INSPECTION
1. Inspection of PLUG & PLAY communication and OSM "MONITOR
INFORMATION" for model name/ serial number
1.1 A construction of System
This system should be connected as shown below.
D -s u b to D -S u b 1 5 p in S ig n a l C a b le
1.2 Input Signal
Horizontal synchronization frequency
Vertical synchronization frequency
1.3 Programs required
PNP.EXE
PNP.INI
08109741.MDL
EDID550V.TXT
P R O G R A M
P A R T N o . 5 9 9 9 1 0 5 5 2
S ig n a l G e n e ra to r
R G B H V
A U T O A D J I/F J IG
P a rt N o . 5 9 9 9 1 0 4 0 1 (1 2 0 V ) (F o r A v e r.)
P a rt N o . 5 9 9 9 1 0 4 0 2 (2 2 0 V ) (F o r B v e r.)
: No specified.
: No specified.
5-1
P ro g ra m D is k
P C
P rin te r C a b le
