Select the DNR level from AUTO, LEV1, LEV2, LEV3 and OFF. SPECIAL MENU SPECIAL MENU ICR MODE : AUTO ICR MODE ▶ ICR AUTO THRES : 01 APERTUREGAIN : 05 ▷...

  • Page 30: Clear Setting

    5. SPECIFICATION 4. 6 Clear Setting 5. 1 Mechanism Specification Clears the PTZ position and function value. With this function the camera keeps the accuracy 5. 1. 1 MECHANICAL of the PTZ position value. - Pan : 360° Continuous Pan, 0.1º to 160º/sec. (64 steps proportional to zoom) - Pan Preset Speed : 330°/sec, ±...

  • Page 31: Camera Specification

    5. 2 Camera Specification 5. 2. 2 MM-202 Image Sensor 1/3" Panasonic CMOS Sensor 5. 2. 1 EH-6300 Total Pixels 2,010(H) x 1,108(V), 2.2M Pixels Imager 1/3 Type Exmor CMOS Sensor Active pixels 1,944(H) x 1,092(V), 2.1M Pixels Picture elements 2000K pixels Scanning system Progressive Scan...

  • Page 32: Dimension

    6. DIMENSION 6. 3 PMB-600(Parapet Mount Bracket) 6. 1 EWSJ Series 647.00 1.25 Inch 250.00 PMB-600 - Stainless steel(SUS) body - Unit : 5.2Kg Unit : (mm) Unit : (mm) - Silver color - Maximum load : 20Kg - Dimensions : 890x650 (Arm) 6.

  • Page 33: Configuration

    7. CONFIGURATION MEMO 7. 1 Control from Keyboard WTX-1200A or DVR RS485 HDMI Video In Video Out...
