Not(4): Minimum distance between dot defect
Bright dot to bright dot
Dark dot to dark dot
Bright dot to dark dot
Note(5): "Average Diameter" description
Dusts would be judged by "Average Diameter" under vertical high ≥0.1mm and horizontal width ≥0.1mm
condition.
Average Diameter D=(a+b)/2
<15mm
NG
<10mm
NG
<10mm
NG
b
a
5-6
