position 1, reverse the
above process for both
shocks.
Pull Up
Sharply
14. FOLDING:
Remove children from
stroller. Remove the
contents of the Low Boy
cargo pouch, seat back
and seat pockets.
Unbuckle AFOD strap
(Fig. 16.). The shock AFOD
(Unbuckled)
absorbers must be in
position 1 (Fig. 2) before
folding. Press both the
Fig. 23
right and left handlebar
release levers (Fig. 3),
and fold the handlebar
forward as shown in Fig.
22. Locate the frame release handle
underneath the seat (Fig. 23) and pull
upwards sharply. This will allow
the lower frame to fold
together, as shown in
Fig. 24. The folded
stroller can be made
even more compact
by removing the front
and rear wheels. The
front wheel is removed by
opening the front wheel
Handlebar
quick release and
removing the wheel (see
section 5). The rear
wheels are removed by
releasing the parking
brake (See section 8),
and then opening the
rear wheel quick release
(Fig. 4), and pulling each
wheel directly to the side.
The Wrist Safety Strap
can be used to keep the
stroller in the folded
position for transport and
storage. With the stroller
folded, loop the end of
Fig. 25
the wrist safety strap
around the handlebar
and back to the cross tube and fix the Velcro surfaces together (Fig.
25).
15. TIRE PRESSURE: IMPORTANT: Check tire pressure before
every use. Keep all tires inflated to pressure specified on the rim (30
p.s.i.).
16. STROLLER
CARE &
Apply Lubricant
MAINTENANCE:
to Interior Faces
The fabric is 100% of Bracket
polyester with a stain
resistant treatment
that makes cleanup
easy. Use a sponge
with a solution of mild
soap and lukewarm
Apply Lubricant
water (maximum
to Axle
temperature of 100
deg. F / 38 deg. C). Rinse
thoroughly with clean water to
remove soap then air dry. Do not
use detergent.
Red
Frame
Release
Handle
Pull red handle upwards
sharply to fold swing arm.
Fig. 24
Stroller in fully folded position.
Cross
Tube
Wrist
Velcro
Strap
Secure stroller in folded position.
Fig. 26
Lubrication Points
5475 Gage St. Boise, Idaho 83706
Regular maintenance should include: Verifying tire pressure, verifying
that all screws and fasteners are tight, and wiping parts clean with a
rag. To reduce the possibility of squeaks, periodically apply a small
amount of lubricant (Triflow, 3-in-one, or light sewing machine oil) to
the pivot axles and interior faces of the pivot brackets, as shown in
Fig. 26.
STORAGE: It is best to store your stroller indoors when it is not in
use. This will prolong its attractive appearance. Extended exposure
to the sun's ultraviolet rays can fade and damage the fabric, tires,
and plastic parts.
CARGO: The Revolution Duallie is equipped with four small pockets
for the kids, a seatback pocket behind each seat and a Low Boy cargo
pouch under the stroller. Adding weight to the seatback changes the
center of gravity of the stroller, and increases the possibility that it will
tip over backwards. For this reason, loads in the seatback pocket
should never exceed two pounds (1 kg.). Although the seatback is
padded, it is important to remember that this is what your child leans
against. Never place sharp or injurious objects into the seatback
pocket. Maximum load for Low Boy is 10 lbs (5.5 kg).
LIMITED WARRANTY
BOB Trailers Inc. takes pride in its workmanship and strives to
manufacture the best products possible. Therefore, we warranty our
Revolution Duallie strollers against defects in material and workmanship
subject to the conditions listed below. Since no product is indestructible,
it does not cover defects attributable to or resulting from normal wear,
abuse or alteration.
. Frame is warranted for 5 years.
. Components and fabric are warranted for one year.
. Warranty is only valid for the original purchaser.
. Proof of purchase is required to exercise this warranty.
. Labor and freight charges are not included.
. Normal wear, neglect, abuse, accidents, improper assembly or
maintenance, or the installation of parts or accessories not compatible
with the original intended use of the stroller, as sold, are not covered
by this Warranty.
. Warranty claims must be made through an authorized dealer.
. This warranty is limited to the repair or replacement of the defective
part. BOB shall in no event be responsible for consequential or
special damages.
. This Limited Warranty is the only express or implied warranty
applicable to BOB. Any implied warranties, including warranties
of merchantability and fitness shall be limited in scope and duration
in accordance with this limited warranty.
STROLLER ACCESSORIES
BOB offers a full line of accessories for your Revolution Duallie stroller.
Visit our website for full details, specs and images:
www.bobgear.com
HANDLEBAR CONSOLE
At your finger tips storage for two water bottles or drinks and other
small items. 4 Velcro straps for easy attachment.
WARM FUZZY
Warm Fuzzy Seat Insert -The ultimate in plushness & comfort. Thick,
polypropylene fleece will give you and your child a warm fuzzy!
WEATHER SHIELD
Your little one will be dry & comfortable in bad weather, strolling with
the BOB Weather Shield!
SUN PROTECTOR
Reduces up to 65% of solar heat and glare as well as UVA/UVB rays.
Also protects children from brisk winds and flying insects.
