Wonwoo PS-100N Installation & Operating Manual

10x ptz dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Distributed by
Installation / Operating Manual
10X PTZ DOME CAMERA
W-388058120
Before attempting to connect or operate this product,
PRINTED IN KOREA
please read these instructions carefully and save this manual for future use
PS-100N
PS-100P
Surface Mount
In-Ceiling Mount

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-100N and is the answer not in the manual?

Questions and answers

Related Manuals for Wonwoo PS-100N

Summary of Contents for Wonwoo PS-100N

  • Page 1 Installation / Operating Manual 10X PTZ DOME CAMERA PS-100N PS-100P Distributed by Surface Mount In-Ceiling Mount W-388058120 Before attempting to connect or operate this product, PRINTED IN KOREA please read these instructions carefully and save this manual for future use...

  • Page 2: Table Of Contents

    CONTENTS USER INFORMATION CAUTION 1. USER INFORMATION RISK OF ELECTRIC SHOCK DO NOT OPEN 2. FEATURES CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, 3. PRECAUTIONS DO NOT REMOVE COVER (OR BACK). 4. PTZ SETTING & INSTALLATION NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED Unpacking SERVICE PERSONNEL.

  • Page 3: Features

    FEATURES PRECAUTIONS Do not install the camera in extreme temperature conditions. The PS-100 series is a compact 10X Day&Night Speed dome camera which can be applied Do use the camera under conditions where temperatures are within -10°C to 50°C. in any surveillance applications. Optical zoom camera is packaged in compact housing with Under high temperatures, ensure proper ventilation.

  • Page 4: Ptz Setting & Installation

    To install and use the PS-100, the followings should be needed. (NOT included in box) 3. Baud : Set the Communication baudrate (2400~19200bps) 4. Protocol : Set the protocol (PELCO-D, PELCO-P , WONWOO) 1) Power adaptor (Over 1A) The power adaptor should have capacity over 1 Ampere.

  • Page 5: Installation & Cable Connection

    PTZ SETTING & INSTALLATION PTZ SETTING & INSTALLATION 2. Installation & Cable connection RS-485 Termination Precautions for Installation In RS-485 communication, the first and last devices (PTZ or keyboard controller) should be terminated for more - Ensure that the installation location can safely bear min. 2Kg and its installation fittings. stable data communication by setting DIP switch.
  • Page 6 PTZ SETTING & INSTALLATION PTZ SETTING & INSTALLATION Connect the external cables to the camera (Video, Prepare the installation accessories provided in the STEP 3 STEP 3. STEP 1 STEP 1. Power, RS-485 communication, Alarm-in, and Relay-out) camera box. The Video and RS-485 control cables, Power adaptor (over 1A) and installation tools are necessary to complete the installation.

  • Page 7: On Screen Display Menu

    On Screen Display Menu On Screen Display Menu (1) MOTION MENU INITIALIZE When you turn on the power, the INITIALIZE screen on the monitor will appear. During Initialization, you can check the PTZ information. If the information is different with your desired setting, turn MOTION MENU off the camera and check the DIP switches again.
  • Page 8 On Screen Display Menu On Screen Display Menu ② TOUR ④ P A T TERN The T our function consists of several presets which r un in sequence. Also, the moving The P atte r n function memorizes the user's random moving path and zoom ratio. There are four speed(0~63 step) and dwell time (1~99sec) is adjustable.

  • Page 9: Dome Menu

    On Screen Display Menu On Screen Display Menu ⑥ A L ARM (2) DOME MENU The Ala r m function enables the camera to move to the programmed P reset position when the ala r m is triggered. This camera suppo r ts 2 No r mal Open Ala r m functions. DOME MENU -------------------------- ¢¹...

  • Page 10: Camera Menu

    On Screen Display Menu On Screen Display Menu (3) CAMERA MENU A TW : Balances the color automatically depending on the source of light from1,800~10,500K color temperature. * Indoo r : Use this mode in the area under the limited color temperature. ①...

  • Page 11: Clear Menu

    On Screen Display Menu DIMENSIONS (mm) ⑥ D A Y&NIGHT < Surface Mount > The darkness level is detected automatically under low light conditions such as at night or under dark light to keep the screen bright and clea r . CO L OR : Output images are displayed in color all the time.

  • Page 12: Specifications

    SPECIFIC A TIONS QUICK COMMAND Mode PS-100N PS-100P PROTOCOL FUNCTION WONWOO Image Pick-up Device Total Pixels 811(H) x 508(V) 795(H) x 596(V) GOTO PRESET 1~63 PRESET 1~63 PRESET 1~63 PRESET Effective Pixels 768(H) x 494(V) 752(H) x 582(V) SET PRESET...
