INSTALLATION / OPERATING MANUAL
IR PTZ Camera
- Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
- The design and specifications are subject to be changed without prior notice to improve
product's quality.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMK-H208 and is the answer not in the manual?

Questions and answers

Related Manuals for Wonwoo MMK-H208

Summary of Contents for Wonwoo MMK-H208

  • Page 1 INSTALLATION / OPERATING MANUAL IR PTZ Camera - Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. - The design and specifications are subject to be changed without prior notice to improve product’s quality.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. PRECAUTIONS 1. 1 Important Safety Instruction ................... 2. GETTING STARTED 2. 1 Unpacking ......................2. 2 Part name ......................2. 3 DIP Switch Setting ....................2. 4 Cable Connection ....................3. INSTALLATION 3. 1 Installation ......................4.

  • Page 3: Precautions

    1. PRECAUTIONS 1. 1 Important Safety Instruction • Read these instructions. • Pay attention on all the warnings. • Follow all instructions. • Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. • Do not dissemble or insert foreign objects. •...

  • Page 4: Getting Started

    2. GETTING STARTED 2. 1 Unpacking The following parts are supplied with the outdoor speed PTZ dome system. <Figure 1. package Components> SCREW (M4*8 SUS) SCREW (SET ANCHOR 1/4") Body Mount Screw Screw Wiper(Spare) Mount joint Manual Power adaptor(Option) <Wall type> <Ceiling type>...

  • Page 5: Dip Switch Setting

    2. 3 DIP Switch Setting Before start up the dome camera, set the protocol and camera address and termination set with dip-switches and click-switches as shown in the below diagram. 1.Set the camera address (ID) Open the top cover of the product to set camera address. S1 : 1-digit number of address S3 : 10-digit number of address Address switch...

  • Page 6: Cable Connection

    2. 4 Cable connection 2. 4. 1 Power/Data communication cable connection SPK:LGR MIC:PK RY1-COM:WT RY1-NO:GRY RY2-COM:VI RY2-NO:BL GND:GR AL1:YL AL2:OR AL3:RD AL4:BR GND:BK MAIN CABLE HD-SDI CABLE 2. 4. 2 RS-485/RS-422 Connection RS-422/485 connection The PTZ can be remotely controlled by an external device or control system, such as a control keyboard or DVR, using RS-485 half-duplex, RS-422 duplex or simplex serial communication signals.

  • Page 7: Installation

    3. Installtion - The following steps of installation and connection work should be done by qualified service personnel or system installers and should conform to all local codes. - Be sure to switch the camera off before installation is completed. - Do not install the camera near the air outlet of an air conditioner.
  • Page 8 OPEN CLOSE (Turn the body to clockwise) SAFTY LOOP 1. Connect the safety loop on the body and mount back side. 2. Connect MAIN cable and HD-SDI cable onto the main body as figure. (Caution! Fix the main body tightly.) 3.

  • Page 9: Main Setup Menu

    4. MAIN SETUP MENU INITIALIZE 4. 1 Initialize PTZ ID : 001 VERSION : X. XX D-OUTPUT : 1080p30/NTSC When the device is powered on, you can check the address, PROTOCOL : PELCO-D version, protocol and video setting values. BAUDRATE : 2400.N.1 CAMERA : XX XXX..OK...
  • Page 10 (2) Set the Preset TITLE Move : Select : Delete : TELE WIDE JOYSTICK JOYSTICK It’s available to set the desired TITLE, displayed on the executing screen of Preset. PRESET MENU PRESET TITLE EDIT ( 01 ) TITLE : NUMBER : 001 0 1 2 3 4 5 6 7 8 9 ( TITLE FOCUS...
  • Page 11 (5) EXIT TIME Setting the dwell time to exit Preset mode after PRESET MENU completing Preset working. (OFF / 5SEC / 10SEC / 20SEC / 30SEC / 1MIN / NUMBER : 001 5MIN / 10MIN / 30MIN) ※ Default : OFF TITLE FOCUS : AUTO...
  • Page 12 4. 2. 2 Tour MOTION MENU MAIN MENU PRESET TOUR ▶ ▶ MOTION GROUP DOME SCAN CAMERA PATTERN CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ TOUR > The Tour function consists of several presets run by turn.
  • Page 13 (3) Define the Preset position ① Move to the set-up window ② Move and set the position ③ Set & Back NEAR NEAR TOUR MENU TOUR EDIT (01) TOUR MENU PRESET SELECT : 001 PRESET SPEED DWELL P001 P002 P003 P004 P005 ◀...
  • Page 14 4. 2. 3 Group MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP ▶ DOME SCAN CAMERA PATTERN CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ GROUP > GROUP : You can make Max.
  • Page 15 (3) GROUP SET ① Move to the set-up window ② Move and set the position ③ Set & Back NEAR NEAR GROUP EDIT (01) GROUP MENU TOUR NUMBER : 01 <001> TITLE : GROUP SET ▶ SAVE BACK EXIT < SEL & NEAR PRESET &...
  • Page 16 4. 2. 4 Scan MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN ▶ CAMERA PATTERN CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ SCAN > The Scan function means that the camera keeps panning between two programmed pan positions.
  • Page 17 (3) Set the Scan speed SCAN MENU Increase : TELE NUMBER : 01 JOYSTICK TITLE SPEED : NONE DWELL : NONE MOTION TYPE : NONE Decrease : WIDE DIRECTION : NONE START POS JOYSTICK END POS SAVE BACK EXIT It adjusts the moving speed from 1~63 steps. <...
  • Page 18 (6) Set the Direction SCAN MENU PAN : Select Clock Wise or C_Clock Wise direction NUMBER : 01 When select C_Clock WISE, counterclockwise progression TITLE SPEED : NONE When select Clock WISE, clockwise progression DWELL : NONE TILT : MOTION TYPE : NONE Set the UP &...
  • Page 19 (9) “Save” above setting Pattern data to the memory. SCAN MENU NUMBER : 01 (10) “CLR” means above setting Pattern data will not be TITLE : NONE SPEED : NONE saved and be cleared. DWELL : NONE MOTION TYPE : NONE DIRECTION : NONE START POS...
  • Page 20 4. 2. 5 Pattern MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN CAMERA PATTERN ▶ CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ PATTERN > The Pattern function memorizes User’s random moving path and zoom ratio.
  • Page 21 (3) Record and Save the User’s random Pattern data ① Select the “Record” Menu ② Move and record the pattern ③ NEAR -> EXIT FAR -> RECORD ON NEAR PATTERN MENU PATTERN RECORD NUMBER : 01 TITLE RECORD ▶ PLAY <NEAR EXIT>...
  • Page 22 4. 2. 6 Area MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN CAMERA PATTERN CLEAR AREA ▶ FACTORY SET ALARM PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ AREA > The Area function means that it displays the Area name between two programmed pan positions.
  • Page 23 (3) Set the Direction Select : Set ON : Set OFF : NEAR NEAR C_Clock WISE is counterclockwise mark, Clock WISE is clockwise mark. AREA MENU NUMBER : 01 TITLE DIRECTION : <C_CLOCK WISE> S PAN POS. E PAN POS. SAVE BACK EXIT...
  • Page 24 (6) “Save” above setting Area data to the memory. AREA MENU (7) “CLR” means above setting Area data will not be NUMBER : 01 TITLE saved and be cleared. DIRECTION : NONE S PAN POS. E PAN POS. (8) “BACK” means it goes back to the previous menu :Motion.
  • Page 25 4. 2. 7 Alarm MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN CAMERA PATTERN CLEAR AREA FACTORY SET ALARM ▶ PTZ RESET PRIVACY HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ ALARM > The Alarm function means that the camera moves to the programmed Preset position by the Alarm trigger.
  • Page 26 (3) Define the Preset position with Alarm trigger ① Select the “Preset Num” ② Move and set the position ③ Set & Back NEAR NEAR ALARM MENU ALARM MENU PRESET SELECT : 001 P001 P002 P003 P004 P005 NUMBER : 01 TITLE PRESET NUM : NONE SAVE...

  • Page 27: Privacy Zone Masking

    4. 2. 8 Privacy Zone Masking MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN CAMERA PATTERN CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY ▶ HOME POS EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > <...
  • Page 28 (3) “Save” above settings of Privacy Zone data to the memory. PRIVACY MENU (4) “CLR” means above setting of Privacy Zone data will not NUMBER : 01 MASK SET ▷ be saved and be cleared. (5) “BACK” means it goes back to the previous menu :Motion.

  • Page 29: Home Position

    4. 2. 9 Home Position MOTION MENU MAIN MENU PRESET TOUR ▶ MOTION GROUP DOME SCAN CAMERA PATTERN CLEAR AREA FACTORY SET ALARM PTZ RESET PRIVACY HOME POS ▶ EXIT BACK EXIT < NEAR / RIGHT ▷ MOTION > < NEAR / RIGHT ▷ HOME POS > Home Postion : Move to selected home position.(255+PRESET) (1) Home Position ON/OFF setting Move :...

  • Page 30: Dome Setting

    4. 3 Dome Setting MAIN MENU MOTION DOME ▶ CAMERA CLEAR FACTORY SET PTZ RESET EXIT < NEAR / RIGHT ▷ DOME > Pan, Tilt, Zoom motion is adjustable in the “Dome Setting” Menu. 4. 3. 1 Set the Dome camera title Move : Select : Delete :...
  • Page 31 4. 3. 3 OSD ON/OFF Set You can select the OSD ON to shown on the screen or clear by selecting OFF in this function. Select : Set ON : Set OFF : NEAR NEAR DOME MENU OSD ON/OFF TITLE <0>...
  • Page 32 4. 3. 5 TEMP MODE DOME MENU It shows you the current temperature and you can also set TITLE the value manually. The compulsory Fan & Heater operation SPEED BY ZOOM : ON OSD ON/OFF is a useful function to remove humidity. PARK MODE TEMPERATURE ▶...
  • Page 33 (4) FAN ON TEMP. MENU Set the operating temperature of the Fan. (0~70℃) HEATER ON : 5 C ON TIME : 30 MIN HEATER OFF : 30 C Select : Set ON : FAN ON : 50 C NEAR FAN OFF : 40 C Set OFF : CURRENT TEMPER : 024.9...
  • Page 34 4. 3. 6 Special DOME MENU TITLE SPEED BY ZOOM : ON OSD ON/OFF PARK MODE TEMPERATURE ▶ SPECIAL ZERO POS DOME RESET NEXT SAVE BACK EXIT < NEAR / RIGHT SUB MENU > (1) HDSDI FORMAT SPECIAL MENU - 1080p/30(25)fps / 720p/60(50)fps HDSDI FAMAT : 1080p30 POWER UP...
  • Page 35 (4) SCROLL TYPE SPECIAL MENU Set the cursor progress HDSDI FAMAT : 1080p30 POWER UP : OFF STEP : by 1 STEP AUTO FLIP : OFF SCROLL TYPE : STEP AUTO : Continuous scroll RESPONSE : OFF P-FREEZE : OFF Select : Set ON : NEAR...

  • Page 36: Dome Reset

    4. 3. 7 ZERO POS DOME MENU TITLE SPEED BY ZOOM : ON OSD ON/OFF PARK MODE TEMPERATURE SPECIAL ZERO POS ▶ DOME RESET NEXT SAVE BACK EXIT < NEAR / RIGHT ZERO POS > When select ON, the zero position is changeable.
  • Page 37 DOME MENU DOME MENU TITLE EXTERNAL IR SET ▶ SPEED BY ZOOM : ON WIPER SETTING ▷ OSD ON/OFF PARK MODE TEMPERATURE SPECIAL ZERO POS DOME RESET NEXT SAVE BACK EXIT NEXT SAVE BACK EXIT < NEAR / RIGHT SUB MENU > <...
  • Page 38 (3) ICR CHG LUX DOME MENU Set the Day / Night ICR illumination. (0.5~10) IR SYNC MODE : ALS SYNC IR ILLUMINATE : HIGHEST ※ Factory default is 2 LUX. ICR CHG LUX : 2 LUX IR CONT. TYPE : AUTO IR OFFSET Select : Set ON :...
  • Page 39 4. 3. 10 WIPER SETTING Set the wiper function. DOME MENU EXTERNAL IR SET ▶ WIPER SETTING ▶ < NEAR / RIGHT SUB MENU > NEXT SAVE BACK EXIT (1) WIPER MODE DOME MENU Select ON MODE / OFF MODE / TIME SET to use the wiper function. WIPER MODE : OFF MODE WIPER POS.

  • Page 40: Clear Setting

    4. 4 Clear Setting Clears the PTZ position and function value. Select : Set ON : Set OFF : NEAR NEAR MAIN MENU CLEAR MENU PRESET <X> PRIVACY MOTION HOME POS. TOUR DOME ZERO POS. GROUP CAMERA MOTION ALL X SCAN CLEAR ▶...

  • Page 41: Specification

    5. SPECIFICATION 5. 1 Mechanism Specification 5. 1. 1 MECHANICAL - Pan : 360° Continuous Pan, 0.1º to 120º/sec. - Pan Preset Speed : 360°/sec, ± 0.1° Accuracy - Tilt : -8°(352°) to 188° movement, 0.1°~80°/sec (proportional to zoom) - Tilt Preset Speed : 250°/sec, ±...

  • Page 42: Dimension

    6. DIMENSION 6. 1 DIMENSION 1-1/2inch PF TAP 155.2 Ø180...
  • Page 43 4-Ø8.5 Ø180...
  • Page 44 155.2 Ø180...

  • Page 45: Configuration

    7. CONFIGURATION 7. 1 Connecting to Keyboard with DVR...
  • Page 46 P/N : 388068605 PRINTED IN KOREA Distributed by...
