Bolt the support leg to the log splitter, lift the log splitter by the handles at both ends, and place
it on a stable, flat, and level work surface that is 24 – 30
1. Log pusher
2. Work table
3. Wedge
4. Support leg
5. Log retaining plates
6. Motor
7. Pushbutton box
8. Switch
9. Wheels (for minor
moving ONLY)
10. Hydraulic control
lever
11. Control lever guard
12. Bleed screw
13. Oil drain bolt with
dipstick
14. Maximum pressure
limiting screw
15. Alternate log pusher
with duo-cut wedge
.
10
9
8
12
13
15
''
(60 – 75 cm) high.
11 1
7 6
2 3
5 4
3
14
14
